🔧 Highlander - Transmission Fluid Drain & Refill

This service replaces a portion of your A/T fluid by draining the pan and refilling to the correct level. On your Highlander, the fluid level must be checked at a specific fluid temperature, so the “level check” step is the most important part.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface; the fluid level check is inaccurate if the vehicle isn’t level.
• ⚠️ Transmission fluid can be hot—wear gloves and safety glasses.
• ⚠️ Always support the vehicle with jack stands; never rely on a floor jack alone.
• ⚠️ Keep engine running only when instructed; stay clear of belts/fans.
• ⚠️ No battery disconnect is required for a drain & refill.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks (pair)
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• 10mm socket
• Ratchet (3/8")
• Trim clip removal tool
• Hex bit socket set (6mm-10mm)
• Torque wrench (3/8" drive, 10-80 ft-lb range)
• Fluid transfer pump (hand pump)
• OBD2 scan tool with live data (specialty)
• Digital thermometer (optional)
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Toyota WS compatible) - Qty: 4 quarts
• Transmission drain plug gasket (crush washer) - Qty: 1
• Transmission overflow plug gasket - Qty: 1
• Transmission fill plug gasket - Qty: 1

---

📋 Before You Begin

• Park your Highlander on level ground and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Plan to do the final level check with the transmission fluid at the correct temperature (your scan tool will help).
• Tip: Do a short drive first. This helps the fluid drain more completely.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front, then support with jack stands (rated 3-ton minimum).
• If you lift the front, also lift the rear so the vehicle sits level on jack stands (rated 3-ton minimum). This matters for the fluid level check.
• Place wheel chocks (pair) at the rear tires.

Step 2: Remove the lower splash shield (if equipped)

• Use a 10mm socket and ratchet (3/8") to remove the bolts.
• Use a trim clip removal tool to pop any plastic clips without breaking them.

Step 3: Identify the transmission fill, drain, and overflow

• Locate the transmission pan area and the fill plug on the side of the transmission case.
• The drain/overflow is typically a “drain plug with an inner overflow plug” at the pan.
• Tip: Always confirm the fill plug loosens first.

Step 4: Loosen the fill plug first

• Place the drain pan (10-quart minimum) underneath in case of drips.
• Use the correctly-fitting bit from your hex bit socket set (6mm-10mm) with a ratchet (3/8") to loosen the fill plug.
• If the fill plug won’t loosen, stop here (you don’t want to drain it and then be unable to refill).

Step 5: Drain the old fluid

• Position the drain pan (10-quart minimum).
• Use the correctly-fitting bit from your hex bit socket set (6mm-10mm) to remove the inner overflow plug first (this is the small inner plug).
• Then remove the outer drain plug (if your setup uses an outer plug) using the correct tool from your ratchet (3/8") and hex bit socket set (6mm-10mm).
• Let the fluid drain until it slows to a drip.

Step 6: Reinstall drain components with new gaskets

• Clean the plug area using shop rags and brake cleaner spray.
• Install a new transmission drain plug gasket (crush washer) on the drain plug.
• Reinstall the drain plug and tighten with a torque wrench (3/8" drive, 10-80 ft-lb range): Torque to 49 Nm (36 ft-lbs).
• Reinstall the overflow plug with a new transmission overflow plug gasket: Torque to 15 Nm (11 ft-lbs).

Step 7: Pump in new transmission fluid

• Insert the hose from the fluid transfer pump (hand pump) into the fill hole.
• Pump in automatic transmission fluid (Toyota WS compatible) until fluid begins to spill back out of the fill hole (initial fill).
• Reinstall the fill plug finger-tight for now (you will reopen it during the level check).

Step 8: Set fluid level at the correct temperature (critical)

• Connect your OBD2 scan tool with live data (specialty) and view transmission fluid temperature (often shown as “ATF Temp”).
• Start the engine and keep your foot on the brake.
• Move the shifter slowly through P-R-N-D, pausing ~3 seconds in each position, then return to P.
• With the engine idling, monitor ATF temperature and perform the level check when ATF is 40-45°C (104-113°F).
• At that temperature, remove the overflow plug using the correct bit from your hex bit socket set (6mm-10mm):
  • If a thin stream/drip comes out, the level is correct.
  • If nothing comes out, add fluid through the fill plug using the fluid transfer pump (hand pump) until it begins to drip from the overflow.
  • If it pours out heavily, let it drain until it becomes a thin stream/drip.
• Reinstall overflow plug: Torque to 15 Nm (11 ft-lbs).

Step 9: Final-tighten the fill plug and reinstall covers

• Remove the fill plug one last time and top off if needed, then reinstall it.
• Tighten the fill plug with a torque wrench (3/8" drive, 10-80 ft-lb range): Torque to 39 Nm (29 ft-lbs).
• Reinstall the splash shield using the 10mm socket, ratchet (3/8"), and trim clip removal tool.

---

✅ After Repair

• Wipe everything clean with shop rags and use brake cleaner spray to remove oily residue.
• Start your Highlander and check for leaks around the fill/drain/overflow plugs.
• Test drive 10-15 minutes, then re-check for leaks when parked.
• If shifting feels odd, re-check the fluid level procedure at the correct temperature.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $45-$95 (parts only)

You Save: $175-$325 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
