🔧 Equinox - Automatic Transmission Fluid Change

You’ll be doing a drain-and-fill on the automatic transmission in your Equinox. This replaces a good portion of the old fluid and restores shifting performance and protection.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Always support the vehicle on jack stands (sturdy metal supports that hold the car up safely). Never work under a car supported only by a jack.
• ⚠️ Transmission fluid and the exhaust can get very hot. Let the engine and exhaust cool before working near them.
• ⚠️ Keep the car on perfectly level ground when checking the fluid level. An uneven surface will give you a wrong level.
• ⚠️ Wear gloves and safety glasses to protect your skin and eyes from hot fluid.
• ⚠️ Set the parking brake firmly and chock the rear wheels so the car cannot roll.
• ⚠️ Do not start or move the car with the level plug removed or fluid low; you can damage the transmission.
• Battery disconnection is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (set of 4)
• 🛠️ Wheel chocks
• 🛠️ Socket set (8mm–19mm metric)
• 🛠️ Ratchet handle (3/8" drive)
• 🛠️ Torque wrench (3/8" drive, 5–80 ft-lbs range) (torque wrench = tool that lets you tighten bolts to a specific force)
• 🛠️ Allen/hex bit sockets (8mm–12mm metric) (hex bit = socket with a hex-shaped tip)
• 🛠️ Flathead screwdriver (medium)
• 🛠️ Drain pan (at least 10-liter capacity)
• 🛠️ Transmission fluid fill pump (hand pump, screws on fluid bottle)
• 🛠️ Clean plastic funnel (small)
• 🛠️ Shop rags or paper towels
• 🛠️ Infrared thermometer (non-contact thermometer for checking surface temperature)
• 🛠️ OBD2 scan tool with live data (specialty) (scan tool = device that reads vehicle data and temperatures)
• 🛠️ Latex or nitrile gloves
• 🛠️ Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 DEXRON-VI automatic transmission fluid - Qty: 6-7 quarts (drain-and-fill, not full dry fill)
• 🔩 Transmission drain plug seal/washer - Qty: 1
• 🔩 Transmission level plug seal/washer - Qty: 1
• 🔩 Brake cleaner spray - Qty: 1 can
• 🔩 Disposable shop towels - Qty: 1 pack

---

📋 Before You Begin

• Park your Equinox on level ground where you have room at the front and sides.
• Shift to P (Park), set the parking brake, and place wheel chocks behind the rear tires.
• Gather all tools and parts so you’re not crawling in and out looking for things.
• Plan to work when the transmission is warm but not hot. You will warm it up again later to check the level.
• If you have a scan tool, make sure it can read transmission fluid temperature.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Safely raise and support the car

• Use the floor jack to lift the front of your Equinox at the front jacking point (behind the front subframe area, center point).
• Place jack stands under the left and right front pinch welds or frame points and slowly lower the car onto them using the floor jack.
• If possible, also raise the rear and support it on jack stands so the car is level front-to-back.
• Give the car a firm shake to confirm it is stable.

Step 2: Remove the lower engine splash shield

• Slide the drain pan under the front area for later, but keep it to the side for now.
• Use the appropriate socket from the socket set (usually 7mm or 10mm) with a ratchet to remove the screws holding the plastic splash shield under the engine/transmission.
• Use a flathead screwdriver to gently pry out any plastic clips if present.
• Drop the shield down and set it aside.

Step 3: Locate the transmission drain and level plugs

• The automatic transmission is on the driver’s side of the engine bay, towards the front.
• From underneath, look for the drain plug on the bottom of the transmission case (usually a hex or standard bolt head).
• On the transmission side (facing the front or slightly to the side), locate the fluid level plug (a smaller plug higher up the case).
• Take a photo so you remember which is which.

Step 4: Loosen the level plug first

• Position the drain pan under the transmission level plug area in case some fluid drips.
• Use the correct size socket or hex bit socket with ratchet on the level plug and carefully crack it loose but do not remove it fully yet.
• This confirms you can refill and the level plug is not seized.

Step 5: Drain the old transmission fluid

• Move the drain pan directly under the transmission drain plug.
• Use the correct size socket or hex bit socket with ratchet to remove the drain plug completely.
• Let the fluid flow into the pan. It may come out quickly at first.
• Allow it to drain until it is just slowly dripping. This can take 10–15 minutes.
• While it drains, inspect the fluid color. Dark brown or burnt smell means it needed this change.

Step 6: Reinstall the drain plug

• Clean the drain plug with shop rags and inspect the washer/seal.
• Install a new drain plug seal/washer if your plug uses one.
• Reinstall the drain plug by hand first to avoid cross-threading.
• Use the correct size socket with torque wrench to tighten the drain plug to 38 Nm (28 ft-lbs).
• Wipe the area clean with a rag and a bit of brake cleaner.

Step 7: Remove the fill/level plug fully

• Place the drain pan under the level plug area again.
• Use the correct size socket or hex bit socket with ratchet to remove the level plug completely.
• Some fluid may drip; that is normal.
• Install a new level plug seal/washer on the plug and set it aside for now.

Step 8: Fill new transmission fluid

• On this transmission, you usually fill through the level/fill plug opening you just removed.
• Attach the transmission fluid fill pump to a bottle of DEXRON-VI automatic transmission fluid.
• Insert the pump hose into the level/fill hole.
• Pump in about 4 quarts of new fluid to start.
• Keep count of how many quarts you pump in.

Step 9: Pre-tighten the level plug for warm-level check

• Once you have pumped in about as much fluid as drained out (typically 4–5 quarts), remove the pump hose.
• Install the level plug by hand, then snug it gently using the correct size socket or hex bit socket with ratchet. Do not torque it fully yet; you will open it again.
• Clean off any spilled fluid with brake cleaner and a rag.

Step 10: Warm up the transmission

• Carefully lower the car just enough so you can safely start it, or leave it on stands if your work area is safe and ventilated.
• Start the engine, keep your foot on the brake, and move the shifter slowly through all gears: P → R → N → D → L, pausing 3 seconds in each, then back to P.
• This circulates the new fluid through the transmission and valve body.
• Use your scan tool to monitor transmission fluid temperature. You want it around 40–50°C (104–122°F).
• If you don’t have a scan tool, you can use an infrared thermometer to read the temperature of the transmission pan and case, aiming for the same range.

Step 11: Check the fluid level at the correct temperature

• With the engine running, transmission in P, and the car level on jack stands, slide under the car again.
• Place the drain pan under the level plug.
• Carefully remove the level plug using the correct size socket or hex bit socket with ratchet.
• At about 40–50°C, a correct level will cause fluid to just trickle from the level hole in a thin stream.
• If no fluid comes out, use the fill pump to add small amounts of fluid (about 200 ml at a time) until it starts to trickle out steadily.
• If a strong stream gushes out, let it drain until it reduces to a small trickle.

Step 12: Tighten the level plug

• Once the fluid is at the correct trickle, reinstall the level plug with its new washer/seal.
• Use the correct size socket or hex bit socket with torque wrench to tighten the level plug to 9 Nm (80 in-lbs). This is gently snug, not very tight.
• Wipe the area clean with a rag and brake cleaner.

Step 13: Final checks and reassembly

• Turn the engine off.
• Inspect both the drain plug and level plug areas for any signs of leaks.
• Reinstall the lower splash shield using the correct size socket with ratchet and any clips or screws you removed.
• Carefully raise the car slightly with the floor jack, remove the jack stands, and lower the car to the ground.

---

✅ After Repair

• Start the engine and move the shifter through all gears again, pausing briefly in each position.
• Take a short, gentle drive (5–10 km) staying near home. Pay attention to how the transmission shifts—shifts should feel smooth, with no slipping or harsh bangs.
• Park on level ground, leave the engine running, and look under the car for any signs of fluid leaks from the transmission area.
• Dispose of the old transmission fluid properly at a recycling center or shop that accepts used oil/ATF.
• After a few days of driving, recheck under the car for any new leaks.

---
