🔧 Engine Oil & Oil Filter - Replacement

Changing the oil and filter on your Tacoma keeps the engine clean, lubricated, and protected from wear. The 3.5L uses a cartridge-style oil filter, so you’ll change the filter element inside the housing instead of a spin-on canister.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Let the engine cool before draining oil. Hot oil can burn skin fast.
• Support the truck securely with jack stands before going underneath.
• Do not work under a vehicle supported only by a jack.
• Wipe up any oil spills right away to prevent slips.
• Used oil must be collected in a drain pan and recycled properly.
• No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 3/8-inch ratchet
• Oil filter housing socket
• Torque wrench
• Drain pan
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Funnel
• Shop towels
• Latex or nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 0W-20 full synthetic) - Qty: 6.2 quarts
• Oil filter element - Qty: 1
• Oil filter housing O-ring - Qty: 1
• Drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Chock the rear wheels before lifting the front.
• Warm oil drains faster, but do not make it hot enough to burn you.
• Have the new oil, filter, and washer ready before starting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the truck

• Use a floor jack to raise the front of your Tacoma at the proper lift point.
• Place jack stands under the frame and lower the truck onto them.
• Verify the truck is stable before getting underneath.

Step 2: Remove the drain plug

• Place the drain pan under the oil pan.
• Use the 14mm socket and 3/8-inch ratchet to loosen and remove the drain plug.
• Let the oil drain completely.
• Install a new drain plug crush washer on the plug.
• Torque to 30 Nm (22 ft-lbs).

Step 3: Remove the oil filter housing

• Move the drain pan under the oil filter housing.
• Use the oil filter housing socket to loosen the housing cap.
• Remove the housing and let any oil drain out.
• Take out the old filter element and remove the old O-ring.
• Keep the O-ring groove clean.

Step 4: Install the new filter and O-ring

• Install the new oil filter element into the housing.
• Lightly coat the new oil filter housing O-ring with clean engine oil.
• Install the O-ring in the correct groove on the housing.
• Thread the housing back in by hand first to avoid cross-threading.
• Use the torque wrench with the oil filter housing socket and Torque to 25 Nm (18 ft-lbs).

Step 5: Reinstall the drain plug

• Reinstall the drain plug with the new washer.
• Use the 14mm socket and torque wrench.
• Torque to 30 Nm (22 ft-lbs).

Step 6: Refill with engine oil

• Lower the truck back to level ground.
• Remove the oil filler cap and use a funnel to add about 6 quarts of SAE 0W-20 full synthetic.
• Start the engine and let it idle for 30 seconds.
• Shut the engine off and wait 5 minutes.
• Check the dipstick and add oil in small amounts until the level is near the full mark.
• Total capacity is about 6.2 quarts with the filter.

Step 7: Check for leaks and reset

• Inspect the drain plug and filter housing for leaks.
• Check the oil level again after a short idle and top off if needed.
• Reset the maintenance reminder if your Tacoma is equipped with one.

---

✅ After Repair

• Drive a few miles and confirm the oil warning light stays off.
• Recheck the oil level on level ground after the engine sits.
• Look underneath for any fresh drips.
• Recheck the drain plug and filter housing after the first drive if you want extra peace of mind.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $55-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
