🔧 Grand Cherokee - Transmission Fluid & Filter Service

Your Grand Cherokee’s 8-speed automatic doesn’t use a dipstick. The fluid level is set through a fill port at a specific fluid temperature, so the “change” is really a drain, pan/filter replacement (recommended), and a temperature-based refill/level check.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface; support the SUV with jack stands before going underneath.
• ⚠️ Transmission fluid can be hot; let the drivetrain cool and wear gloves/safety glasses.
• ⚠️ Keep the engine running only when instructed (for final level setting); keep hands/loose clothing clear of rotating parts.
• ⚠️ Do not overfill—incorrect level can cause shifting problems and damage.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Fluid transfer pump (specialty)
• OBD2 scan tool with transmission fluid temperature data (specialty)
• Metric socket set (8mm–13mm)
• Torx bit set (T25–T40)
• 3/8" ratchet
• 3/8" torque wrench (5–60 Nm range)
• Trim clip removal tool
• Brake cleaner
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Mopar 8&9 Speed ATF) - Qty: 8 quarts
• Transmission oil pan with integrated filter - Qty: 1
• Transmission pan bolt set - Qty: 1
• Fill plug seal - Qty: 1
• Drain plug seal - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks at the rear wheels.
• Raise the front and rear so the SUV sits level on jack stands; fluid level is checked with the vehicle level.
• Connect your scan tool. A scan tool is a plug-in device that reads live data like Transmission Fluid Temperature.
• Make sure you have a way to pump fluid upward into the fill port. A fluid transfer pump is a hand pump that pushes fluid from the bottle into the transmission.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower underbody shield (if equipped)

• Use a trim clip removal tool for plastic push-clips.
• Use a Torx bit set (T25–T30) and 3/8" ratchet to remove the fasteners.
• Set the shield and fasteners aside in order. Lay bolts out in a pattern.

Step 2: Locate the transmission fill and drain points

• Position a drain pan (10-quart minimum) under the transmission pan.
• Identify the fill plug on the transmission case and the drain plug at/near the pan.
• Before draining, crack the fill plug loose using the correct Torx bit set (T40) and 3/8" ratchet so you know you’ll be able to refill.

Step 3: Drain the old transmission fluid

• Use the correct Torx bit set (T40) with a 3/8" ratchet to remove the drain plug.
• Allow fluid to drain until it slows to a drip.
• Clean the drain plug area using brake cleaner and shop towels.

Step 4: Remove the transmission pan and filter assembly

• Use an 8mm socket and 3/8" ratchet to remove the pan bolts evenly around the pan.
• Support the pan as you remove the last bolts; more fluid will spill.
• Remove the pan/filter assembly and keep it level over the drain pan.

Step 5: Clean the mating surface and prepare the new pan

• Use brake cleaner and shop towels to clean the transmission case sealing surface.
• Do not gouge the sealing surface with metal tools.
• Confirm the new pan/filter O-ring/seal is correctly seated on the new assembly.

Step 6: Install the new pan/filter assembly

• Hold the new pan/filter in place and start all bolts by hand.
• Tighten bolts in a crisscross pattern using an 8mm socket and 3/8" ratchet.
• Final tighten using a 3/8" torque wrench (5–60 Nm range): Torque to 8 Nm (71 in-lbs).

Step 7: Reinstall the drain plug

• Install a new drain plug seal, then install the drain plug.
• Use a 3/8" torque wrench (5–60 Nm range) with the correct Torx bit set (T40): Torque to 30 Nm (22 ft-lbs).

Step 8: Initial refill (engine OFF)

• Remove the fill plug using the correct Torx bit set (T40) and 3/8" ratchet.
• Use a fluid transfer pump (specialty) to pump Mopar 8&9 Speed ATF into the fill port until fluid begins to run back out.
• Install the fill plug finger-tight for now.

Step 9: Final level set (engine RUNNING at the correct temperature)

• Start the engine and keep the vehicle level on jack stands.
• Use the OBD2 scan tool with transmission fluid temperature data (specialty) to monitor transmission fluid temperature.
• With your foot on the brake, slowly shift through P-R-N-D, pausing 2–3 seconds in each, then return to P.
• When fluid temperature is in the check range: 30–50°C (86–122°F), remove the fill plug using the correct Torx bit set (T40) and 3/8" ratchet.
• Use the fluid transfer pump (specialty) to add fluid until it flows out as a steady stream, then wait until it becomes a thin drip.
• Reinstall the fill plug and torque it using a 3/8" torque wrench (5–60 Nm range): Torque to 35 Nm (26 ft-lbs).

Step 10: Reinstall the underbody shield

• Reinstall the shield using the Torx bit set (T25–T30), 3/8" ratchet, and any clips using the trim clip removal tool.

---

✅ After Repair

• Start the engine and check for leaks around the pan, drain plug, and fill plug.
• Take a short test drive (10–15 minutes), then recheck for leaks.
• If you notice slipping, delayed engagement, or flare shifts, recheck the fluid level using the same 30–50°C (86–122°F) temperature window.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $180-$420 (parts only)

You Save: $270-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
