🔧 550i - Engine Oil & Oil Filter Replacement

You’ll drain the old engine oil, replace the oil filter cartridge and seals, then refill with fresh BMW-approved oil. This keeps the turbo V8 properly lubricated and helps prevent timing chain, turbo, and bearing wear.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

Assumption: cartridge-style oil filter housing and single sump drain plug.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the car with jack stands, not just a jack.
• ⚠️ Hot oil can burn you; let the engine cool 10–20 minutes before draining.
• ⚠️ Keep oil off belts, hoses, and the exhaust to avoid smoke/fire risk.
• ⚠️ Do not crawl under the car unless it is stable and chocked.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (15-quart minimum)
• Funnel
• Torque wrench (10–60 Nm range)
• 17mm socket
• 36mm socket
• 3/8" drive ratchet
• 6" extension (3/8" drive)
• 8mm socket
• Trim clip remover
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil filter kit (cartridge + O-rings) - Qty: 1
• Oil drain plug crush washer - Qty: 1
• Engine oil (BMW Longlife-approved full synthetic, typically 5W-30) - Qty: 10 quarts

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Warm the engine for 5–10 minutes, then shut it off and wait 10–20 minutes so the oil is warm (drains well) but safer.
• Open the hood and remove the oil filler cap (this helps the oil drain faster).
• Plan your oil-level check: your 550i measures oil electronically through iDrive after the refill.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front of the car

• Use a floor jack to lift the front jack point, then place the car on jack stands.
• Use wheel chocks to prevent rolling.
• Give the car a firm shake test.

Step 2: Remove the lower splash shield (undertray)

• Place your drain pan (15-quart minimum) under the engine area.
• Use an 8mm socket to remove the undertray screws.
• Use a trim clip remover for any plastic push-clips.
• Set the fasteners aside so none are lost.

Step 3: Drain the engine oil

• Locate the oil drain plug on the bottom of the oil pan.
• Use a 17mm socket with a 3/8" drive ratchet to loosen the drain plug.
• Finish removing the plug by hand and let the oil drain into the drain pan.
• Remove the old crush washer and install the new oil drain plug crush washer.
• Reinstall the drain plug by hand first (to avoid cross-threading), then use a torque wrench and 17mm socket: Torque to 25 Nm (18 ft-lbs).

Step 4: Replace the oil filter cartridge and O-rings

• Find the oil filter housing at the top of the engine (it has a cap that takes a large socket).
• Use a 36mm socket with a 3/8" drive ratchet and 6" extension (3/8" drive) to loosen the filter cap slowly.
• Lift the cap and filter out together, keeping it upright to reduce spills; use shop rags to catch drips.
• Pull the old filter cartridge off the cap (it snaps on) and push the new cartridge on until it seats.
• Replace the cap O-ring(s) from the oil filter kit.
• Use a shop rag to wipe the housing sealing surface clean.
• Reinstall the filter cap and tighten with a torque wrench and 36mm socket: Torque to 25 Nm (18 ft-lbs).
• Tool note: a torque wrench helps prevent cracking the plastic cap (tighten to spec only).

Step 5: Reinstall the undertray

• Position the undertray back in place.
• Use an 8mm socket to reinstall the screws and the trim clip remover to press clips back in as needed.
• Snug fasteners evenly (do not overtighten plastic hardware).

Step 6: Refill with fresh oil

• Insert a funnel into the oil fill opening.
• Pour in 9.5 quarts first (don’t dump all 10 quarts immediately).
• Reinstall the oil filler cap.
• Start the engine and let it idle for 30–60 seconds, then shut it off.
• Check underneath for leaks at the drain plug and around the filter housing using safety glasses and shop rags.

Step 7: Check oil level using iDrive and top off

• With the car on level ground, bring the engine to operating temperature (short drive helps).
• On iDrive, go to My Vehicle > Vehicle status > Measure engine oil level (wording may vary slightly).
• Follow the prompts; the car will display the oil level electronically (there is no dipstick on most setups).
• If low, add oil in small amounts (about 0.25 quart at a time) using a funnel, then re-measure.
• Small top-offs prevent overfilling.

Step 8: Reset the engine oil service reminder

• Turn ignition on (engine off). Press the start button without pressing the brake.
• Press and hold the trip odometer reset button until the service menu appears.
• Use short presses of the trip reset button to scroll to Engine oil.
• Press and hold the trip reset button to confirm reset.

---

✅ After Repair

• Recheck for leaks after your first 10–15 minute drive.
• Verify the oil level again through iDrive: My Vehicle > Vehicle status > Measure engine oil level.
• Dispose of used oil and the old filter at an oil-recycling drop-off location (many auto parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $200-$350 (parts + labor)

DIY Cost: $90-$160 (parts only)

You Save: $110-$190 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
