🔧 CX-5 - Engine Oil & Oil Filter Change

You’ll drain the old engine oil, replace the oil filter, then refill with the correct oil. This keeps your CX-5’s engine properly lubricated and helps prevent wear and sludge buildup.

Difficulty Level: Beginner | Estimated Time: 0.75-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the CX-5 with jack stands, not just a jack.
• ⚠️ Let the engine cool 15-30 minutes; hot oil can burn you.
• ⚠️ Chock the rear wheels before lifting the front.
• ⚠️ Keep oil off belts/tires and clean spills immediately.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 7-quart)
• Funnel
• Shop rags
• Ratchet
• Socket extension (3-inch)
• 17mm socket
• 8mm socket
• Flat trim clip tool
• Oil filter wrench (adjustable band type)
• Torque wrench (10-80 Nm range)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 0W-20 full synthetic) - Qty: 5 quarts
• Oil filter (spin-on) - Qty: 1
• Oil drain plug crush washer (gasket) - Qty: 1

---

📋 Before You Begin

• Park on level ground, engine off, and apply the parking brake.
• Chock both rear wheels.
• Warm the engine for 2-3 minutes, then shut it off and wait 15-30 minutes.
• Raise the front of the CX-5 with a floor jack and set it securely on jack stands at the factory lift points.
• Open the oil cap now; it drains faster.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Use an 8mm socket to remove the small bolts.
• Use a flat trim clip tool to pop out plastic clips (a trim clip tool is a flat pry tool that removes push-clips without breaking them).
• Set the shield and hardware aside in the order removed.

Step 2: Drain the old engine oil

• Place the drain pan (at least 7-quart) under the oil pan drain plug.
• Use a 17mm socket, ratchet, and socket extension (3-inch) to loosen the drain plug.
• Finish removing the plug by hand and let the oil drain fully (5-10 minutes).
• Remove the old crush washer from the drain plug and install the new one.

Step 3: Reinstall and torque the drain plug

• Thread the drain plug in by hand until it seats.
• Use a torque wrench (10-80 Nm range) and 17mm socket to tighten: Torque to 30 Nm (22 ft-lbs).
• Wipe the area clean with shop rags.

Step 4: Remove the oil filter

• Move the drain pan (at least 7-quart) under the oil filter area (some oil will spill).
• Use an oil filter wrench (adjustable band type) to loosen the filter, then spin it off by hand.
• Check that the old rubber gasket came off with the filter (it should not stay stuck to the engine).

Step 5: Install the new oil filter

• Dip a gloved finger (use nitrile gloves) into fresh oil and lightly oil the new filter’s rubber gasket.
• Spin the new filter on by hand until the gasket contacts the mounting surface.
• Tighten by hand an additional 3/4 turn (do not use the wrench to tighten).
• Wipe the area clean with shop rags.

Step 6: Reinstall the splash shield

• Reposition the shield.
• Reinstall clips with the flat trim clip tool.
• Reinstall bolts using the 8mm socket and ratchet.

Step 7: Refill with new oil and check level

• Lower the CX-5 off the jack stands using the floor jack (rated 2-ton minimum).
• Remove the oil fill cap and insert a funnel.
• Pour in SAE 0W-20 full synthetic (start with about 4.5 quarts), then reinstall the oil cap.
• Start the engine and let it idle for 30-60 seconds, then shut it off.
• Wait 5 minutes, then check the dipstick and top off as needed to the full mark.
• Add oil slowly; dipsticks can lag.

Step 8: Reset the oil maintenance reminder (if it’s on)

• Dash maintenance menu method: Use the steering wheel/dash controls to navigate to Settings > Maintenance > Oil Change > Reset.
• If you don’t have that menu: Tell me what warning you see (wrench icon, “Oil Change Due,” etc.) and I’ll give the exact reset steps for your cluster.

---

✅ After Repair

• With the engine idling, look underneath for leaks at the drain plug and oil filter.
• Recheck the oil level after your first short drive (5-10 minutes).
• Dispose of used oil and the old filter properly (most parts stores/service shops will take it).

---

💰 DIY vs Shop Cost

Shop Cost: ₹2,000-₹4,000 (parts + labor)

DIY Cost: ₹1,200-₹2,800 (parts only)

You Save: ₹800-₹1,200 by doing it yourself!

Shop labor rates vary but typically run ₹800-₹1,500/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
