🔧 Envision - Engine Oil & Oil Filter Replacement

This service drains the old engine oil and replaces the oil filter, then refills with the correct oil so your Envision’s turbo engine stays protected. Doing this on schedule prevents sludge, reduces wear, and helps the turbo live longer.

Difficulty Level: Beginner | Estimated Time: 1.0-1.5 hours

Assumption: Using the 2.0L turbo oil spec dexos1 5W-30; verify capacity with your owner’s manual label/spec chart.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the Envision with jack stands before going underneath.
• ⚠️ Engine oil gets very hot; let it cool 10–20 minutes to avoid burns.
• ⚠️ Keep oil off belts, hoses, and the exhaust to prevent smoke and odor.
• ⚠️ If you raise the vehicle, chock the rear wheels with wheel chocks.
• 🔋 Battery disconnect is not required for an oil change.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart)
• Socket set with ratchet (metric)
• Oil drain plug socket (metric, vehicle-specific)
• Torque wrench (3/8" drive)
• Oil filter wrench (cap or band type)
• Trim clip remover tool
• Flathead screwdriver
• Funnel
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (dexos1 5W-30 full synthetic) - Qty: 6 quarts
• Engine oil filter - Qty: 1
• Oil drain plug gasket/seal (if equipped) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Warm the engine for 2–3 minutes, then shut it off and wait 10–20 minutes so the oil drains well but isn’t scalding.
• Gather all tools and parts. Put a piece of cardboard under the front of the Envision to catch drips.
• If your Envision has a lower splash shield (undertray), plan to remove it for access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the Envision

• Place wheel chocks behind the rear tires.
• Lift the front using a floor jack (rated 3-ton minimum) at the front center jack point.
• Set the vehicle onto jack stands (rated 3-ton minimum) at the approved front support points.
• Give the vehicle a gentle shake to confirm it’s stable before going underneath.

Step 2: Remove the lower splash shield (if equipped)

• Use a trim clip remover tool and flathead screwdriver to remove plastic push clips.
• Use your socket set with ratchet (metric) to remove any small bolts holding the panel.
• Set all clips/bolts aside in a small tray so they don’t get lost.

Step 3: Drain the engine oil

• Position a drain pan (at least 8-quart) under the oil pan drain plug.
• Use the correct oil drain plug socket (metric, vehicle-specific) with your socket set with ratchet (metric) to loosen and remove the drain plug.
• Let the oil drain until it slows to an occasional drip (usually 5–10 minutes).
• Wipe the drain plug and oil pan sealing surface with shop towels.
• If your plug uses a separate seal, replace it with the new oil drain plug gasket/seal.
• Reinstall the drain plug by hand first (to avoid cross-threading), then tighten with a torque wrench (3/8" drive).
• Torque: If your manual/spec label lists a drain plug torque, use it. If not available, do not over-tighten—snug plus a small turn is safer than stripping threads.
• Tip: Keep inward pressure while unthreading the plug.

Step 4: Remove the old oil filter

• Move the drain pan (at least 8-quart) under the oil filter area (it will spill).
• Use an oil filter wrench (cap or band type) to loosen the filter, then spin it off by hand.
• Oil filter wrench: a tool that grips the filter canister so you can turn it.
• Make sure the old rubber gasket came off with the old filter (it sometimes sticks to the engine).
• Clean the sealing surface with shop towels.

Step 5: Install the new oil filter

• Lightly coat the new filter’s rubber gasket with fresh oil (use a dab on a gloved finger).
• Spin the new filter on by hand until the gasket touches the base.
• Tighten by hand an additional 3/4 turn (unless the filter packaging specifies a different turn amount).
• Tip: Hand-tight prevents crushing the gasket.

Step 6: Reinstall the splash shield (if removed)

• Reposition the shield and install bolts with your socket set with ratchet (metric).
• Install push clips with the trim clip remover tool as needed.

Step 7: Lower the Envision and refill with oil

• Raise slightly with the floor jack (rated 3-ton minimum), remove the jack stands (rated 3-ton minimum), and lower to the ground.
• Open the hood and remove the oil fill cap.
• Insert a funnel and add engine oil (dexos1 5W-30 full synthetic).
• Add most of the expected capacity first, then wait 1 minute and check the dipstick.
• Top off to the full mark (do not overfill).

Step 8: Start, check for leaks, and re-check level

• Start the engine and let it idle for 30–60 seconds.
• Shut the engine off and look underneath for leaks at the drain plug and oil filter.
• Wait 5 minutes, then check the dipstick again and top off if needed using the funnel.
• Wipe any spilled oil with shop towels.

Step 9: Reset the Oil Life Monitor

• Turn the ignition on (engine can be off).
• Use the steering wheel controls to find the oil life screen in the Driver Information Center.
• Press and hold SET/CLR to reset to 100%.
• Confirm the reset when prompted.

---

✅ After Repair

• Check the dipstick again after your first short drive and top off if needed.
• Dispose of used oil and the old filter properly at a recycling center/auto parts store that accepts waste oil.
• If you see any dripping, re-check the filter tightness (hand-tight only) and confirm the drain plug is properly tightened.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $75-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
