🔧 Engine Oil & Oil Filter - Change

Changing the oil and filter on your XC90 keeps the turbo/supercharged engine lubricated and helps protect the timing and valve-train components. This is a straightforward service if you can safely lift the vehicle and keep the oil level within spec.

Difficulty Level: Beginner | Estimated Time: 1.0-1.5 hours

---

⚠️ Safety & Precautions

• Work on a cool engine to avoid burns from hot oil and exhaust parts.
• Use jack stands on a level surface; never rely on the jack alone.
• The engine oil can be very hot if the vehicle was recently driven.
• Keep dirt away from the oil filter housing and filler opening.
• Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 36mm oil filter cap socket
• 3/8-inch ratchet
• 17mm socket
• Torque wrench
• Drain pan
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Funnel
• Oil filter drain tool (specialty)
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 0W-20 synthetic - Qty: 6.7 quarts
• Oil filter cartridge - Qty: 1
• Oil filter housing O-ring set - Qty: 1
• Drain plug washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool fully before opening the oil system.
• If your XC90 has an oil life reminder, note the current service interval before resetting it.
• Gather all parts first so the oil filter housing does not sit open.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the vehicle

• Use the floor jack to lift the front of the vehicle at the approved lift points.
• Place the vehicle on jack stands and chock the rear wheels.
• Make sure the vehicle is stable before going underneath.

Step 2: Remove the lower splash shield

• Use the 3/8-inch ratchet with the correct fastener tool for the shield fasteners if equipped.
• Remove the lower engine cover or splash shield to access the drain plug and oil filter area.
• Set all fasteners aside in order.

Step 3: Drain the engine oil

• Place the drain pan under the oil pan drain plug.
• Use the 17mm socket to loosen and remove the drain plug.
• Let the oil drain completely. This can take several minutes.
• Install a new drain plug washer on the plug.
• Reinstall the drain plug and tighten to 35 Nm (26 ft-lbs).

Step 4: Remove the oil filter

• Move the drain pan under the oil filter housing.
• Use the 36mm oil filter cap socket to loosen the filter housing cap.
• Remove the cap and old filter cartridge together.
• Use the oil filter drain tool (specialty) if needed to keep oil from spilling during removal.

Step 5: Replace the filter element and seals

• Pull the old filter cartridge off the cap.
• Remove the old O-rings from the cap carefully.
• Install the new O-rings from the oil filter housing O-ring set.
• Lightly oil the new O-rings with clean engine oil.
• Install the new filter cartridge on the cap.
• Lightly oiling the seals helps prevent tearing.

Step 6: Install the new filter

• Thread the filter housing cap back in by hand first.
• Use the 36mm oil filter cap socket and torque wrench to tighten to 25 Nm (18 ft-lbs).
• Do not overtighten the plastic filter housing cap.

Step 7: Refill the engine with oil

• Lower the vehicle enough to access the oil filler if needed, or refill from the top with a funnel.
• Add about 6.0 quarts first, then top off gradually.
• Use only 0W-20 synthetic oil that meets Volvo specification.
• Do not overfill.

Step 8: Check the oil level

• Start the engine and let it idle for 30-60 seconds.
• Shut it off and wait a few minutes for the oil to settle.
• Check the level using the vehicle’s electronic oil level display.
• Top off in small amounts until the level reaches the correct range.

Step 9: Reinstall the splash shield

• Use the 3/8-inch ratchet to reinstall the lower engine cover.
• Make sure all fasteners are secured.
• Lower the vehicle from the jack stands.

Step 10: Reset the service reminder

• On the center display, go to Vehicle > Status > Service if the reminder is shown there.
• Complete the oil change reminder reset as prompted on the screen.
• If your display wording differs, use the vehicle’s service reminder reset menu before driving.

---

✅ After Repair

• Check under the vehicle for leaks around the drain plug and filter housing.
• Recheck the oil level after a short drive and after the engine sits for a few minutes.
• Make sure the service reminder is cleared.
• Dispose of used oil and filter at a proper recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $140-$240 (parts + labor)

DIY Cost: $55-$95 (parts only)

You Save: $85-$145 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
