🔧 TITAN - Engine Oil & Oil Filter Replacement

You’ll drain the old oil, replace the oil filter, then refill with the correct oil. This keeps your engine lubricated, prevents sludge, and helps the engine last longer.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and chock the rear wheels.
• ⚠️ Hot oil can burn you—let the engine cool 10-20 minutes before draining.
• ⚠️ Never rely on a jack alone—support your TITAN with jack stands.
• ⚠️ Wear gloves and safety glasses; oil will splash when the plug comes out.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Funnel
• Shop rags
• 14mm socket
• 3/8" drive ratchet
• Torque wrench (3/8" drive, 10-80 ft-lbs range)
• Oil filter wrench (adjustable band type)
• 10mm socket
• Trim clip remover (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 8 quarts
• Engine oil filter - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park your TITAN on level ground and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Warm the engine for 2-3 minutes, then shut it off and let it cool 10-20 minutes.
• Gather a drain pan that holds at least 10 quarts.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the front

• Use a floor jack (rated 3-ton minimum) to lift the front safely.
• Set the frame onto jack stands (rated 3-ton minimum).
• Give the truck a gentle shake to confirm it’s stable. Stable first, then work.

Step 2: Remove the lower cover (if equipped)

• If your TITAN has a front splash shield/undercover, remove fasteners using a 10mm socket.
• Remove any plastic push-clips using a trim clip remover (specialty) (a small forked tool that pops clips out).
• Set the cover and hardware aside in a small pile so nothing gets lost.

Step 3: Drain the engine oil

• Place the drain pan (10-quart minimum) under the oil pan drain plug.
• Loosen the drain plug using a 14mm socket and 3/8" drive ratchet.
• Finish removing the plug by hand (push inward slightly while unthreading, then pull away quickly).
• Let the oil drain until it slows to an occasional drip (typically 5-10 minutes).

Step 4: Reinstall the drain plug with a new crush washer

• Wipe the drain plug area clean using shop rags.
• Install a new oil drain plug crush washer onto the drain plug.
• Thread the plug in by hand first to avoid cross-threading.
• Tighten using a torque wrench and 14mm socket: Torque to 34 Nm (25 ft-lbs).

Step 5: Remove the oil filter

• Move the drain pan under the oil filter area (oil will spill when the filter comes off).
• Loosen the oil filter using an oil filter wrench (adjustable band type).
• Spin the filter off by hand and keep it upright as you remove it.
• Make sure the old rubber gasket isn’t stuck to the engine (a “double gasket” can cause a bad leak).

Step 6: Install the new oil filter

• Wipe the filter mounting surface clean using shop rags.
• Lightly coat the new filter’s rubber gasket with fresh oil (use a fingertip).
• Thread the new filter on by hand until the gasket touches, then tighten an additional 2/3 turn by hand. Hand-tight is correct.
• If you must use a wrench to finish, do not over-tighten.

Step 7: Reinstall the lower cover (if removed)

• Reinstall the splash shield/undercover using a 10mm socket.
• Reinstall push-clips using a trim clip remover (specialty) to align them, then press them in.

Step 8: Refill with engine oil

• Lower your TITAN off the stands using the floor jack (rated 3-ton minimum).
• Remove the oil filler cap on top of the engine.
• Use a funnel to add 0W-20 full synthetic oil.
• Add most of the oil first, then use the dipstick to bring the level to the top mark (do not overfill). Sneak up on the full mark.

Step 9: Start, check for leaks, and verify level

• Start the engine and let it idle for 30-60 seconds.
• Shut the engine off and look underneath for leaks at the drain plug and oil filter.
• Wait 5 minutes, then check the dipstick and top off as needed using the funnel.

---

✅ After Repair

• Re-check for leaks after your first short drive.
• Reset the oil maintenance reminder on the gauge cluster (if enabled): use the steering-wheel buttons to open Settings > Maintenance > Oil and Filter > Reset.
• Dispose of used oil and the filter at an oil-recycling drop-off location.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $75-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
