🔧 Engine Oil & Filter - Oil Change

This service replaces the old engine oil and the oil filter so fresh oil can protect the turbocharged engine properly. On your GTI, the oil filter is a cartridge-style filter in a housing on top of the engine, so the job is clean and straightforward.

Difficulty Level: Beginner | Estimated Time: 1-1.5 hours

---

⚠️ Safety & Precautions

• Work on a level surface and set the parking brake.
• Let the engine cool down before draining oil. Hot oil can burn you.
• Use jack stands if you lift the car. Never rely on a jack alone.
• Keep dirt out of the oil filter housing. Cleanliness matters on this engine.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 32mm oil filter socket
• Ratchet
• 3/8-inch drive torque wrench
• Drain pan
• Funnel
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Torx T25 screwdriver
• 10mm socket
• Oil filter cap pick
• Clean shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (VW 502 00 approved full synthetic 5W-40) - Qty: 6 quarts
• Oil filter cartridge - Qty: 1
• Oil filter cap O-ring - Qty: 1
• Drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool for a safer drain.
• Have the new filter, O-ring, and drain washer ready.
• Tip: Warm oil drains faster, but it should not be hot.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front of the car

• Use the floor jack to lift the front of the GTI at the proper jacking point.
• Place jack stands under the car and lower it onto them.
• Use wheel chocks at the rear wheels.

Step 2: Remove the lower engine cover

• Use the Torx T25 screwdriver to remove the lower splash shield fasteners.
• Lower the cover and set it aside.

Step 3: Drain the old engine oil

• Place the drain pan under the oil pan drain plug.
• Use the 10mm socket to loosen the drain plug.
• Remove the plug by hand and let the oil drain fully.
• Install a new drain plug crush washer.
• Reinstall the drain plug and Torque to 30 Nm (22 ft-lbs).

Step 4: Replace the oil filter cartridge

• Move the drain pan under the oil filter housing.
• Use the 32mm oil filter socket to remove the filter cap.
• Pull the old filter cartridge off the cap. The cartridge is the replaceable filter element inside the housing.
• Remove and replace the old oil filter cap O-ring.
• Lightly oil the new O-ring with clean engine oil.
• Install the new filter cartridge and reinstall the cap.
• Torque to 25 Nm (18 ft-lbs).

Step 5: Reinstall the lower engine cover

• Put the splash shield back in place.
• Use the Torx T25 screwdriver to reinstall all fasteners.

Step 6: Add fresh engine oil

• Lower the car to level ground.
• Remove the oil filler cap on top of the engine.
• Use the funnel to add about 5.5 quarts first.
• Install the cap and start the engine for 30 seconds.
• Shut the engine off and wait 5 minutes.
• Check the oil level and top off to the full mark as needed.
• Total capacity is about 5.7 quarts with filter.

Step 7: Check for leaks

• Look under the car for oil leaks at the drain plug and filter housing.
• If dry, wipe away any spilled oil from the engine and undertray.

---

✅ After Repair

• Check the oil level again after the first drive and top off if needed.
• Reset the service reminder if your GTI shows one in the cluster or infotainment.
• Dispose of used oil and the old filter at a proper recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $75-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
