🔧 Renegade - Manual Transmission Fluid Change

On your Renegade (manual), changing the gearbox oil means draining the old fluid from the transmission case and refilling through the fill/level plug until it reaches the correct level. The exact fluid spec, fill amount, and torque specs depend on which manual gearbox your Renegade has.

Before I give the exact spec/torques, answer these 2 quick questions:

• ❓ Is it a 6-speed manual (most 2.4L manuals are) or a different manual (5-speed)?
• ❓ Do you want only the manual transmission fluid, or also the AWD fluids (power transfer unit and rear differential)?

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface; the vehicle must sit level to set the correct fluid level.
• ⚠️ Support with jack stands at factory lift points; never rely on a floor jack alone.
• ⚠️ Let the drivetrain cool; hot gear oil can burn skin.
• ⚠️ Wear gloves and eye protection; gear oil has a strong odor and can irritate skin.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (6-quart minimum)
• Trim clip removal tool
• Ratchet (3/8" drive)
• Socket set (metric, 8mm-18mm)
• Hex bit socket set (metric, 6mm-12mm)
• Torque wrench (10-100 ft-lbs)
• Fluid transfer pump (hand pump) (specialty)
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid (OEM-spec for your gearbox) - Qty: 3 quarts
• Fill/drain plug sealing washers (if equipped) - Qty: 2

---

📋 Before You Begin

• Park on level ground, leave the transmission in 1st gear, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• If your Renegade has a lower splash shield/skid plate, plan to remove it (usually small bolts and/or plastic clips).
• Important: Always loosen the fill plug first. If it’s stuck and you drain first, you can’t refill.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front at the center jacking point.
• Set the front down onto jack stands (rated 3-ton minimum) at the factory lift points.
• If needed to keep the vehicle level, raise the rear and support it with jack stands (rated 3-ton minimum) as well.

Step 2: Remove the lower shield (if equipped)

• Use a socket set (metric, 8mm-18mm) and trim clip removal tool to remove the bolts/clips.
• Set the shield aside so you can access the transmission case.

Step 3: Locate and loosen the fill plug first

• Find the transmission fill/level plug on the side of the manual transmission case (it’s usually about halfway up the case).
• Place a drain pan (6-quart minimum) under the area (a little fluid can drip when opened).
• Use a hex bit socket set (metric, 6mm-12mm) with a ratchet (3/8" drive) to loosen and remove the fill plug.
• Tip: Clean the plug area first. Use brake cleaner spray and shop rags.

Step 4: Drain the old transmission fluid

• Move the drain pan (6-quart minimum) under the transmission drain plug (lowest plug on the case).
• Use the correct size from your hex bit socket set (metric, 6mm-12mm) to remove the drain plug.
• Let it drain until it slows to an occasional drip.

Step 5: Reinstall the drain plug

• Clean the drain plug and magnet (if it has one) using shop rags and brake cleaner spray.
• Reinstall the drain plug by hand first (to avoid cross-threading), then tighten with a torque wrench (10-100 ft-lbs).
• Torque: I’ll provide the exact Torque to XX Nm (YY ft-lbs) once you confirm 5-speed vs 6-speed.

Step 6: Refill the transmission to the correct level

• Insert the hose from a fluid transfer pump (hand pump) (specialty) into the fill hole.
• Pump in the correct manual transmission fluid (OEM-spec) until fluid just starts to dribble back out of the fill hole (this is the “level”).
• Wait 1-2 minutes, then top off again until it dribbles.

Step 7: Reinstall the fill plug

• Reinstall the fill plug by hand first, then tighten with a torque wrench (10-100 ft-lbs).
• Torque: I’ll provide the exact Torque to XX Nm (YY ft-lbs) once you confirm 5-speed vs 6-speed.
• Clean any spilled oil using shop rags and brake cleaner spray.

Step 8: Reinstall the shield and lower the vehicle

• Reinstall the shield using your socket set (metric, 8mm-18mm) and trim clip removal tool.
• Raise slightly with the floor jack (rated 3-ton minimum), remove jack stands (rated 3-ton minimum), then lower fully.

---

✅ After Repair

• Start the engine, press the clutch, and shift through all gears with the vehicle stationary.
• Take a short test drive and listen for abnormal whining/grinding.
• Park, then check underneath for leaks around the fill and drain plugs.
• Dispose of used gear oil at a recycling center or parts store that accepts oil.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $35-$90 (parts only)

You Save: $145-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
