🔧 GLE - Transmission Fluid & Filter Service

On your GLE, the automatic transmission fluid level is set by temperature using an internal overflow tube (there’s no normal dipstick). The correct way is to drain the pan, replace the filter and pan gasket, then refill and set the level at the specified transmission temperature.

Difficulty Level: Advanced | Estimated Time: 2.5–4.0 hours

Assumption: Your GLE uses the 7G-TRONIC/722.9 style “sealed” transmission with temperature-based level setting.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface; the fluid level will be wrong if the vehicle isn’t level.
• ⚠️ Let the exhaust and transmission cool; ATF can burn skin.
• ⚠️ Use jack stands; never rely on a floor jack alone.
• ⚠️ Keep the engine running only when instructed; wheels must be chocked.
• ⚠️ Cleanliness matters: dirt in the transmission can cause shifting problems.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Trim clip tool
• Torx T25 driver
• Torx T30 driver
• 8mm socket
• 10mm socket
• 13mm socket
• Ratchet (3/8")
• Torque wrench (5–60 Nm range)
• Drain pan (at least 10-quart capacity)
• Fluid transfer pump (hand pump) (specialty)
• Mercedes 722.9 transmission dipstick tool (specialty)
• Scan tool with live data for transmission fluid temperature (specialty)
• Brake cleaner spray
• Shop rags
• Funnel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (MB spec 236.14 / 236.15 equivalent) - Qty: 8–10 quarts
• Transmission filter - Qty: 1
• Transmission pan gasket - Qty: 1
• Transmission drain plug seal ring - Qty: 1
• Transmission fill/level plug seal ring (if equipped) - Qty: 1
• Transmission electrical connector sleeve seal (pilot bushing) - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and chock the rear wheels.
• Lift the front and rear so the GLE sits level on jack stands.
• Gather a scan tool that can read “Transmission fluid temperature.” (Live data = real-time sensor reading.)
• Plan for cleanliness: lay out shop rags and use brake cleaner spray to clean the pan and mating surfaces.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the underbody shields

• Use a Torx T25 driver and 10mm socket to remove the fasteners holding the lower engine/transmission splash shields.
• Use a trim clip tool for any plastic push-clips.
• Set all hardware aside in a tray. Keep front/rear screws separated.

Step 2: Drain the transmission pan

• Place a drain pan (10-quart capacity) under the transmission pan.
• Use the correct driver/socket for the drain plug (commonly 8mm socket or Torx T30 driver, depending on plug style) and loosen it carefully.
• Let it drain until it slows to a drip.
• Reinstall the drain plug loosely for now to prevent drips while you remove the pan.

Step 3: Remove the transmission pan

• Support the pan with one hand and remove the pan bolts using a 10mm socket and ratchet (3/8").
• Lower the pan slowly; more ATF will spill when the gasket seal breaks.
• Remove the old gasket from the pan and transmission case.

Step 4: Replace the transmission filter

• Pull the filter straight down (it’s press-fit into the valve body).
• Make sure the old filter’s rubber seal/O-ring comes out with the filter. (An O-ring is a rubber sealing ring.)
• Push the new filter in firmly by hand until fully seated.

Step 5: (Recommended) Replace the electrical connector sleeve seal

• Locate the transmission electrical connector where the harness plugs into the transmission case.
• Use a Torx T30 driver to unlock/remove the retaining screw/bolt (design varies by connector style).
• Pull out the old connector sleeve, install the new sleeve, then retighten the retainer.
• This helps prevent common ATF seepage into the harness connector area.

Step 6: Clean the pan and install the new gasket

• Clean the pan thoroughly using brake cleaner spray and shop rags.
• Clean the magnet(s) in the pan; a gray paste is normal wear.
• Install the new pan gasket onto the pan.

Step 7: Reinstall the transmission pan

• Hold the pan in place and start all bolts by hand to avoid cross-threading.
• Tighten pan bolts evenly in a crisscross pattern using a torque wrench.
• Torque to 8 Nm (71 in-lbs) for the pan bolts.
• Install a new drain plug seal ring, then tighten the drain plug with a torque wrench: Torque to 20 Nm (15 ft-lbs).

Step 8: Fill the transmission with new ATF

• Locate the transmission fill port (typically accessed from underneath on this setup).
• Use a fluid transfer pump (hand pump) (specialty) to pump in fresh ATF.
• Add an initial fill of about 5–6 quarts (typical after pan drop and filter change).
• Reinstall the fill plug loosely (or keep the fill setup ready) so you can continue with level setting.

Step 9: Warm up and circulate fluid (critical for correct level)

• With the GLE still level on jack stands, start the engine.
• Hold the brake and slowly move the shifter through P-R-N-D and back, pausing 3–5 seconds in each gear to fill passages.
• Use the scan tool to monitor Transmission fluid temperature.

Step 10: Set the fluid level at temperature (sealed/overflow method)

• At ~45°C (113°F) transmission fluid temperature, set the level (this system is temperature-sensitive).
• Insert the Mercedes 722.9 transmission dipstick tool (specialty) into the dipstick tube/service port as designed for this transmission (the tool is a service-only dipstick).
• If the level is low at temperature, add ATF in small amounts (about 0.25 quart at a time) using the fluid transfer pump.
• Recheck until it reads in the correct range for the measured temperature.
• Reinstall and tighten the fill plug using a torque wrench: Torque to 20 Nm (15 ft-lbs) (typical for this style plug).

Step 11: Reinstall underbody shields

• Reinstall the splash shields using the Torx T25 driver, 10mm socket, and trim clip tool.
• Snug fasteners evenly; do not overtighten plastic clips.

---

✅ After Repair

• Start the engine and check for leaks around the pan, drain plug, and electrical connector sleeve.
• Road test gently for 10–15 minutes, then recheck for any seepage underneath.
• If shifts feel abnormal (flare, slip, harsh), re-check the level again at the correct temperature using the scan tool and dipstick tool.
• Dispose of used ATF properly at a recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$900 (parts + labor)

DIY Cost: $150–$300 (parts only)

You Save: $300–$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.0–3.0 hours.

---
