🔧 CX-9 - Engine Oil & Oil Filter Change

You’ll drain the old engine oil, replace the oil filter, then refill with fresh oil. This protects the turbocharged engine from wear, overheating, and sludge buildup.

Difficulty Level: Beginner | Estimated Time: 1.0-1.5 hours

Assumption: 2.5L turbo uses 5W-30 and ~5.1 qt with filter.

---

⚠️ Safety & Precautions

• Let the engine cool 15-30 minutes; oil can burn skin.
• Support the CX-9 on jack stands; never rely on a floor jack alone.
• Chock the rear wheels and keep the transmission in P with the parking brake set.
• Keep oil off the serpentine belt and exhaust; it can smoke or smell.
• Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum, pair)
• Wheel chocks (pair)
• Safety glasses
• Nitrile gloves
• Drain pan (7-quart minimum)
• Funnel
• Shop towels
• Ratchet
• 17mm socket
• 8mm socket
• Phillips #2 screwdriver
• Trim clip removal tool
• Torque wrench (10-80 Nm range)
• Oil filter wrench (adjustable band type)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (5W-30 full synthetic) - Qty: 6 quarts
• Oil filter - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and place wheel chocks behind the rear tires.
• Warm the engine for 2-3 minutes, then shut it off. Warm oil drains faster, but you don’t want it dangerously hot.
• Open the hood and loosen/remove the oil filler cap to help the crankcase vent while draining.
• Gather a place to pour used oil into a sealed container for recycling.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front

• Use a floor jack (rated 2-ton minimum) to lift the front at the center front jacking point.
• Set the vehicle onto jack stands (rated 2-ton minimum, pair) at the approved pinch weld/support points.
• Give the CX-9 a gentle shake to confirm it’s stable before going underneath.

Step 2: Remove the lower splash shield (if equipped)

• Use an 8mm socket and ratchet to remove small bolts, if present.
• Use a Phillips #2 screwdriver for any screw-type fasteners.
• Use a trim clip removal tool to pop plastic push-clips. (A trim clip tool is a small pry tool made for plastic clips so they don’t break.)
• Set all fasteners aside in a tray so nothing gets lost.

Step 3: Drain the old oil

• Position the drain pan (7-quart minimum) under the oil pan drain plug.
• Use a 17mm socket and ratchet to loosen the drain plug, then finish unthreading by hand.
• Let the oil drain until it slows to an occasional drip (usually 5-10 minutes).
• Remove the old oil drain plug crush washer from the plug and install the new one. (A crush washer is a soft metal ring that seals when tightened.)

Step 4: Reinstall the drain plug

• Thread the drain plug in by hand first to avoid cross-threading.
• Use a torque wrench (10-80 Nm range) with a 17mm socket to tighten the drain plug: Torque to 30 Nm (22 ft-lbs). (A torque wrench tightens to an exact setting so you don’t strip threads.)
• Wipe the area clean to spot leaks.

Step 5: Remove the old oil filter

• Move the drain pan (7-quart minimum) under the oil filter area (some oil will spill).
• Use an oil filter wrench (adjustable band type) to loosen the filter, then spin it off by hand.
• Check that the old rubber gasket came off with the old filter (it should not stick to the engine).

Step 6: Install the new oil filter

• Put a light film of new oil on the new filter’s rubber gasket using a gloved finger.
• Spin the new filter on by hand until the gasket contacts the engine, then tighten an additional 3/4 turn by hand.
• Do not use the filter wrench to tighten unless you cannot get it snug by hand.

Step 7: Reinstall the splash shield

• Reposition the shield and install fasteners by hand first.
• Use an 8mm socket and ratchet and/or Phillips #2 screwdriver to snug fasteners.
• Press plastic clips back in using the trim clip removal tool (or your thumb) until fully seated.

Step 8: Refill with new oil and verify the level

• Lower the CX-9 back to the ground using the floor jack (rated 2-ton minimum).
• Insert a funnel and add about 5.0 quarts of 5W-30 full synthetic.
• Reinstall the oil filler cap.
• Start the engine and let it idle for 30-60 seconds, then shut it off.
• Wait 5 minutes, then check the dipstick and top off in small amounts until it reaches the full mark (typically ends up near ~5.1 quarts total with filter).

Step 9: Reset the oil maintenance reminder

• Turn ignition to ON (engine off).
• On Mazda Connect, go to: Applications > Vehicle Status Monitor > Maintenance > Oil Change > Reset.
• If your menu layout differs, look for: Settings > Vehicle Maintenance > Oil Change > Reset.

---

✅ After Repair

• With the engine running, look underneath for leaks around the drain plug and oil filter.
• Recheck the dipstick after a short 5-10 minute drive; top off if needed.
• Pour used oil into sealed containers and recycle it with the used filter.
• Write the date and mileage for your records.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$200 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $75-$110 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
