🔧 Escape - Engine Oil & Oil Filter Replacement

You’ll drain the old engine oil, replace the oil filter, and refill with fresh oil. This keeps your engine lubricated, reduces wear, and helps the Escape run cooler and cleaner.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• Work on level ground and let the engine cool if it’s very hot.
• Use jack stands any time you’re under the Escape; never rely on a jack alone.
• Wear gloves and safety glasses; hot oil can burn skin.
• Keep oil off the exhaust and belts; wipe spills right away.
• Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 8-quart)
• Funnel
• 3/8" drive ratchet
• 3/8" drive extension (3"-6")
• 15mm socket
• Torque wrench (3/8" drive)
• Oil filter wrench
• Shop rags
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (5W-20) - Qty: 5 quarts
• Oil filter - Qty: 1
• Oil drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and chock the rear wheels.
• Warm the engine for 2-3 minutes so oil drains faster, then shut it off.
• Gather a drain pan and rags; oil will run along the drain plug at first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the Escape

• Use a floor jack (rated 3-ton minimum) to lift the front of the Escape at a proper front jacking point.
• Set it down securely onto jack stands (rated 3-ton minimum).
• Give the vehicle a gentle shake to confirm it’s stable. Stability first, always.

Step 2: Remove the oil fill cap (and loosen dipstick)

• Open the hood and remove the oil fill cap by hand.
• Pull the dipstick up slightly to help the crankcase vent while draining.

Step 3: Drain the old oil

• Place the drain pan (at least 8-quart) under the oil pan drain plug.
• Use a 3/8" drive ratchet with a 15mm socket (and 3/8" drive extension (3"-6") if needed) to loosen and remove the drain plug.
• Let the oil drain until it slows to an occasional drip (typically 5-10 minutes).

Step 4: Reinstall the drain plug

• Wipe the drain plug and oil pan sealing surface with shop rags.
• Replace the oil drain plug gasket if your plug uses one.
• Thread the plug in by hand first to avoid cross-threading.
• Use a torque wrench (3/8" drive) with a 15mm socket to tighten the drain plug: Torque to 28 Nm (21 ft-lbs).
• A torque wrench is a tool that clicks when you reach the correct tightness.

Step 5: Remove the oil filter

• Reposition the drain pan (at least 8-quart) under the oil filter area (some oil will spill).
• Use an oil filter wrench to loosen the filter, then spin it off by hand.
• Make sure the old rubber gasket comes off with the old filter (it can stick to the engine).

Step 6: Install the new oil filter

• Put a light film of fresh oil on the new filter’s rubber gasket using a gloved finger.
• Spin the new filter on by hand until the gasket contacts the base, then tighten an additional 3/4 turn by hand.
• If you’re using a torque method, use a torque wrench (3/8" drive) with the correct oil filter wrench adapter: Torque to 19 Nm (14 ft-lbs).

Step 7: Refill with new oil

• Lower the Escape back to the ground using the floor jack (rated 3-ton minimum).
• Insert a funnel into the oil fill hole.
• Add engine oil (5W-20): start with about 4.0 quarts, then top off to the correct level on the dipstick (typical fill is about 4.5 quarts with filter change).
• Reinstall the oil fill cap by hand.

Step 8: Start, inspect, and set the final level

• Start the engine and let it idle for 30-60 seconds.
• Shut it off and wait 3-5 minutes, then check the dipstick and top off as needed with engine oil (5W-20).
• Look underneath for leaks at the drain plug and oil filter, using safety glasses.

---

✅ After Repair

• Recheck the oil level the next day and top off if it drops slightly.
• Dispose of used oil and the old filter at an oil recycling drop-off (most parts stores accept it).
• If equipped with an oil life monitor in the cluster, reset it using the instrument panel menu (common path: Setup > Oil Life Reset), then confirm the reset.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$160 (parts + labor)

DIY Cost: $30-$70 (parts only)

You Save: $50-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
