🔧 Escape - Engine Oil & Oil Filter Change

On your Escape, you’ll drain the old oil from the oil pan, replace the oil filter element, then refill with the correct oil. Fresh oil protects the turbo engine from wear and helps prevent sludge buildup.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the Escape with jack stands before going underneath.
• ⚠️ Oil and exhaust parts can be hot; let the engine cool 15–30 minutes to avoid burns.
• ⚠️ Keep the drain pan ready—oil can shoot out sideways at first.
• ⚠️ Wear nitrile gloves and safety glasses.
• Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (8-quart minimum)
• Funnel
• Shop towels
• 3/8" drive ratchet
• 3/8" drive extension (6")
• Torque wrench (10–50 ft-lbs range)
• 15mm socket
• 27mm socket
• 7mm socket
• 8mm socket
• Trim clip tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (5W-30 full synthetic) - Qty: 6 quarts
• Oil filter element (cartridge style) with O-ring - Qty: 1
• Oil drain plug washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Warm the engine for 2–3 minutes, then shut it off. Warm oil drains faster.
• Raise the front with a floor jack and support with jack stands at the proper lift points.
• Open the hood and remove the oil fill cap (this helps oil drain smoothly).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Use a 7mm socket and 8mm socket to remove the undertray screws.
• Use a trim clip tool to pop out any push-pins without breaking them.
• Set the shield and hardware aside in a small pile so nothing gets lost.

Step 2: Drain the engine oil

• Place the drain pan (8-quart minimum) under the oil pan drain plug.
• Use a 15mm socket with a 3/8" drive ratchet to loosen the drain plug, then finish by hand.
• Let the oil drain until it slows to an occasional drip (usually 5–10 minutes).
• Clean the drain plug area with shop towels.

Step 3: Reinstall the drain plug

• Install a new oil drain plug washer on the plug.
• Thread the drain plug in by hand first (prevents cross-threading).
• Use a torque wrench with a 15mm socket: Torque to 27 Nm (20 ft-lbs).

Step 4: Replace the oil filter element (cartridge)

• Locate the oil filter housing cap in the engine bay (it’s a round cap on top of the engine).
• Use a 27mm socket with a 3/8" drive ratchet and 3/8" drive extension (6") to loosen the cap.
• Lift the cap straight up; the old filter element will usually come up with it.
• Pull the old filter element off the cap by hand.
• Remove the old O-ring from the cap (the O-ring is a rubber sealing ring) and install the new O-ring from the filter kit.
• Wipe the housing sealing surface with shop towels.

Step 5: Install the new filter and torque the housing cap

• Push the new filter element onto the cap until fully seated.
• Thread the cap into the housing by hand until snug.
• Use a torque wrench with a 27mm socket: Torque to 25 Nm (18 ft-lbs).
• Hand-starting prevents expensive housing damage.

Step 6: Reinstall the lower splash shield

• Reposition the shield.
• Use the trim clip tool to reinstall push-pins.
• Use a 7mm socket and 8mm socket to reinstall and snug the screws (do not over-tighten).

Step 7: Refill with oil and verify the level

• Insert a funnel into the oil fill hole.
• Pour in 5.5 quarts of 5W-30 full synthetic to start (your target with filter change is about 5.7 quarts (5.4 L)).
• Reinstall the oil fill cap.
• Start the engine and let it idle for 30–45 seconds, then shut it off.
• Wait 3–5 minutes, then check the dipstick and top off to the full mark (usually the remaining ~0.2 quart).
• Use shop towels to wipe the dipstick clean between checks.

Step 8: Reset the oil life monitor

• Key on, engine off.
• Using the steering wheel buttons, go to Settings > Vehicle > Oil Life Reset.
• Select reset and press/hold OK until it confirms 100%.

---

✅ After Repair

• Look underneath for leaks around the drain plug and filter housing after the first idle run.
• Recheck the dipstick one more time after a short 5–10 minute drive.
• Dispose of used oil and the old filter at a recycling center or parts store (never dump it).

---

💰 DIY vs Shop Cost

Shop Cost: $120-$200 (parts + labor)

DIY Cost: $35-$75 (parts only)

You Save: $45-$165 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
