🔧 Escape - Engine Oil & Filter Change

You’ll be draining the old engine oil, replacing the oil filter, and refilling with fresh oil on your Escape. This keeps the 2.0L EcoBoost lubricated, running cooler, and extends engine life.

Difficulty Level: Beginner | Estimated Time: 1–1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Always support the front of your Escape with jack stands, never rely only on a floor jack.
• ⚠️ Engine oil can be hot; let the engine cool at least 20–30 minutes after driving.
• ⚠️ Wear safety glasses and mechanic gloves to protect your eyes and hands from hot oil.
• ⚠️ Keep rags handy and clean up any spilled oil immediately so you don’t slip.
• ⚠️ Used oil and filters are hazardous waste; dispose of them at an auto parts store or recycling center (California has strict rules).
• ⚠️ You do not need to disconnect the battery for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (pair, rated 3-ton minimum)
• 🛠️ Wheel chocks
• 🛠️ 13mm socket
• 🛠️ 3/8" drive ratchet
• 🛠️ 3/8" drive torque wrench (ft-lb scale)
• 🛠️ Oil filter cap/socket wrench (74mm, 14-flute) (specialty)
• 🛠️ Oil drain pan (at least 8-quart capacity)
• 🛠️ Plastic funnel (medium size)
• 🛠️ Flathead screwdriver (medium size)
• 🛠️ Shop rags or paper towels
• 🛠️ Safety glasses
• 🛠️ Mechanic gloves
• 🛠️ Creeper or foam pad
• 🛠️ Work light or flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Engine oil (5W-30 full synthetic, meeting Ford WSS-M2C946-B1 or later) - Qty: 5.7 quarts (buy 6 quarts)
• 🔩 Engine oil filter cartridge (2.0L EcoBoost) - Qty: 1
• 🔩 Oil filter cap O-ring - Qty: 1 (usually included with filter)
• 🔩 Oil drain plug washer (sealing washer) - Qty: 1 (optional but recommended)
• 🔩 Brake cleaner or parts cleaner spray - Qty: 1 can
• 🔩 Disposable gloves - Qty: 1 box
• 🔩 Shop towels - Qty: 1 pack

---

📋 Before You Begin

• Park your Escape on level ground, put the transmission in PARK, and set the parking brake.
• Place wheel chocks behind the rear tires so the vehicle cannot roll.
• Run the engine for 3–5 minutes so the oil is slightly warm; then shut it off. Warm oil drains faster.
• Gather all tools and parts and keep them within reach before jacking up the vehicle.
• Plan where you will take the used oil and filter (most auto parts stores in Los Angeles accept used oil for free).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the front of your Escape

• Use the floor jack (rated 3-ton minimum) to lift the front of the vehicle at the front center jacking point (behind the front bumper on the subframe).
• Place jack stands under the factory pinch welds or subframe on both sides, then slowly lower the vehicle onto the stands using the floor jack.
• Give the vehicle a firm shake by hand to make sure it is stable on the jack stands.
• Leave the wheel chocks in place at the rear wheels.

Step 2: Remove the lower engine splash shield

• Position your work light or flashlight so you can see under the front of the Escape.
• Use a flathead screwdriver to gently pry out the plastic push clips at the front of the splash shield.
• If there are small bolts present, remove them using the 13mm socket and 3/8" drive ratchet.
• Lower the splash shield and set it aside where you won’t step on it.

Step 3: Position the drain pan

• Locate the oil pan at the bottom of the engine; the oil drain plug is at the rear of the pan.
• Slide the oil drain pan (at least 8-quart capacity) under the drain plug, slightly toward the rear of the vehicle because the oil will shoot out a bit.

Step 4: Remove the oil drain plug and drain the oil

• Put on your mechanic gloves and safety glasses.
• Use the 13mm socket and 3/8" drive ratchet to crack the drain plug loose, then finish removing it by hand.
• Let the oil drain completely into the oil drain pan for at least 5–10 minutes until it becomes a slow drip.
• Inspect the drain plug and washer; replace the oil drain plug washer if it’s damaged or flattened.

Step 5: Reinstall the oil drain plug

• Install the drain plug (with new washer if used) by hand first to avoid cross-threading.
• Use the 13mm socket and 3/8" drive ratchet to snug it down.
• Use the 3/8" drive torque wrench with the 13mm socket to tighten the plug to 30 Nm (22 ft-lbs).
• Wipe any spilled oil off the oil pan with shop rags and, if needed, a little brake cleaner.

Step 6: Remove the oil filter housing

• Locate the oil filter housing from underneath; on the 2.0L EcoBoost it is a black plastic or metal cap pointing downward near the front of the engine.
• Position the oil drain pan under the oil filter area to catch any extra oil.
• Place the 74mm, 14-flute oil filter cap/socket wrench (specialty) on the filter housing cap and turn it counterclockwise using the 3/8" drive ratchet.
• Once loose, spin the cap off by hand and lower it straight down; the old filter cartridge will come out with it.
• Let any remaining oil drain into the pan.

Step 7: Replace the oil filter and O-ring

• Pull the old filter cartridge off the filter cap by hand and discard it into the oil drain pan.
• Use a flathead screwdriver gently to lift the old O-ring off the groove of the filter cap. Be careful not to scratch the cap.
• Lightly coat the new O-ring with a bit of fresh engine oil from a bottle (use your finger) and install it in the same groove on the filter cap.
• Push the new oil filter cartridge onto the filter cap until it snaps in place.

Step 8: Reinstall the oil filter housing

• Insert the filter and cap assembly back up into the housing and start threading it by hand to avoid cross-threading.
• Once it is hand-tight, use the 74mm, 14-flute oil filter cap/socket wrench (specialty) and 3/8" drive ratchet to snug it down.
• Switch to the 3/8" drive torque wrench with the same filter cap socket and tighten the cap to 25 Nm (18 ft-lbs).
• Wipe off any oil around the filter housing with shop rags.

Step 9: Reinstall the lower engine splash shield

• Lift the splash shield back into position under the engine.
• Install the push clips by hand, pressing them firmly into the holes.
• If your Escape has small bolts, install them using the 13mm socket and 3/8" drive ratchet and snug them; do not overtighten.

Step 10: Lower the vehicle

• Use the floor jack to raise the front of the vehicle slightly off the jack stands.
• Remove the jack stands and then carefully lower the vehicle to the ground with the floor jack.
• Remove the wheel chocks from the rear wheels.

Step 11: Add new engine oil

• Open the hood and locate the oil filler cap on top of the engine; it will say “SAE 5W-30”.
• Twist the cap off by hand and set it aside.
• Place the plastic funnel in the filler opening.
• Pour in about 5.25 quarts of 5W-30 full synthetic engine oil to start (the full capacity is about 5.7 quarts).
• Reinstall the oil filler cap by hand.

Step 12: Start the engine and check for leaks

• Start the engine and let it idle for about 30–60 seconds.
• While it runs, look underneath with your work light to check around the oil drain plug and oil filter housing for any leaks.
• If you see drips, shut off the engine and gently snug that connection using the appropriate socket and 3/8" drive ratchet, then recheck.
• Shut off the engine and wait 3–5 minutes for the oil to settle back into the oil pan.

Step 13: Check and top off the oil level

• Pull out the engine oil dipstick (yellow handle), wipe it clean with a shop rag, and push it fully back in.
• Pull it out again and check the oil level. It should be between the “MIN” and “MAX” marks, ideally near the top mark.
• If needed, add oil in small amounts (about 0.1–0.2 quarts) using the plastic funnel, then recheck the dipstick until you are right near the “MAX” mark without going over.

Step 14: Reset the oil change reminder (instrument cluster)

• Turn the ignition to ON without starting the engine (press the start button without pressing the brake).
• Use the steering wheel buttons to go to Menu > Settings > Vehicle > Oil Life Reset on the instrument cluster screen.
• Select Oil Life Reset, then choose OK or Reset and confirm when asked.
• Turn the ignition off, then back on to verify the oil life shows 100%.

---

✅ After Repair

• Drive your Escape for 5–10 minutes and then park on level ground.
• Recheck under the engine for any fresh oil drips from the drain plug or oil filter housing.
• Recheck the oil level with the dipstick and top off if necessary.
• Make a note of the mileage and date so you know when the next oil change is due.

---

💰 DIY vs Shop Cost

Shop Cost: $120–$180 (parts + labor) in Los Angeles

DIY Cost: $45–$80 (oil + filter + small supplies)

You Save: $40–$135 by doing it yourself!

Shop labor rates vary but typically run $120–$160/hour in your area. This repair takes a shop approximately 0.5–0.8 hours.

---
