🔧 Colorado - Engine Oil & Oil Filter Replacement

You’ll drain the old oil, replace the oil filter, and refill with the correct oil. Fresh oil protects your Colorado’s engine from wear and helps it run cooler and cleaner.

Difficulty Level: Beginner | Estimated Time: 0.75-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and chock the rear wheels.
• ⚠️ Let the engine cool 10–15 minutes; oil can burn skin.
• ⚠️ Always support the truck with jack stands; never rely on a jack.
• ⚠️ Keep oil off belts, exhaust, and oxygen sensors.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (7-quart minimum)
• Funnel
• Shop rags
• Ratchet
• Extension (3-inch)
• 15mm socket
• 10mm socket
• Flathead screwdriver
• Oil filter wrench (band or cap style)
• Torque wrench (10–100 ft-lbs range)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 5W-30 full synthetic, dexos1) - Qty: 6 quarts
• Engine oil filter (2.5L-specific) - Qty: 1
• Oil drain plug gasket/washer - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on a level surface and set the parking brake.
• 🧱 Place wheel chocks behind the rear tires.
• 🛢️ Warm the engine 2–3 minutes, then shut it off. Warm oil drains faster.
• 📌 If your Colorado has an underbody shield/air deflector, plan to remove it for access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front

• Place wheel chocks at the rear wheels.
• Lift the front with a floor jack (rated 3-ton minimum).
• Set the truck down onto jack stands (rated 3-ton minimum) under the frame.
• Give the truck a gentle push to confirm it’s stable.

Step 2: Remove the lower shield (if equipped)

• Remove the fasteners using a 10mm socket and ratchet.
• Pop plastic clips (if present) with a flathead screwdriver.
• Set the shield and fasteners aside in a small pile so nothing gets lost.

Step 3: Drain the engine oil

• Place the drain pan (7-quart minimum) under the oil pan drain plug.
• Loosen and remove the drain plug using a 15mm socket, ratchet, and extension (3-inch).
• Let the oil drain until it slows to an occasional drip (usually 5–10 minutes).
• Reinstall the drain plug and tighten with a torque wrench (10–100 ft-lbs range): Torque to 25 Nm (18 ft-lbs).

Step 4: Remove and replace the oil filter

• Move the drain pan (7-quart minimum) under the oil filter area (some oil will spill).
• Remove the oil filter using an oil filter wrench (band or cap style).
• Wipe the engine’s filter sealing surface with shop rags.
• Put a light film of new oil on the new filter’s rubber gasket (dip a finger into fresh oil).
• Install the new oil filter by hand until the gasket contacts, then tighten: Torque to 18 Nm (13 ft-lbs) using the oil filter wrench (band or cap style) (or hand-tight plus about 3/4 turn if you can’t fit a torque wrench).
• Make sure the old gasket didn’t stick.

Step 5: Reinstall the shield (if removed) and lower the truck

• Reinstall the shield fasteners using the 10mm socket and ratchet.
• Lower the truck from the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).

Step 6: Refill with new oil

• Open the hood and remove the oil fill cap.
• Place a funnel in the fill hole.
• Pour in Engine oil (SAE 5W-30 full synthetic, dexos1) (start with about 5.5 quarts).
• Reinstall the oil fill cap.

Step 7: Start, check for leaks, and verify the oil level

• Start the engine and let it idle 30–60 seconds.
• Check underneath for leaks at the drain plug and oil filter using safety glasses.
• Shut the engine off and wait 5 minutes.
• Check the dipstick, then top off as needed using the funnel (add small amounts until at the full mark).
• Wipe any spilled oil with shop rags.

Step 8: Reset the Oil Life Monitor

• Turn the key to ON (engine off).
• Use the steering wheel buttons to open the Driver Information Center.
• Navigate to Vehicle Info > Oil Life.
• Press and hold SET/CLR until it resets to 100%.

---

✅ After Repair

• 🧾 Confirm the Oil Life reads 100%.
• 🔍 Recheck for leaks after a short 5–10 minute drive.
• 🛢️ Recheck the dipstick the next morning and top off if needed.
• ♻️ Take used oil and the old filter to an oil recycling drop-off (most parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $120-$200 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $50-$150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
