🔧 Corolla - Manual Transmission Fluid Drain & Fill

This job replaces the old gear oil inside your Corolla’s manual transmission with fresh fluid. Fresh fluid helps smooth shifting and reduces wear inside the gearbox.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• 🛑 Support the car on jack stands before going underneath.
• 🔥 Transmission fluid can be hot—let the car cool 30+ minutes.
• 🧯 Work on level ground so the fill level is accurate.
• 🔋 Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 6-quart)
• 24mm socket
• 3/8" drive ratchet
• Torque wrench (10-100 ft-lbs range)
• Fluid transfer pump (hand pump) (specialty)
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission gear oil (Toyota LV 75W) - Qty: 2 quarts
• Transmission drain plug crush washer - Qty: 1
• Transmission fill plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on a level surface and set the parking brake.
• Place wheel chocks behind the rear tires.
• Raise the front using a floor jack and support with jack stands.
• Keep the car level for correct fill.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the fill and drain plugs

• Slide a drain pan under the transmission.
• Find the fill plug on the side of the transmission case (faces the front of the car), and the drain plug at the bottom.
• Clean around both plugs using brake cleaner spray and shop rags.

Step 2: Loosen the fill plug first

• Use a 24mm socket with a 3/8" drive ratchet to loosen (but do not remove yet) the fill plug.
• This prevents getting stuck with an empty transmission you can’t refill.

Step 3: Drain the old fluid

• Use the 24mm socket and 3/8" drive ratchet to remove the drain plug.
• Let the fluid drain completely into the drain pan (usually 5-10 minutes).
• Wipe the drain plug clean using shop rags.

Step 4: Reinstall the drain plug with a new crush washer

• Install a new transmission drain plug crush washer on the drain plug.
• Thread the drain plug in by hand to avoid cross-threading.
• Use a torque wrench with a 24mm socket and Torque to 39 Nm (29 ft-lbs).

Step 5: Fill the transmission with new fluid

• Remove the fill plug using a 24mm socket and 3/8" drive ratchet.
• Install the hose from the fluid transfer pump (hand pump) (specialty) into the fill hole. (A fluid transfer pump is a hand-operated pump that pushes fluid from the bottle into tight spaces.)
• Pump in manual transmission gear oil (Toyota LV 75W) until fluid just starts to seep/dribble out of the fill hole.
• That dribble means the level is correct.

Step 6: Reinstall the fill plug with a new crush washer

• Install a new transmission fill plug crush washer on the fill plug.
• Thread the fill plug in by hand.
• Use a torque wrench with a 24mm socket and Torque to 39 Nm (29 ft-lbs).
• Clean any spilled fluid using brake cleaner spray and shop rags.

---

✅ After Repair

• 🧪 Start the engine and, with the clutch pressed, shift through all gears (engine idling) to confirm smooth engagement.
• 🚗 Take a short 5-10 minute test drive and recheck for seepage around the fill and drain plugs.
• 🧼 Dispose of used gear oil at a recycling center or parts store that accepts fluids.

---

💰 DIY vs Shop Cost

Shop Cost: $150-$300 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $80-$265 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
