🔧 Transmission Fluid - Drain and Fill

Assumption: this S60 has the 8-speed Geartronic automatic. A proper service means draining the old fluid, refilling with the correct Volvo-approved ATF, then setting the level at the correct fluid temperature.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a level surface. Transmission level checking is temperature-sensitive.
• ATF can be hot. Let the vehicle cool enough to avoid burns, but not fully cold if you are doing a warm level check.
• Use jack stands. Never rely on a floor jack alone.
• Keep the engine running only when the procedure calls for a level check.
• Do not overfill. Too much fluid can cause foaming and shift problems.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated for vehicle weight)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan
• Fluid transfer pump
• Torque wrench
• Transmission fluid temperature scan tool
• Correct-size socket for transmission drain and fill plugs
• Rags or shop towels
• Funnel with hose

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Volvo-approved automatic transmission fluid meeting JWS 3324 / AW-1 spec - Qty: 5 quarts
• Transmission drain plug sealing washer - Qty: 1
• Transmission fill plug sealing washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Warm the transmission with a short drive so the fluid drains more completely.
• Raise and support the vehicle so it stays level.
• Have the scan tool ready to read transmission fluid temperature.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Warm the transmission

• Drive the vehicle 10-15 minutes so the fluid reaches operating temperature.
• Warm fluid drains more completely.

Step 2: Raise and level the vehicle

• Use the floor jack to lift the vehicle and place it securely on jack stands.
• Make sure the vehicle sits level front-to-rear and side-to-side.

Step 3: Remove the drain plug and drain the fluid

• Place the drain pan under the transmission.
• Use the correct-size socket to remove the transmission drain plug.
• Let the fluid drain fully.
• Inspect the drained fluid for glitter, metal chunks, or a burnt smell.

Step 4: Reinstall the drain plug

• Install a new drain plug sealing washer.
• Use the torque wrench and tighten the drain plug to 35 Nm (26 ft-lbs).

Step 5: Refill with new transmission fluid

• Use the fluid transfer pump or funnel hose to add Volvo-approved ATF through the fill port.
• Add fluid slowly until it begins to run back out of the fill opening.
• Install the fill plug finger-tight for now.

Step 6: Set the fluid level

• Start the engine and keep the vehicle level.
• Use the scan tool to monitor transmission fluid temperature.
• Move the shifter slowly through each gear position, pausing briefly in each one, then return to Park.
• With the fluid at the correct temperature range, remove the fill plug again and top off until a thin stream just begins to dribble out.
• Install a new fill plug sealing washer and tighten the fill plug to 35 Nm (26 ft-lbs).
• A small dribble means the level is right.

Step 7: Check for leaks

• Wipe the area clean with rags.
• Look for leaks at both plugs while the engine is running and after shutdown.

---

✅ After Repair

• Road test the vehicle and check for smooth shifting.
• Recheck for leaks after the test drive.
• If shifts feel abnormal, verify the fluid level again at the correct temperature.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $80-$140 (parts only)

You Save: $170-$310 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
