🔧 Soul - Automatic Transmission Fluid Change (Drain & Fill)

Your Soul can be equipped with either a dipstick-style transmission (easy level check) or a “sealed” transmission (level is set through a side level/check plug at a specific fluid temperature). The exact procedure, plug locations, and torque specs depend on which one you have.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Hot fluid burn risk: let the transmission cool before opening plugs.
• ⚠️ Support the Soul level on jack stands; level fluid checks are inaccurate if the car isn’t level.
• ⚠️ Never get under a car supported only by a jack.
• ⚠️ Keep the engine off unless a step explicitly says to run it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• Socket set (10mm-24mm)
• 3/8" drive ratchet
• Torque wrench (10-100 ft-lbs range)
• Trim clip remover
• Fluid transfer pump (specialty)
• Shop rags
• Brake cleaner spray
• Infrared thermometer (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Kia/Hyundai SP-IV equivalent) - Qty: 4-5 quarts
• Transmission drain plug crush washer - Qty: 1
• Fill plug O-ring or washer (if equipped) - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and place wheel chocks behind the rear tires.
• Raise the front and support on jack stands, then raise the rear so the Soul sits level.
• Two quick questions so I can give you the exact correct steps + torque specs:
  • Do you have a transmission dipstick under the hood (yes/no)?
  • Do you have a way to read ATF temperature (scan tool) or will you use an infrared thermometer?
• A “sealed” transmission requires a temperature-based level check.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm which level-check style you have

• Open the hood and look for a transmission dipstick (usually has a colored handle).
• If there is no dipstick, your Soul uses a sealed level-check method (it will have a fill plug and a level/check plug on the transmission case).
• Use a flashlight (or good lighting) to visually locate the transmission case plugs before you drain anything.

Step 2: Remove the lower splash shield (if equipped)

• Use a trim clip remover to pop plastic clips.
• Use a 10mm socket and ratchet to remove any bolts.
• Set all clips/bolts aside in a tray so none get lost.

Step 3: Always loosen the fill point first

• Before draining, make sure you can open the fill plug or access the dipstick tube.
• Use the correctly-sized socket and ratchet to crack the fill plug loose (do not remove it yet).
• If you can’t fill it, don’t drain it.

Step 4: Drain the old fluid

• Place a 10-quart drain pan under the transmission drain plug.
• Use the correctly-sized socket and ratchet to remove the drain plug and washer.
• Let it drain until it slows to an occasional drip.
• Clean the drain plug area with shop rags and brake cleaner spray.

Step 5: Reinstall the drain plug with a new washer

• Install a new crush washer on the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use a torque wrench to tighten the drain plug to the correct factory spec.
• Torque spec note: I’ll give you the exact number once you confirm dipstick vs sealed (the spec differs by transmission/plug style).

Step 6: Refill with the correct ATF

• If sealed-style: use a fluid transfer pump (specialty) to pump SP-IV fluid into the fill port.
• If dipstick-style: add SP-IV through the dipstick tube using a pump/funnel setup.
• Add about what drained out as a starting point.

Step 7: Set the final fluid level (this is the “critical” part)

• If sealed-style: final level must be set with the transmission at a specific temperature, then the level/check plug is opened to confirm a proper dribble/stream.
• If dipstick-style: final level is checked on the dipstick using the correct temperature/engine-running condition.
• Important: I’ll give you the exact temperature target and the exact steps once you answer the 2 questions above.

---

✅ After Repair

• Reinstall the splash shield using the 10mm socket and trim clip remover.
• Wipe everything dry, then run the engine and check underneath for leaks.
• Test drive gently, then recheck for leaks again.
• Dispose of used ATF at a recycling center or auto parts store that accepts fluids.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $175-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
