🔧 XT5 - Engine Oil & Oil Filter Replacement

You’ll drain the old engine oil, replace the oil filter, and refill with fresh oil. This keeps your A4—sorry—your XT5’s engine lubricated properly and helps prevent wear and sludge buildup.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and set the parking brake.
• ⚠️ Let the engine cool 15-30 minutes; hot oil can burn you.
• ⚠️ Support the XT5 with jack stands before going underneath; never rely on a jack alone.
• ⚠️ Keep oil off belts, electrical connectors, and exhaust parts.
• ⚠️ No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Funnel
• Shop towels
• Ratchet
• 15mm socket
• 10mm socket
• 24mm socket
• Torque wrench (10-80 Nm range)
• Flat trim clip tool
• Oil filter O-ring pick (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic, dexos1 Gen 2) - Qty: 6 quarts
• Engine oil filter (cartridge element) - Qty: 1
• Oil filter cap O-ring (usually included with filter) - Qty: 1
• Drain plug gasket/washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Warm the engine for 2-3 minutes, then shut it off. Warm oil drains faster.
• Open the hood and remove the oil fill cap to help the crankcase vent while draining.
• If your XT5 has a lower splash shield, you’ll remove it to access the drain plug.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and safely support the XT5

• Place wheel chocks behind the rear tires.
• Use a floor jack (rated 3-ton minimum) to lift the front of the XT5 at the proper front jacking point.
• Set it down onto jack stands (rated 3-ton minimum) and gently shake the vehicle to confirm it’s stable.

Step 2: Remove the lower splash shield (if equipped)

• Use a 10mm socket to remove any small bolts holding the shield.
• Use a flat trim clip tool to pop out plastic clips (pry the center pin up first, then pull the clip body out).
• Slide the shield out and set it aside.

Step 3: Drain the old engine oil

• Put the drain pan (10-quart minimum) under the oil pan drain plug.
• Use a 15mm socket and ratchet to loosen the drain plug, then finish removing it by hand.
• Let the oil drain until it slows to an occasional drip (typically 5-10 minutes).
• Wipe the drain plug and the oil pan sealing surface using shop towels.

Step 4: Reinstall and torque the drain plug

• Install a new drain plug gasket/washer if your XT5 uses a separate washer.
• Thread the drain plug in by hand to avoid cross-threading.
• Use a torque wrench (10-80 Nm range) with a 15mm socket and Torque to 25 Nm (18 ft-lbs).

Step 5: Replace the oil filter (cartridge style)

• From the top of the engine bay, locate the oil filter housing cap (a plastic cap on the oil filter housing).
• Place shop towels around the housing to catch drips.
• Use a 24mm socket with a ratchet to loosen and remove the housing cap.
• Pull the old cartridge filter off the cap and discard it.
• Use an oil filter O-ring pick (specialty) to remove the old O-ring from the cap. (An O-ring is a rubber seal that prevents leaks.)
• Install the new O-ring and lightly coat it with fresh oil using a gloved finger.
• Push the new cartridge filter onto the cap (or into the housing, depending on your filter design) until it seats.

Step 6: Reinstall and torque the oil filter housing cap

• Thread the cap in by hand until the O-ring contacts and it seats smoothly.
• Use a torque wrench (10-80 Nm range) with a 24mm socket and Torque to 25 Nm (18 ft-lbs).
• Don’t overtighten; the cap is plastic.

Step 7: Refill with fresh oil
