🔧 Engine Oil & Oil Filter - Replacement

Your Camry uses a cartridge-style oil filter and low-viscosity synthetic oil. On a hybrid, the engine can shut off and start automatically, so the car must be fully OFF before you begin and kept out of READY mode during service.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Make sure the vehicle is fully OFF and not in READY mode before opening the hood.
• Keep the key fob away from the vehicle so the hybrid system does not wake up.
• Let the engine and exhaust cool before draining oil.
• Use jack stands if you lift the front of the car; never rely on a jack alone.
• Dispose of used oil and filter properly. Do not pour oil on the ground or into drains.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• Ratchet
• Torque wrench
• 64mm 14-flute oil filter cap wrench (specialty)
• Drain pan
• Funnel
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Gloves
• Safety glasses
• Clean rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-16 full synthetic) - Qty: 5 quarts
• Oil filter element kit - Qty: 1
• Drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Turn the vehicle fully OFF and remove the key fob from the area.
• If the engine is hot, wait until it cools.
• Raise the front only if needed for access, then support it with jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the front

• Use a floor jack to lift the front of the vehicle at the proper lift point.
• Place jack stands under the support points and lower the vehicle onto them.
• Never work under a car supported only by a jack.

Step 2: Remove the under-engine cover

• Use a 14mm socket and ratchet to remove the bolts holding the lower engine cover.
• Set the cover and fasteners aside in order.

Step 3: Drain the engine oil

• Position the drain pan under the oil pan drain plug.
• Use a 14mm socket to loosen and remove the drain plug.
• Let the oil drain completely.
• Install a new drain plug gasket on the plug.
• Reinstall the drain plug and Torque to 39 Nm (29 ft-lbs).

Step 4: Replace the oil filter element

• Move the drain pan under the oil filter housing.
• Use the 64mm 14-flute oil filter cap wrench (specialty) to remove the filter housing cap.
• Pull out the old filter element and remove the old O-rings.
• Install the new O-rings from the kit and lightly coat them with clean engine oil.
• Install the new filter element.
• Reinstall the housing cap and Torque to 25 Nm (18 ft-lbs).

Step 5: Refill with new oil

• Lower the vehicle if needed so it sits level.
• Use a funnel to add 0W-16 full synthetic engine oil through the oil fill cap.
• Start with about 4.5 quarts, then top off carefully after checking the level.
• Reinstall the oil fill cap.

Step 6: Check for leaks and verify level

• Start the vehicle and let it idle briefly.
• Check the drain plug and filter housing for leaks.
• Turn the vehicle off, wait a few minutes, then check the dipstick and add oil as needed.
• Do not overfill.

Step 7: Reinstall the under cover

• Use the 14mm socket to reinstall the lower engine cover.
• Make sure all fasteners are secure.

---

✅ After Repair

• Confirm there are no oil leaks after a short drive.
• Check the oil level again on level ground after the engine sits for a few minutes.
• Reset the maintenance reminder if it is due: Menu > Settings > Vehicle Settings > Scheduled Maintenance or the maintenance menu in the instrument cluster, depending on screen setup.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $55-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
