🔧 Corolla - Engine Oil & Oil Filter Change

Changing the oil and oil filter keeps your engine lubricated, cool, and clean. On your Corolla, you’ll drain the old oil, replace the spin-on oil filter, then refill with the correct amount of fresh oil.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the car with jack stands—never rely on a jack alone.
• ⚠️ Engine oil can be hot; let the engine cool 15-30 minutes to avoid burns.
• ⚠️ Keep oil off belts and exhaust parts; wipe spills immediately.
• ⚠️ Wear gloves and safety glasses; used oil is a skin irritant.
• ⚠️ No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (2-ton minimum pair)
• Wheel chocks (pair)
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart capacity)
• 14mm socket
• 3/8" drive ratchet
• 3"-6" socket extension
• 10mm socket
• Flat trim clip tool
• Oil filter wrench (band or cup style)
• Torque wrench (10-80 ft-lbs range)
• Funnel
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 5W-30) - Qty: 4 quarts
• Oil filter (spin-on type) - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, put the transmission in neutral, set the parking brake, and place wheel chocks behind the rear tires.
• Warm the engine for 2-3 minutes, then shut it off. This helps the oil drain faster.
• Open the hood and loosen the oil filler cap (this helps the crankcase vent while draining).
• If you raise the front of the car, lift using a floor jack and support with jack stands at the proper front support points.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the front (if needed)

• Use a floor jack (rated 3-ton minimum) to lift the front of the car.
• Place jack stands (2-ton minimum pair) under solid front support points and lower the car onto them.
• Give the car a gentle shake to confirm it’s stable before you get underneath.

Step 2: Remove the lower splash shield (if equipped)

• Locate the plastic under-cover under the engine area.
• Use a 10mm socket with a 3/8" drive ratchet to remove any 10mm bolts.
• Use a flat trim clip tool to pop out plastic clips (a trim clip tool is a flat prying tool made for push-clips).
• Set the shield hardware aside so nothing gets lost.

Step 3: Drain the old engine oil

• Place the drain pan (at least 8-quart capacity) under the oil pan drain plug.
• Use a 14mm socket with a 3/8" drive ratchet and socket extension to loosen the drain plug.
• Finish removing the plug by hand and let the oil drain fully (usually 5-10 minutes).
• Remove the old crush washer from the drain plug and install the new oil drain plug crush washer.

Step 4: Reinstall and torque the drain plug

• Thread the drain plug in by hand first (this prevents cross-threading).
• Use a torque wrench (10-80 ft-lbs range) with a 14mm socket to tighten the drain plug: Torque to 37 Nm (27 ft-lbs).
• Hand-starting threads prevents expensive damage.

Step 5: Remove the oil filter

• Move the drain pan under the oil filter area (some oil will spill).
• Use an oil filter wrench (band or cup style) to loosen the filter, then spin it off by hand.
• Use shop rags to wipe the filter mounting surface clean.
• Make sure the old filter’s rubber gasket didn’t stick to the engine (double-gasket can cause a major leak).

Step 6: Install the new oil filter

• Put a light film of fresh oil on the new filter’s rubber gasket using a gloved finger.
• Spin the new filter on by hand until the gasket touches the engine, then tighten it an additional 3/4 turn by hand.
• If you’re using a torque wrench adapter for the filter, tighten to: Torque to 18 Nm (13 ft-lbs).

Step 7: Reinstall the splash shield (if removed)

• Reposition the shield and install clips by hand first.
• Use a 10mm socket with a 3/8" drive ratchet to reinstall the bolts snugly (do not overtighten plastic).

Step 8: Refill with fresh oil

• Lower the car off the jack stands using the floor jack.
• Insert a funnel into the oil fill hole.
• Pour in about 3.5 quarts of SAE 5W-30 first.
• Wait 1 minute, then use the dipstick to check level and top off gradually.
• Typical fill amount with filter change is about 3.9 quarts (3.7 L) total—always confirm with the dipstick.
• Reinstall the oil filler cap.

Step 9: Start, check for leaks, and re-check the level

• Start the engine and let it idle 30-60 seconds.
• Shut the engine off and look underneath for leaks around the drain plug and oil filter.
• Wait 5 minutes, then check the dipstick and adjust the oil level to the full mark.

---

✅ After Repair

• Re-check the oil level again after your first short drive.
• Dispose of used oil and the old filter at an oil recycling drop-off (most parts stores accept it).
• Reset the maintenance reminder light (if it’s on): with the key OFF, press and hold the ODO/TRIP button, turn the key to ON (do not start), keep holding until the light resets.

---
