🔧 Soul - Manual Transmission Fluid Change

This service drains the old manual transmission fluid and refills it with the correct Kia-specified gear oil. Fresh fluid helps smooth shifting and protects the bearings and synchronizers (the parts that match gear speeds during shifts).

Difficulty Level: Intermediate | Estimated Time: 1.0-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the Soul on jack stands on a level surface; never rely on a jack alone.
• ⚠️ Transmission fluid can be hot; let the drivetrain cool before removing plugs.
• ⚠️ Keep the car level while draining/filling or the fluid level will be wrong.
• ⚠️ No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 6-quart)
• Ratchet
• 24mm socket
• 17mm hex bit socket
• Torque wrench (10–100 Nm range)
• Trim clip tool
• Phillips screwdriver
• Fluid transfer pump (specialty)
• Funnel with hose
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid (API GL-4 75W-85) - Qty: 2 quarts
• Drain plug crush washer - Qty: 1
• Fill plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and place wheel chocks behind the rear wheels.
• Do a short 5–10 minute drive to slightly warm the fluid, then shut the engine off.
• Raise the front of the Soul with a floor jack and support it securely on jack stands.
• Pro tip: Always loosen the fill plug first.
• Assumption: This procedure is for the Soul’s factory manual transmission; plug head style may be 24mm hex or 17mm internal hex.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Use a Phillips screwdriver and trim clip tool to remove the screws/clips and lower the shield.
• Set hardware aside so nothing gets lost.

Step 2: Locate the fill and drain plugs

• Find the fill plug on the side of the transmission case (usually higher up) and the drain plug near the bottom.
• Clean around both plugs using shop rags and brake cleaner spray so dirt can’t fall inside.
• A crush washer is a soft metal ring that seals when tightened; plan to replace it.

Step 3: Loosen the fill plug first

• Place the drain pan under the transmission (some fluid may drip).
• Use either a 24mm socket or 17mm hex bit socket with a ratchet to loosen and remove the fill plug.
• If it won’t loosen, stop and do not drain yet—you must be able to refill before you drain.

Step 4: Drain the old fluid

• Move the drain pan directly under the drain plug.
• Use either a 24mm socket or 17mm hex bit socket with a ratchet to remove the drain plug.
• Let it drain until it slows to an occasional drip (usually 5–10 minutes).
• Wipe the drain plug clean with shop rags. If the plug is magnetic, a gray “paste” is normal; chunks are not.

Step 5: Reinstall the drain plug with a new crush washer

• Install a new drain plug crush washer on the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use a torque wrench with the correct socket/bit and Torque to 39–49 Nm (29–36 ft-lbs).

Step 6: Fill the transmission with the correct fluid

• Install a fluid transfer pump (specialty) onto the GL-4 75W-85 bottle, or use a funnel with hose if access allows.
• Pump fluid into the fill hole until fluid just begins to dribble back out of the fill opening (this is the correct level when the car is level).
• Pro tip: Fill slowly near the end.

Step 7: Reinstall the fill plug with a new crush washer

• Install a new fill plug crush washer on the fill plug.
• Thread the fill plug in by hand first.
• Use a torque wrench and Torque to 39–49 Nm (29–36 ft-lbs).
• Wipe the case clean with shop rags and a light spray of brake cleaner spray to make leak-checking easy.

Step 8: Reinstall the splash shield and lower the car

• Reinstall the shield using the Phillips screwdriver and trim clip tool.
• Raise slightly with the floor jack, remove the jack stands, and lower the car.

---

✅ After Repair

• Start the engine and, with the clutch pressed, shift through all gears while parked (don’t force it).
• Take a short test drive and confirm smooth shifting and no abnormal noises.
• Park and look underneath for seepage at the fill/drain plugs.
• Dispose of used fluid properly (most auto parts stores accept waste oil/fluids).

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $35-$80 (parts only)

You Save: $100-$240 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
