🔧 Camry - Engine Oil & Oil Filter Change

This job drains the old engine oil and replaces the cartridge-style oil filter element so your engine stays properly lubricated and clean. On your Camry, the filter sits in a housing under the front of the engine, so you’ll remove a small under-cover to access it.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat surface and support the car with jack stands before going underneath.
• ⚠️ Hybrid safety: Make sure the car is OFF (not in READY). Keep the key fob away from the car so it can’t wake up.
• ⚠️ Hot oil can burn—let the engine cool 15–30 minutes if it was just running.
• ⚠️ Wear gloves and safety glasses; oil will splash when the drain plug comes out.
• ⚠️ Do not overtighten the oil filter housing—its threads can be damaged.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart)
• Funnel
• Shop towels
• 10mm socket
• Ratchet
• 3/8" drive extension
• 14mm socket
• Torque wrench (10-80 ft-lb range)
• 64mm 14-flute oil filter cap wrench (specialty)
• Oil filter housing drain tool (specialty)
• Trim clip removal tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 5 quarts
• Oil filter element (cartridge type) - Qty: 1
• Oil filter housing O-ring set - Qty: 1
• Engine oil drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to P, and apply the parking brake.
• Place wheel chocks behind the rear wheels.
• Confirm the vehicle is fully OFF (not READY). Keep the key fob 10+ feet away.
• Gather your oil and filter parts so you’re not climbing out mid-job.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front of the car

• Use a floor jack (rated 3-ton minimum) at the front center jacking point to lift the front.
• Set the car down onto jack stands (rated 3-ton minimum) at the proper support points.
• Give the car a gentle shake to confirm it’s stable before you go underneath.

Step 2: Remove the front under cover (access panel)

• Use a 10mm socket and ratchet to remove the bolts holding the access panel.
• Use a trim clip removal tool to pop any plastic clips without breaking them.
• Set the bolts/clips aside in a small tray so they don’t get lost.

Step 3: Drain the engine oil

• Slide a drain pan (at least 8-quart) under the oil pan drain plug.
• Use a 14mm socket with a ratchet to loosen and remove the drain plug.
• Let the oil fully drain (usually 5–10 minutes). Warm oil drains faster.
• Install a new engine oil drain plug gasket on the drain plug.
• Reinstall the drain plug by hand first, then tighten with a torque wrench: Torque to 40 Nm (30 ft-lb).

Step 4: Drain the oil filter housing (reduces mess)

• Move the drain pan under the oil filter housing.
• Use the oil filter housing drain tool (specialty) to open the small drain in the housing and let it drain.
• Once it stops dripping, remove the drain tool and wipe the area with shop towels.

Step 5: Remove the oil filter housing and replace the filter element

• Use a 64mm 14-flute oil filter cap wrench (specialty) with a ratchet to loosen the filter housing.
• Lower the housing carefully—there will still be some oil inside.
• Pull the old filter element out of the housing by hand and discard it.
• Remove the old O-ring(s) from the housing and install the new O-ring(s) from the oil filter housing O-ring set.
• Lightly coat the new O-ring(s) with fresh 0W-20 so they don’t pinch during tightening.
• Install the new filter element into the housing.
• Reinstall the filter housing by hand first, then tighten with a torque wrench: Torque to 25 Nm (18 ft-lb).

Step 6: Reinstall the under cover

• Position the access panel/under cover back in place.
• Use a 10mm socket and ratchet to reinstall the bolts.
• Reinstall any clips using the trim clip removal tool to align them, then press them in.

Step 7: Refill with new oil

• Lower the car off the jack stands using the floor jack.
• Open the hood and remove the oil fill cap.
• Use a funnel and add 0W-20 full synthetic (start with about 4.0 quarts).
• Reinstall the oil fill cap.

Step 8: Start, check for leaks, and set the oil level

• Start the car and let it run briefly (the gasoline engine may cycle on/off—this is normal for a hybrid).
• Shut the car OFF and wait 5 minutes for oil to drain back into the pan.
• Check underneath for leaks at the drain plug and filter housing.
• Check the dipstick and top off as needed (add small amounts). Don’t overfill.

Step 9: Reset the maintenance reminder (if it’s on)

• Set the display to ODO using the trip button (not Trip A/Trip B) if your cluster supports it.
• With your foot OFF the brake, press the POWER button twice to ignition ON (not READY).
• Press and hold the trip/odo button until the display resets.

---

✅ After Repair

• Recheck the dipstick the next morning (cold) and adjust if needed.
• Dispose of used oil and the old filter at an oil recycling location—most parts stores accept it.
• If you notice any drip marks on the driveway, inspect the drain plug gasket and filter housing O-ring seating.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $55-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
