🔧 Transaxle Fluid - Fluid Change

On your RAV4 Hybrid, this is a transaxle fluid service, not a conventional automatic transmission service. The fluid is drained and refilled through the transaxle case, then the level is set with an overflow check at the correct temperature.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a cool vehicle. The transaxle and fluid can be hot.
• Keep the hybrid system powered OFF before working underneath the vehicle.
• Do not remove any orange high-voltage cables or covers.
• Use jack stands on solid ground. Never rely on the floor jack alone.
• Level vehicle position is critical for the final fluid level check.
• Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Toyota WS ATF fluid transfer pump
• 10mm socket
• 14mm socket
• 24mm socket
• Torque wrench
• Ratchet
• Drain pan
• Fluid level pump or hand pump
• Funnel
• Floor jack (rated 3-ton minimum)
• Jack stands (rated for vehicle weight)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Scan tool or temperature monitor
• Catch container
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Toyota WS specification) - Qty: 4 quarts
• Drain plug gasket - Qty: 1
• Fill plug gasket - Qty: 1
• Level check plug gasket - Qty: 1

---

📋 Before You Begin

• Park on a level surface and set the parking brake.
• Chock the rear wheels if the front of the vehicle will be raised.
• Drive the vehicle until the transaxle is warm, then shut it OFF.
• If possible, use a scan tool to watch transaxle fluid temperature during the final level check.
• Have the new fluid ready before opening the fill plug.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use the floor jack to raise the vehicle, then support it securely with jack stands.
• Keep the vehicle as level as possible for accurate fluid checking.
• Level matters for fluid level.

Step 2: Remove the underbody cover

• Use a 10mm socket to remove the fasteners holding the lower engine or transaxle splash shield.
• Set the cover and fasteners aside.

Step 3: Loosen the fill plug first

• Use a 24mm socket to loosen the fill plug on the transaxle case.
• Do this before draining the fluid so you know it will refill.

Step 4: Drain the old fluid

• Place the drain pan under the drain plug.
• Use the 24mm socket to remove the drain plug.
• Let the fluid drain completely.
• Install a new drain plug gasket on the drain plug.
• Torque to 40 Nm (30 ft-lbs).

Step 5: Remove the level check plug and overflow tube

• Use a 24mm socket to remove the level check plug.
• If equipped with an overflow tube, use the 24mm socket to remove it as well.
• This lets you set the exact fluid level later.

Step 6: Reinstall the overflow tube and level check plug loosely

• Reinstall the overflow tube and level check plug by hand first.
• Do not fully torque the fill plug yet if you still need to add fluid.

Step 7: Fill with new fluid

• Use the fluid level pump or transfer pump to add Toyota WS fluid through the fill opening.
• Keep adding until fluid begins to flow out of the level check opening.
• This means the transaxle is close to full.

Step 8: Set the final fluid level at temperature

• Use a scan tool or temperature monitor to watch transaxle fluid temperature.
• With the engine and hybrid system in the proper service state, continue until fluid temperature is in the specified check range.
• When fluid just dribbles from the level check opening, the level is correct.
• If it pours out heavily, let it slow to a small stream or drip.
• Small drip is the goal.

Step 9: Tighten the level check plug and fill plug

• Install new gaskets on the plugs if needed.
• Use the 24mm socket and torque wrench to tighten the level check plug.
• Torque to 20 Nm (15 ft-lbs).
• Use the 24mm socket and torque wrench to tighten the fill plug.
• Torque to 39 Nm (29 ft-lbs).

Step 10: Reinstall the splash shield

• Use the 10mm socket to reinstall the underbody cover.
• Make sure all clips and fasteners are secure.

---

✅ After Repair

• Start the vehicle and check for leaks around the drain, fill, and level plugs.
• Road test gently and confirm normal operation.
• Recheck for seepage after the test drive.
• Dispose of used fluid at a proper recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: ₹12,000-₹22,000 (parts + labor)

DIY Cost: ₹3,500-₹7,500 (parts only)

You Save: ₹8,500-₹14,500 by doing it yourself!

Shop labor rates vary but typically run ₹8,000-₹12,000/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
