🔧 Outlander Sport - Engine Oil & Oil Filter Change

Changing the oil and filter keeps your engine lubricated and prevents internal wear. You’ll drain the old oil, replace the filter (it traps dirt/metal), then refill with fresh oil to the correct level.

Difficulty Level: Beginner | Estimated Time: 45-90 minutes

Assumption: 2.0L uses 0W-20 full synthetic and a 17mm drain plug; layouts can vary slightly by under-cover style.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the Outlander Sport with jack stands (never the jack alone).
• ⚠️ Engine oil can be hot. Let it cool 10-20 minutes to avoid burns.
• ⚠️ Keep oil off belts/exhaust; wipe spills immediately.
• ⚠️ Wear nitrile gloves and safety glasses.
• 🔋 Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart)
• Funnel
• 17mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-80 Nm range)
• Oil filter wrench (cap-style or band-style)
• 10mm socket
• Trim clip removal tool
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 5 quarts
• Oil filter - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to neutral, and set the parking brake.
• Place wheel chocks behind the rear tires.
• Warm the engine for 2-3 minutes, then shut it off. Warm oil drains faster.
• Open the hood and remove the oil fill cap and pull up the dipstick slightly (this helps the oil drain).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the front

• Use a floor jack to lift at the front center jacking point, then set the vehicle onto jack stands at the pinch welds.
• Shake the vehicle lightly to confirm it’s stable before going underneath.

Step 2: Remove the lower engine under-cover (if equipped)

• Use a 10mm socket to remove the bolts.
• Use a trim clip removal tool to pop out any plastic clips (a clip tool is a small forked pry tool that removes plastic fasteners without breaking them).
• Set the cover and fasteners aside in order.

Step 3: Drain the old engine oil

• Place the drain pan (at least 8-quart) under the oil pan drain plug.
• Use a 17mm socket with a 3/8" drive ratchet to loosen the drain plug, then finish removing it by hand.
• Let the oil drain until it slows to an occasional drip (typically 5-10 minutes).
• Remove the old crush washer from the drain plug and install a new crush washer.

Step 4: Reinstall and torque the drain plug

• Thread the drain plug in by hand first to avoid cross-threading.
• Use a 3/8" drive torque wrench with a 17mm socket and Torque to 39 Nm (29 ft-lbs).
• Wipe the area clean with shop rags.

Step 5: Remove the oil filter

• Move the drain pan under the oil filter area (oil will spill when the filter comes off).
• Use an oil filter wrench to loosen the filter, then spin it off by hand.
• Confirm the old rubber gasket came off with the filter (it should not stick to the engine). Double-gasket can cause a big leak.

Step 6: Install the new oil filter

• Put a light film of fresh oil on the new filter’s rubber gasket using a gloved finger.
• Spin the new filter on by hand until the gasket touches, then tighten 3/4 turn by hand.
• If your filter lists a torque spec and you have the correct cap tool, use the oil filter wrench and torque wrench to tighten to the filter’s specification.

Step 7: Reinstall the under-cover

• Reinstall the cover using the trim clip removal tool (to align clips) and tighten fasteners with the 10mm socket.
• Do not overtighten plastic fasteners.

Step 8: Refill with fresh oil

• Lower the vehicle from the jack stands using the floor jack.
• Insert a funnel into the oil fill hole.
• Pour in about 4.0 quarts of 0W-20 full synthetic first.
• Reinstall the oil fill cap, then start the engine for 30-60 seconds.
• Shut the engine off and wait 3-5 minutes, then check the dipstick and top off as needed (typical total is about 4.3 quarts with filter).

Step 9: Check for leaks

• With the engine running, look underneath for leaks at the drain plug and oil filter.
• Shut it off and recheck the dipstick one more time.

---

✅ After Repair

• Dispose of used oil and the old filter at a recycling center/auto parts store that accepts waste oil.
• Wipe any spilled oil off the skid plate/underbody with shop rags.
• If equipped with a maintenance reminder in the cluster: reset the oil reminder in the multi-information display maintenance settings (wording varies by cluster).
• Recheck the oil level the next day (cold engine, level ground) and top off if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $55-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
