🔧 Camry - Engine Oil & Oil Filter Change

Changing the engine oil and oil filter keeps your A4’s engine lubricated and prevents premature wear. On your Camry, the filter is a cartridge-style element inside a reusable housing, so you replace the inner filter and O-rings each time.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

Assumption: 0W-20 full synthetic; cartridge filter housing type.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the car with jack stands (never the jack alone).
• ⚠️ Let the engine cool 20-30 minutes; hot oil can burn you.
• ⚠️ Hybrid safety: make sure the car is fully OFF (not in READY) and keep the key/fob away from the car while you’re underneath.
• ⚠️ Wear safety glasses and nitrile gloves; oil will drip when the filter housing opens.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart)
• Funnel
• 14mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-80 Nm range)
• 10mm socket
• Trim clip removal tool
• 64mm 14-flute oil filter cap wrench (specialty)
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 5 quarts
• Oil filter element (cartridge type) - Qty: 1
• Oil filter housing O-ring set - Qty: 1
• Oil drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Start the engine for 2-3 minutes, then shut it off; slightly warm oil drains faster.
• Lift the front using a floor jack and place it securely on jack stands at the front pinch welds or proper lift points.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash cover access

• Slide your drain pan under the engine area.
• Use a 10mm socket and trim clip removal tool to open/remove the small service door (or fasteners) in the lower splash shield.
• Keep clips in a cup so none disappear.

Step 2: Drain the engine oil

• Locate the oil drain plug on the bottom of the oil pan.
• Use a 14mm socket with a 3/8" drive ratchet to loosen the drain plug.
• Finish unthreading by hand and quickly pull it away so oil flows into the drain pan.
• Replace the old drain plug gasket with the new one.
• Reinstall the drain plug and tighten with a torque wrench: Torque to 40 Nm (29 ft-lbs).

Step 3: Remove the oil filter housing (cartridge style)

• Find the oil filter housing near the front/bottom of the engine.
• Use the 64mm 14-flute oil filter cap wrench (specialty) with a 3/8" drive ratchet to loosen the housing.
• As you remove it, keep the drain pan underneath; oil will spill out.
• Turn slowly to avoid a sudden oil splash.

Step 4: Replace the filter element and O-rings

• Pull the old filter element out of the housing by hand and discard it.
• Remove the old O-ring(s) from the housing using a shop rag (avoid scratching the plastic/metal groove).
• Lightly coat the new O-ring(s) with fresh 0W-20 engine oil (this helps prevent pinching).
• Install the new filter element into the housing.

Step 5: Reinstall and torque the filter housing

• Thread the housing back on by hand first (this prevents cross-threading, meaning damaging the threads by starting crooked).
• Use the 64mm 14-flute oil filter cap wrench (specialty) and torque wrench: Torque to 25 Nm (18 ft-lbs).
• Wipe the area clean with shop rags.

Step 6: Reinstall the splash cover access

• Use the 10mm socket and trim clip removal tool to reinstall the access door/fasteners.

Step 7: Refill with new engine oil

• Lower the car off the jack stands using the floor jack.
• Open the hood and remove the oil fill cap.
• Use a funnel and add 0W-20 full synthetic (start with about 4.0 quarts).
• Wait 1-2 minutes, then check the dipstick and top off to the full mark (typically around 4.4-4.6 quarts with filter).

Step 8: Start, check for leaks, and re-check level

• Start the car and let it run 30-60 seconds, then shut it off.
• Look underneath for leaks at the drain plug and filter housing.
• Wait 5 minutes, then check the dipstick again and adjust the level if needed.

Step 9: Reset the maintenance reminder

• Turn ignition to ON (dash lights on), engine OFF.
• Use the steering wheel controls to display ODO (not Trip A/Trip B).
• Turn ignition OFF.
• Press and hold the trip/ODO button, then turn ignition back to ON while holding.
• Keep holding until the reminder resets (dashes/countdown completes).

---

✅ After Repair

• Test drive 5-10 minutes, then re-check for leaks and confirm the oil level is at the full mark.
• Dispose of used oil and the old filter properly at a recycling/parts store drop-off.
• If you see oil seeping around the filter housing, shut off and re-check the O-ring seating.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$180 (parts + labor)

DIY Cost: $35-$75 (parts only)

You Save: $55-$105 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
