🔧 Escape - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and front brake rotors on your Escape. New pads and rotors restore smooth braking, reduce vibration, and prevent metal-to-metal brake damage.

Difficulty Level: Beginner to Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack by itself.
• ⚠️ Use jack stands before putting any part of your body near the wheels.
• ⚠️ Brake dust is harmful. Do not blow it off with compressed air.
• ⚠️ Front brake parts can be heavy. Keep fingers clear when removing the caliper and rotor.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with water.
• ⚠️ Battery disconnect is not required for the front brakes on your Escape.
• ⚠️ The electronic parking brake does not need service mode for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 19mm lug nut socket
• 13mm socket
• 18mm socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• 1/2-inch torque wrench
• 3/8-inch torque wrench
• Brake caliper piston compressor tool (specialty)
• Flathead screwdriver
• Small pry bar
• Wire brush
• Brake cleaner spray
• Shop rags
• Brake caliper hanger hook
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake lubricant - Qty: 1
• Brake cleaner spray - Qty: 1-2 cans

---

📋 Before You Begin

• Park your Escape on level ground and shift to Park.
• Set the parking brake before lifting the vehicle.
• Place wheel chocks behind the rear wheels. Wheel chocks are blocks that stop the vehicle from rolling.
• Loosen the front lug nuts slightly before lifting the vehicle.
• Open the hood and check the brake fluid reservoir. If it is completely full, remove a small amount with a clean suction tool before compressing the caliper pistons.
• Do one side at a time so the other side can be used as a reference.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use the 19mm lug nut socket and 1/2-inch breaker bar to loosen each front lug nut about half a turn.
• Do not remove the lug nuts yet.
• Loosen before lifting for safety.

Step 2: Lift and Support the Front of the Vehicle

• Use the floor jack rated 2-ton minimum at the front jacking point to raise the front of your Escape.
• Place jack stands rated 2-ton minimum under the proper front support points.
• Lower the vehicle gently onto the jack stands.
• Lightly shake the vehicle by hand to confirm it is stable.

Step 3: Remove the Front Wheel

• Use the 19mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove the wheel and place it flat under the side of the vehicle as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Put on safety glasses and nitrile gloves.
• Use brake cleaner spray and shop rags to clean loose dust from the caliper area.
• Look at the hose connected to the caliper. Do not stretch, twist, or hang the caliper by this hose.

Step 5: Remove the Caliper Slide Pin Bolts

• The caliper is the clamp-shaped part that squeezes the brake pads against the rotor.
• Use the 13mm socket and 3/8-inch ratchet to remove the two caliper slide pin bolts from the back of the caliper.
• If the slide pin spins, hold the pin with a suitable wrench while loosening the bolt with the 13mm socket.

Step 6: Remove and Support the Caliper

• Use the small pry bar or flathead screwdriver to gently wiggle the caliper off the rotor.
• Hang the caliper from the strut spring using the brake caliper hanger hook.
• Do not let the caliper hang by the brake hose.

Step 7: Remove the Old Brake Pads

• Use the flathead screwdriver to slide the old inner and outer brake pads out of the caliper bracket.
• Note how the pads and clips are positioned before removing them.
• The caliper bracket is the metal frame that holds the brake pads in place.

Step 8: Remove the Caliper Bracket

• Use the 18mm socket and 1/2-inch breaker bar to remove the two caliper bracket bolts from the steering knuckle.
• Remove the caliper bracket and set it on a clean surface.
• These bolts are tight from the factory, so steady pressure works better than quick jerks.

Step 9: Remove the Old Rotor

• Pull the rotor straight off the wheel hub by hand.
• If the rotor is stuck, use the brake cleaner spray around the hub center and tap the rotor hat area with controlled force using the small pry bar only as needed.
• Do not pry against the dust shield or brake hose.
• Rust can make rotors stubborn.

Step 10: Clean the Hub Face

• Use the wire brush to clean rust and debris from the wheel hub face.
• Use brake cleaner spray and shop rags to wipe the hub clean.
• The new rotor must sit flat against the hub to prevent brake vibration.

Step 11: Install the New Rotor

• Clean both sides of the new rotor using brake cleaner spray and shop rags.
• Slide the new rotor onto the hub by hand.
• Thread one lug nut on by hand to hold the rotor flat while you work.

Step 12: Service the Caliper Bracket

• Use the flathead screwdriver to remove the old brake pad hardware clips from the caliper bracket.
• Use the wire brush to clean the clip mounting areas.
• Install the new clips from the front brake hardware kit by hand.
• Apply a thin layer of brake lubricant only where the pad ears slide on the clips.
• Do not put lubricant on the rotor or pad friction surface.

Step 13: Reinstall the Caliper Bracket

• Place the caliper bracket over the rotor.
• Start both bracket bolts by hand to prevent cross-threading.
• Use the 18mm socket and 1/2-inch torque wrench to tighten the caliper bracket bolts.
• Torque to 175 Nm (129 ft-lbs)

Step 14: Install the New Brake Pads

• Slide the new inner and outer brake pads into the caliper bracket by hand.
• Use the flathead screwdriver only if needed to gently guide the pad ears into the clips.
• The friction material faces the rotor.
• Make sure the pads move smoothly in the bracket.

Step 15: Compress the Caliper Piston

• The piston is the round metal piece inside the caliper that pushes the brake pad.
• Use the brake caliper piston compressor tool to slowly push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston. Stop if fluid gets near the top.
• Compress slowly to protect the brake hydraulic system.

Step 16: Reinstall the Caliper

• Remove the caliper from the brake caliper hanger hook.
• Place the caliper over the new pads and rotor.
• Start both slide pin bolts by hand.
• Use the 13mm socket and 3/8-inch torque wrench to tighten the slide pin bolts.
• Torque to 28 Nm (21 ft-lbs)

Step 17: Repeat the Repair on the Other Front Side

• Use the same tools and steps on the opposite front brake.
• Always replace front brake pads and rotors in pairs.

Step 18: Reinstall the Wheels

• Remove the temporary lug nut holding each rotor.
• Install the wheels by hand.
• Start all lug nuts by hand first.
• Use the 19mm lug nut socket and 3/8-inch ratchet to snug the lug nuts in a star pattern.

Step 19: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack rated 2-ton minimum to raise the vehicle slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the vehicle until the tires touch the ground.
• Use the 19mm lug nut socket and 1/2-inch torque wrench to tighten the lug nuts in a star pattern.
• Torque to 135 Nm (100 ft-lbs)

Step 20: Pump the Brake Pedal

• Before driving, sit in the driver seat and press the brake pedal several times.
• The pedal will feel soft at first, then become firm.
• Do not move the vehicle until the brake pedal feels firm.

---

✅ After Repair

• Check the brake fluid level and make sure it is between the MIN and MAX marks.
• Start your Escape and press the brake pedal again to confirm it feels firm.
• Test the brakes at low speed in a safe area before normal driving.
• Listen for scraping, grinding, or clunking noises.
• Perform a gentle brake bedding procedure: make 8-10 medium stops from about 30 mph to 5 mph, letting the brakes cool briefly between stops.
• Avoid hard braking for the first 200 miles unless it is an emergency.
• Recheck lug nut torque after the first short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 (parts + labor)

DIY Cost: $180-$350 (parts only)

You Save: $270-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
