🔧 Focus - Manual Transmission Fluid Change

This service drains the old gear oil from your manual transmission and refills it with fresh fluid. Fresh fluid helps protect gears and bearings and can improve shifting feel, especially in cold weather.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• 🛑 Work on a level surface and support the car with jack stands—never rely on a jack alone.
• 🧤 Wear gloves and safety glasses; gear oil has a strong odor and can irritate skin.
• 🔥 Let the drivetrain cool before starting; the transmission case and exhaust can be hot.
• 🔧 Always loosen the fill plug first—if you drain it and can’t refill it, you’re stuck.
• 🔋 Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• 8mm hex bit socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-100 Nm range)
• Drain pan (at least 6-quart)
• Fluid transfer pump (hand pump)
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid (75W-90, Ford spec WSS-M2C200-C) - Qty: 2 quarts
• Drain/fill plug sealing washers - Qty: 2

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• ⬆️ Raise the front of the car with a floor jack and set it securely on jack stands.
• 📏 Keep the car level while filling (level is important because you fill to the correct height at the fill hole).
• 🧼 Wipe dirt off the fill and drain plug areas with a rag and brake cleaner so debris doesn’t fall inside.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the fill plug and drain plug

• Use a flashlight to find the fill plug on the side/front of the transmission case (it’s higher up).
• Find the drain plug at the lowest point of the transmission case (it points downward).
• Both plugs are typically an internal-hex style—use an 8mm hex bit socket.

Step 2: Remove the fill plug first

• Place the drain pan under the transmission (a little fluid may seep out).
• Use a 3/8" drive ratchet with an 8mm hex bit socket to loosen and remove the fill plug.
• Fill plug first prevents getting stranded.

Step 3: Drain the old fluid

• Position the drain pan directly under the drain plug.
• Use a 3/8" drive ratchet with an 8mm hex bit socket to remove the drain plug.
• Let it drain until it slows to an occasional drip (usually 5-10 minutes).

Step 4: Reinstall the drain plug

• Clean the drain plug and the sealing surface using shop rags and brake cleaner spray.
• Install a new drain plug sealing washer (a sealing washer is a soft ring that helps prevent leaks).
• Thread the drain plug in by hand first to avoid cross-threading.
• Use a torque wrench with an 8mm hex bit socket and Torque to 35 Nm (26 ft-lbs).

Step 5: Fill the transmission

• Put the fluid bottle into a fluid transfer pump (hand pump) (this tool pumps fluid through a hose into the fill hole).
• Pump in manual transmission fluid (75W-90, Ford spec WSS-M2C200-C) through the fill hole.
• Stop when fluid just begins to run back out of the fill hole in a steady dribble (that’s the correct level).
• Slow down near full to avoid a mess.

Step 6: Reinstall the fill plug

• Install a new fill plug sealing washer.
• Thread the fill plug in by hand first.
• Use a torque wrench with an 8mm hex bit socket and Torque to 35 Nm (26 ft-lbs).
• Clean the area with shop rags and brake cleaner spray so you can easily spot leaks later.

Step 7: Lower the car

• Use the floor jack to lift slightly, remove the jack stands, then lower the car.
• Remove the wheel chocks.

---

✅ After Repair

• 🧪 Start the engine and, with the clutch pressed, shift through all gears while parked (don’t force it).
• 🚗 Take a short 10-minute test drive and check for any new noises or hard shifting.
• 🔎 Park on a clean spot and look underneath for drips around the fill and drain plugs.
• 🧴 Dispose of used gear oil properly (most auto parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $150-$300 (parts + labor)

DIY Cost: $35-$80 (parts only)

You Save: $115-$220 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
