🔧 Rogue - CVT Transmission Fluid Drain & Fill

This guide covers a drain-and-fill of the CVT transmission fluid on your Rogue, which is the safest DIY method and is what most shops do unless using a dedicated machine. You’ll drain the old fluid from the pan, refill with fresh Nissan-approved CVT fluid, then verify the level.

Difficulty Level: Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• ⚠️ Always support the vehicle with jack stands. Never rely only on a floor jack.
• ⚠️ Transmission fluid can be hot. Let the engine and transmission cool before draining.
• ⚠️ Keep the engine in Park, parking brake on, and wheels chocked whenever you’re under the vehicle.
• ⚠️ The CVT is sensitive. Use only Nissan NS-3 CVT fluid or fluid that explicitly states NS-3 compatibility.
• ⚠️ Work in a well-ventilated area and keep fluid away from skin and eyes.
• ⚠️ Do not drive the Rogue if the transmission is underfilled or overfilled—this can cause damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (rated 3-ton minimum, Qty: 2–4)
• 🛠️ Wheel chocks
• 🛠️ Drain pan (at least 10-quart capacity)
• 🛠️ Ratchet handle (3/8" drive)
• 🛠️ Torque wrench (10–100 Nm range)
• 🛠️ 10mm socket
• 🛠️ 12mm socket
• 🛠️ 17mm socket
• 🛠️ 8mm hex bit socket
• 🛠️ Phillips screwdriver
• 🛠️ Flathead screwdriver
• 🛠️ Plastic trim clip tool
• 🛠️ Long-neck funnel with flexible hose
• 🛠️ Fluid transfer pump (hand pump) (specialty)
• 🛠️ OBD2 scan tool with live data (trans temp) (specialty)
• 🛠️ Shop rags
• 🛠️ Nitrile gloves
• 🛠️ Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Nissan NS-3 CVT fluid - Qty: 6–7 quarts (drain-and-fill)
• 🔩 CVT drain plug crush washer - Qty: 1
• 🔩 CVT level/check plug crush washer - Qty: 1
• 🔩 Brake cleaner spray - Qty: 1 can
• 🔩 Disposable shop towels - Qty: 1 pack

---

📋 Before You Begin

• 🔹 Park the Rogue on a level surface, set the parking brake, and chock the rear wheels.
• 🔹 You do not need to disconnect the battery for this job.
• 🔹 Plan to measure how much fluid drains out so you can put about the same amount back in.
• 🔹 If you have an OBD2 scan tool with live data, locate the transmission fluid temperature PID before you start.
• 🔹 Wear gloves and safety glasses to protect your skin and eyes from fluid.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the Rogue

• Use the floor jack to lift the front of the Rogue at the front jacking point (center of front crossmember).
• Place jack stands under the left and right front pinch welds (sides under the doors) and gently lower the vehicle onto them with the floor jack.
• Make sure the Rogue is stable by giving it a light shake before going underneath.

Step 2: Remove the engine under-cover

• Use the 10mm socket and Phillips screwdriver to remove the bolts and screws holding the plastic splash shield under the engine and transmission.
• Use the plastic trim clip tool to pop out any plastic push clips.
• Remove the under-cover and set it aside where you won’t step on it.

Step 3: Locate CVT drain and level plugs

• The CVT pan is on the driver side of the engine bay area, toward the front, visible from underneath.
• Identify the main drain plug (larger hex head, usually 17mm) at the bottom of the pan.
• Identify the level/check plug (smaller internal hex, use the 8mm hex bit socket) usually near the drain but offset.
• Clean the area with brake cleaner before opening plugs.

Step 4: Drain the old CVT fluid

• Position the drain pan under the CVT drain plug.
• Use the 17mm socket and ratchet to loosen and remove the drain plug carefully.
• Let the fluid drain completely into the pan. This can take several minutes.
• Once drained, pour the fluid from the drain pan into a clean, marked container to measure the exact amount removed.
• Write down the amount you drained.

Step 5: Reinstall the CVT drain plug

• Install a new drain plug crush washer onto the drain plug.
• Thread the drain plug in by hand to avoid cross-threading.
• Use the 17mm socket and torque wrench to tighten the drain plug to 34 Nm (25 ft-lbs).
• Spray a bit of brake cleaner on the area and wipe clean with shop rags.

Step 6: Access the CVT fill point (air box removal)

• From the top of the engine bay, loosen the air intake hose clamp using a flathead screwdriver or 10mm socket.
• Unplug the mass airflow sensor electrical connector by hand.
• Use the 10mm socket to remove the bolts holding the air filter box.
• Lift out the air intake duct and air filter box to expose the top of the transmission.
• Locate the CVT vent/fill port (a plastic cap on top of the transmission). Pry the cap off gently with a flathead screwdriver.

Step 7: Add new CVT fluid (initial fill)

• Insert the long-neck funnel with flexible hose into the CVT vent/fill port.
• Pour in the same amount of new NS-3 fluid you measured coming out, using the funnel.
• Go slowly to avoid spilling and allow air to escape.
• Once done, leave the funnel in place for now in case you need to add more later.

Step 8: Warm up the CVT fluid

• Reinstall the air box loosely (or just reconnect the intake hose firmly) so you can safely run the engine. Use the 10mm socket for bolts and flathead screwdriver for the clamp.
• Lower the Rogue just enough that the front wheels are still off the ground and it’s level on the jack stands.
• Start the engine with your foot on the brake and let it idle.
• Slowly move the shifter through P-R-N-D-L, pausing 3–5 seconds in each position, then back to Park. Do this 2–3 times to circulate the fluid.
• If you have a OBD2 scan tool with live data, monitor transmission fluid temperature and aim for 35–45°C (95–113°F).
• If you do not have a scan tool, idle for about 10–15 minutes; the transmission should reach a similar warm range, but this is less precise.

Step 9: Check and set the fluid level (with level plug)

• With the engine still idling, parking brake on, and shifter in Park, slide back under the Rogue.
• Place the drain pan under the CVT level/check plug.
• Use the 8mm hex bit socket and ratchet to carefully loosen and remove the level/check plug.
• If fluid pours out in a steady stream, let it drain until it becomes a thin drip, then the level is correct.
• If no fluid comes out, the level is low:
  • Reinstall the level plug loosely with the 8mm hex bit socket.
  • Go back up top and add 0.25–0.5 quart of fluid via the funnel.
  • Wait 1–2 minutes, then remove the level plug again and see if fluid begins to drip out.
  • Repeat small additions until you get a thin drip with engine idling.
• Once you have a thin drip at the correct temperature, install a new level plug crush washer and tighten the level plug to 8 Nm (71 in-lbs) using the torque wrench and 8mm hex bit socket.

Step 10: Final reassembly

• Turn off the engine.
• Securely reinstall the air box and intake duct using the 10mm socket and flathead screwdriver. Reconnect the mass airflow sensor connector by hand.
• Reinstall the under-cover using the 10mm socket, Phillips screwdriver, and plastic trim clip tool for any clips.
• Use brake cleaner and shop rags to clean any spilled fluid from the transmission pan and surrounding areas.

Step 11: Lower the Rogue and road test

• Use the floor jack to raise the Rogue slightly, remove the jack stands, and lower it to the ground.
• Take a short test drive of 10–15 minutes, including light acceleration and a few gentle stops.
• Listen and feel for any unusual noise, shudder, or slipping.
• After the drive, check under the Rogue for leaks around the drain and level plugs.

---

✅ After Repair

• 🔹 Recheck the area under the Rogue over the next day or two for any fresh fluid drips.
• 🔹 If you have a scan tool, you can later recheck the fluid level at the correct temperature using the same level plug procedure.
• 🔹 Note the mileage and date; plan to repeat a CVT drain-and-fill every 40,000–60,000 miles if you want extra protection (even if Nissan says “lifetime”).
• 🔹 Dispose of old CVT fluid at a recycling center or parts store that accepts used oil/fluids.

---

💰 DIY vs Shop Cost

Shop Cost: $260–$420 (parts + labor)

DIY Cost: $90–$160 (parts only)

You Save: $170–$260 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
