🔧 Transmission Fluid - Manual Fluid Change

On your Corolla, this is a manual transmission fluid service. The old gear oil is drained from the transaxle and refilled through the fill plug until the fluid reaches the correct level. Fresh fluid helps protect the gears, synchronizers, and bearings.

Difficulty Level: Beginner | Estimated Time: 1-1.5 hours

---

⚠️ Safety & Precautions

• Work on a level surface so the fluid level is set correctly.
• Let the transmission cool before starting; the fluid can be hot.
• Use jack stands, not just a floor jack. A floor jack is for lifting only.
• Wear safety glasses and gloves. Gear oil has a strong smell and can irritate skin.
• Do not confuse the manual transmission with an automatic transmission. This service uses manual gear oil, not ATF.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• 24mm socket
• Ratchet
• Torque wrench
• Fluid transfer pump
• Drain pan
• Shop towels
• Safety glasses
• Nitrile gloves
• Funnel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid, 75W-90 GL-4 - Qty: 3 quarts
• Drain plug gasket washer - Qty: 1
• Fill plug gasket washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Put the shifter in neutral.
• Chock the rear wheels.
• Raise the front of the car and support it with jack stands.
• Remove the fill plug first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the vehicle

• Use the floor jack (rated 3-ton minimum) to lift the front of the car.
• Set the car securely on jack stands.
• Keep the rear wheels blocked with wheel chocks.

Step 2: Remove the fill plug

• Use a 24mm socket and ratchet to loosen and remove the fill plug first.
• This confirms you can refill the transmission before draining it.
• Always open the fill plug first.

Step 3: Drain the old fluid

• Position the drain pan under the drain plug.
• Use the 24mm socket and ratchet to remove the drain plug.
• Let the fluid drain completely.
• Clean the drain plug and install a new drain plug gasket washer.

Step 4: Reinstall the drain plug

• Thread the drain plug in by hand first to avoid cross-threading.
• Use the torque wrench and 24mm socket to tighten the drain plug to 39 Nm (29 ft-lbs).

Step 5: Fill the transmission

• Use a fluid transfer pump and funnel to pump in fresh manual transmission fluid, 75W-90 GL-4 through the fill opening.
• Keep filling until fluid just begins to dribble back out of the fill hole.
• This is the correct level for this service.
• Install a new fill plug gasket washer.

Step 6: Reinstall the fill plug

• Thread the fill plug in by hand first.
• Use the torque wrench and 24mm socket to tighten the fill plug to 39 Nm (29 ft-lbs).

Step 7: Clean up and lower the car

• Wipe away any spilled fluid with shop towels.
• Lower the car carefully off the jack stands.
• Remove the wheel chocks.

---

✅ After Repair

• Start the car and let it idle.
• Shift through all gears with the clutch pedal fully pressed.
• Check underneath for leaks at both plugs.
• Take a short test drive and confirm smooth shifting.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $45-$85 (parts only)

You Save: $75-$135 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
