🔧 Sedona - Engine Oil & Oil Filter Change

Changing the engine oil and oil filter keeps your A4’s engine lubricated, clean, and protected from wear. You’ll drain the old oil, replace the filter (which traps contaminants), and refill with the correct oil.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the van with jack stands, not just a jack.
• ⚠️ Engine oil can be hot; let the engine cool 15–30 minutes before draining.
• ⚠️ Wear nitrile gloves and safety glasses; oil can irritate skin and eyes.
• ⚠️ Keep oil off the exhaust and drive belts to prevent smoke/odors.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 8-quart capacity)
• Funnel
• 17mm socket
• 3/8" drive ratchet
• Torque wrench (10-80 ft-lbs range)
• Oil filter wrench (cap or band style)
• Trim clip remover
• 10mm socket
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (5W-30 full synthetic) - Qty: 6 quarts
• Engine oil filter - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Warm the engine for 2–3 minutes (oil drains faster), then shut it off and let it cool 15–30 minutes.
• Open the hood and remove the oil fill cap (this helps the oil drain smoothly).
• Tip: Lay cardboard under the engine for easy cleanup.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and safely support the van

• Use a floor jack (rated 3-ton minimum) to lift the front at the approved front jacking point.
• Set the van onto jack stands (rated 3-ton minimum) placed at the front support points.
• Give the van a gentle push to confirm it’s stable before going underneath.

Step 2: Remove the lower splash shield (if equipped)

• Use a 10mm socket and 3/8" drive ratchet to remove the bolts.
• Use a trim clip remover to pop out plastic clips without breaking them. (A trim clip remover is a fork-shaped tool made to pry clips safely.)
• Set the shield and hardware aside in a small pile so nothing gets lost.

Step 3: Drain the old engine oil

• Place the drain pan (at least 8-quart capacity) under the oil pan drain plug.
• Use a 17mm socket and 3/8" drive ratchet to loosen the drain plug, then finish removing it by hand.
• Let the oil drain until it slows to an occasional drip (usually 5–10 minutes).
• Remove the old crush washer from the drain plug and install the new oil drain plug crush washer.
• Reinstall the drain plug by hand first (prevents cross-threading), then tighten with a torque wrench: Torque to 39 Nm (29 ft-lbs).

Step 4: Remove the old oil filter

• Move the drain pan under the oil filter area (some oil will spill).
• Use an oil filter wrench to loosen the filter, then spin it off by hand.
• Use shop rags to wipe the filter mounting surface clean.
• Make sure the old rubber gasket came off with the old filter (a stuck gasket will cause a serious leak).

Step 5: Install the new oil filter

• Put a small film of fresh oil on the new filter’s rubber gasket using a gloved finger.
• Thread the new filter on by hand until the gasket touches the engine, then tighten an additional 3/4 turn by hand.
• Tip: Hand-tight is correct—don’t crank it down.

Step 6: Reinstall the splash shield

• Reposition the shield and install clips by hand first.
• Use a 10mm socket and 3/8" drive ratchet to snug the bolts.

Step 7: Refill with fresh oil

• Lower the van back to the ground using the floor jack (rated 3-ton minimum).
• Insert a funnel into the oil fill opening.
• Pour in about 5.5 quarts of 5W-30 full synthetic first.
• Reinstall the oil fill cap.

Step 8: Start, check for leaks, then set the oil level

• Start the engine and let it idle for 30–60 seconds.
• Shut the engine off and wait 5 minutes for oil to drain back to the pan.
• Check underneath for leaks at the drain plug and oil filter.
• Check the dipstick, then add oil in small amounts until it reaches the full mark (typical total fill is about 5.8 quarts (5.5 L) with filter).
• Use shop rags to wipe any spilled oil.

---

✅ After Repair

• Recheck the dipstick after a short 5–10 minute drive and top off if needed.
• Make sure there are no drips under the van after it sits for a few minutes.
• Reset the service reminder (common cluster method): use steering wheel buttons to go to User Settings > Service Interval > Reset if your cluster supports it.
• Dispose of used oil and the old filter properly (most parts stores accept them for recycling).

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$75 (parts only)

You Save: $55-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
