🔧 E-150 - Engine Oil & Oil Filter Change

Changing the oil and oil filter keeps your A4’s engine lubricated and helps prevent wear. On your E-150, you’ll drain old oil from the oil pan, replace the spin-on oil filter, then refill with the correct oil and verify the level.

Difficulty Level: Beginner | Estimated Time: 0.75-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and set the parking brake.
• ⚠️ Support the van with jack stands or ramps—never rely on a floor jack alone.
• ⚠️ Let the exhaust cool if it’s very hot; oil and components can burn you.
• ⚠️ Wear gloves and safety glasses; used oil is a skin irritant.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• Funnel
• Oil filter wrench (cap or band type)
• 3/8" drive ratchet
• 16mm socket
• 19mm socket
• Torque wrench (ft-lb)
• Shop rags
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 5W-20, API SP or newer) - Qty: 6 quarts
• Engine oil filter (spin-on) - Qty: 1
• Oil drain plug gasket (if equipped/separate) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Warm the engine for 2–3 minutes so the oil flows easier, then shut it off.
• Open the hood and remove the oil fill cap to help the oil drain faster.
• If you’re new: an oil filter wrench is a tool that grips the oil filter so you can loosen it without crushing it.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the van

• Place wheel chocks and set the parking brake.
• Use a floor jack (rated 3-ton minimum) to lift the front, then set the van down onto jack stands (rated 3-ton minimum).
• Give the van a gentle shake to confirm it’s stable before going underneath.

Step 2: Drain the old engine oil

• Position the drain pan (at least 10-quart) under the oil pan drain plug.
• Use a 3/8" drive ratchet with a 16mm socket (or 19mm socket on some oil pans) to loosen the drain plug.
• Remove the plug by hand the last few turns and let the oil drain fully (usually 5–10 minutes).
• Clean the drain plug and the oil pan sealing surface using shop rags.
• Reinstall the drain plug and tighten with a torque wrench (ft-lb): Torque to 26 Nm (19 ft-lbs).
• Tip: keep pressure on the plug as you unthread it.

Step 3: Remove the old oil filter

• Move the drain pan (at least 10-quart) under the oil filter area (some oil will spill).
• Use an oil filter wrench (cap or band type) to loosen the oil filter, then spin it off by hand.
• Make sure the old rubber gasket came off with the old filter (it can stick to the engine).

Step 4: Install the new oil filter

• Lightly oil the new filter’s rubber gasket with fresh oil (use a dab from a bottle and a finger with nitrile gloves).
• Spin the new filter on by hand until the gasket touches, then tighten 3/4 turn by hand.
• Do not use the oil filter wrench to tighten unless the filter instructions specifically say so.

Step 5: Refill with new oil

• Lower the van off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Insert a funnel into the oil fill opening and pour in 5 quarts of SAE 5W-20.
• Reinstall the oil fill cap.

Step 6: Run, check for leaks, and set the level

• Start the engine and let it idle for 30–60 seconds.
• Shut the engine off and wait 3–5 minutes.
• Check underneath for leaks at the drain plug and oil filter using safety glasses and a shop rag.
• Check the dipstick level, then add oil as needed to reach the full mark (typically you’ll end up around 6 quarts total with filter).
• Tip: add oil in small amounts near full.

---

✅ After Repair

• Recheck the dipstick after a short drive and top off if needed.
• Dispose of used oil and the old filter at an oil recycling drop-off (many auto parts stores accept it).
• Wipe any spilled oil off the frame/crossmember using shop rags to avoid smoke/odor later.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$75 (parts only)

You Save: $55-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
