🔧 Engine Oil and Oil Filter - Replacement

Your Tiguan uses a cartridge-style oil filter and a drain plug service. This job is straightforward if you take your time, keep the engine warm-not-hot, and follow the torque specs closely so you do not crack the filter housing or strip the drain plug.

Difficulty Level: Beginner | Estimated Time: 1-1.5 hours

---

⚠️ Safety & Precautions

• Work on a level surface and support the vehicle with jack stands. Never rely on a jack alone.
• Engine oil can be very hot. Let the engine cool slightly before draining.
• Use eye protection and gloves. Used oil is messy and can burn skin.
• Keep the ignition off and key away from the vehicle while you work underneath.
• No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• 19mm socket
• 3/8-inch ratchet
• Oil filter cap wrench, 74mm 14-flute (specialty)
• Torque wrench
• Oil drain pan
• Funnel
• Shop towels
• Flat-blade trim tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil meeting VW 502 00 specification, 5W-40 full synthetic - Qty: 6 quarts
• Oil filter cartridge kit - Qty: 1
• Drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Run the engine for 2-3 minutes so the oil flows easier, then shut it off.
• Let it sit briefly so the oil is warm, not scalding.
• Open the hood and remove the oil filler cap to help draining.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the vehicle

• Use the floor jack to lift the front of the Tiguan at the approved lift point.
• Place the vehicle on jack stands and confirm it is stable before going underneath.
• Set wheel chocks behind the rear wheels.

Step 2: Remove the lower engine cover

• Use the flat-blade trim tool to release the fasteners or clips for the lower splash shield.
• Lower the cover and set it aside.

Step 3: Drain the engine oil

• Position the oil drain pan under the drain plug.
• Use the 19mm socket and 3/8-inch ratchet to remove the drain plug.
• Let the oil drain completely.
• Install a new drain plug crush washer on the plug.
• Reinstall the drain plug and Torque to 30 Nm (22 ft-lbs).

Step 4: Replace the oil filter

• Move the drain pan under the filter housing.
• Use the oil filter cap wrench, 74mm 14-flute to loosen the filter housing cap.
• Remove the old cartridge filter from the cap.
• Replace the O-rings from the new filter kit onto the cap.
• Install the new cartridge filter.
• Thread the cap back in by hand, then Torque to 25 Nm (18 ft-lbs).

Step 5: Refill with new oil

• Lower the vehicle to level ground.
• Use the funnel to add about 5.5 quarts of new engine oil.
• Reinstall the oil filler cap.
• Start the engine and let it idle for 30 seconds.
• Shut the engine off and wait 5 minutes for oil to settle.

Step 6: Check the oil level and inspect for leaks

• Use the dipstick, if equipped, or the dash oil level display if fitted on your Tiguan.
• Add oil in small amounts until the level is correct.
• Inspect the drain plug and filter housing for leaks.
• Do not overfill.

Step 7: Reinstall the lower cover

• Use the flat-blade trim tool to reinstall the splash shield fasteners.
• Make sure the cover is seated properly before lowering the vehicle fully.

---

✅ After Repair

• Start the engine again and watch for any oil leaks.
• Check the oil level one more time after a short drive.
• Reset the service reminder in the instrument cluster or infotainment if your Tiguan displays one.
• Dispose of used oil and filter at a recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $45-$85 (parts only)

You Save: $75-$135 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
