🔧 Outlander - Engine Oil & Oil Filter Change

You’ll drain the old engine oil, replace the oil filter, then refill with fresh oil. This keeps your engine lubricated, reduces wear, and helps your A4—sorry, your Outlander—run cooler and cleaner.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

Assumption: stock 2.4L uses 0W-20 and a spin-on oil filter.

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the Outlander on jack stands (never jack only).
• ⚠️ Engine oil can be hot—let it cool a bit and wear gloves.
• ⚠️ Keep oil off belts and exhaust parts to avoid smoke/odor.
• ⚠️ No battery disconnect is required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart)
• Funnel
• Shop rags
• 17mm socket
• 3/8" drive ratchet
• Torque wrench (10-50 ft-lb range)
• Oil filter wrench (cap or strap type)
• Flat trim clip tool
• 10mm socket

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 5 quarts
• Oil filter - Qty: 1
• Drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Run the engine 2-3 minutes, then shut it off (warm oil drains faster).
• Open the hood and remove the oil fill cap (helps oil drain smoothly).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front

• Use a floor jack (rated 3-ton minimum) to lift the front safely at the front center jacking point.
• Set the Outlander onto jack stands (rated 3-ton minimum) at the proper support points.

Step 2: Remove the lower splash shield (if equipped)

• Use a 10mm socket to remove the small bolts holding the front lower cover.
• Use a flat trim clip tool to pop out any plastic push-clips (a trim clip tool is a flat pry tool that removes plastic fasteners without breaking them).
• Set the shield and fasteners aside where you won’t lose them.

Step 3: Drain the engine oil

• Place the drain pan (at least 8-quart) under the oil pan drain plug.
• Use a 17mm socket with a 3/8" drive ratchet to loosen and remove the drain plug.
• Let the oil drain until it slows to an occasional drip (usually 5-10 minutes).

Step 4: Reinstall drain plug with new crush washer

• Wipe the drain plug area clean with shop rags.
• Install a new drain plug crush washer on the drain plug.
• Thread the plug in by hand first (prevents cross-threading).
• Use a torque wrench (10-50 ft-lb range) and 17mm socket: Torque to 30 Nm (22 ft-lb).

Step 5: Remove the oil filter

• Move the drain pan (at least 8-quart) under the oil filter (it will spill).
• Use an oil filter wrench (cap or strap type) to loosen the filter, then spin it off by hand.
• Make sure the old rubber gasket comes off with the old filter (a stuck gasket can cause a bad leak).

Step 6: Install the new oil filter

• Lightly coat the new filter’s rubber gasket with fresh oil (use a dab of new oil from the bottle).
• Spin the new filter on by hand until the gasket touches the base.
• Tighten by hand an additional 3/4 turn (no tools for final tightening).
• Hand-tight is correct—don’t crush the gasket.

Step 7: Reinstall the splash shield

• Reposition the shield.
• Reinstall fasteners using the 10mm socket and any clips using the flat trim clip tool.

Step 8: Refill with new oil

• Lower the Outlander off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Insert a funnel into the oil fill hole.
• Add 4.5 quarts of 0W-20 full synthetic to start.
• Reinstall the oil fill cap.

Step 9: Start, inspect for leaks, and set the oil level

• Start the engine and let it idle 30-60 seconds.
• Check underneath for leaks at the drain plug and oil filter.
• Shut the engine off and wait 5 minutes.
• Check the dipstick, wipe it, reinsert, then read level again.
• Add oil in small amounts as needed to reach the full mark (use the funnel).

---

✅ After Repair

• Recheck for leaks after a short 5-10 minute drive.
• Dispose of used oil and the old filter at an oil recycling drop-off (most auto parts stores accept it).
• Reset the maintenance reminder (if it’s on): Ignition ON > Multi-Information Display Settings > Maintenance > Oil > Reset.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$60 (parts only)

You Save: $55-$100 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
