🔧 Gladiator - Manual Transmission Fluid Change

On your Gladiator’s 6-speed manual, the fluid is drained from a bottom plug and refilled through a side fill plug until it reaches the correct level. Doing this on schedule helps smooth shifting and protects the gears and synchronizers.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the truck on jack stands; never rely on a jack alone.
• ⚠️ Work on a level surface so the fluid level is correct.
• ⚠️ Let the drivetrain cool; hot gear oil can burn you.
• ⚠️ Wear safety glasses; fluid can splash when plugs loosen.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 6-quart)
• Fluid transfer pump (specialty)
• Metric socket set (8mm–18mm)
• Ratchet (3/8" drive)
• Torque wrench (10–100 ft-lbs range)
• Hex bit socket set (6mm–14mm)
• Trim clip tool
• Shop rags
• Brake cleaner

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid (Mopar spec MS-9224 75W-85) - Qty: 3 quarts
• Drain/fill plug seal washers (if equipped) - Qty: 2

---

📋 Before You Begin

• Park on level ground, leave the shifter in neutral, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Raise and support the truck with a floor jack and jack stands so it sits level.
• Two quick questions so I can give exact plug tool size + torque specs:
  • Are you changing the manual transmission fluid, or did you mean the transfer case fluid?
  • Can you upload a clear photo of the transmission’s fill and drain plugs (driver side of transmission case + bottom area)?
• Tip: Always loosen the fill plug first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the transmission plugs

• Slide under the driver side and locate the manual transmission case.
• If a skid plate blocks access, remove it using a metric socket set (8mm–18mm) and ratchet (3/8" drive).
• Place a drain pan (at least 6-quart) under the drain plug area.

Step 2: Loosen the fill plug first

• Use the correct hex bit socket set (6mm–14mm) or metric socket set (8mm–18mm) with a ratchet (3/8" drive) to crack the fill plug loose (do not remove it yet).
• If it won’t move, stop and don’t drain anything yet.

Step 3: Drain the old fluid

• Remove the drain plug using the same fitting with a ratchet (3/8" drive).
• Let it drain fully into the drain pan (at least 6-quart).
• Clean the plug and magnet (if magnetic) with shop rags and brake cleaner.

Step 4: Reinstall drain plug

• Install the drain plug by hand first to avoid cross-threading.
• Tighten using a torque wrench (10–100 ft-lbs range) to the correct factory spec once you share the plug photo (I’ll give you the exact number for your case).

Step 5: Refill the transmission

• Remove the fill plug fully using the correct bit/socket and ratchet (3/8" drive).
• Add manual transmission fluid (Mopar spec MS-9224 75W-85) using a fluid transfer pump (specialty).
• Stop when fluid just begins to seep out of the fill hole (that’s the correct level when the truck is level).

Step 6: Reinstall fill plug and clean up

• Install the fill plug by hand first.
• Tighten using a torque wrench (10–100 ft-lbs range) to the correct factory spec once you share the plug photo (I’ll provide the exact torque).
• Spray any spilled fluid with brake cleaner and wipe with shop rags.

---

✅ After Repair

• Start the engine and, with the clutch depressed, shift through all gears while parked.
• Take a short drive and check for leaks around the fill and drain plugs.
• Recheck underneath after 10–15 minutes of driving for any fresh seepage.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $45-$110 (parts only)

You Save: $135-$240 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
