🔧 Sorento - Automatic Transmission Fluid Change (Drain & Fill)

This service replaces a portion of your automatic transmission fluid by draining the pan and refilling with the correct Kia-spec ATF. It helps maintain smooth shifting and reduces wear, especially with city driving, towing, or high heat.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

Assumption: your Sorento uses the Kia 6-speed automatic with SP-IV fluid and a bottom drain + side fill/level check (common for this model).

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the SUV with jack stands, not just a jack.
• ⚠️ Transmission fluid can be hot; let it cool enough to avoid burns.
• ⚠️ Keep the vehicle level while checking/setting the final fluid level.
• ⚠️ Engine may need to run during level check; keep hands/clothes away from belts/fans.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (8-quart minimum)
• Funnel
• Fluid transfer pump (specialty)
• 10mm socket
• 12mm socket
• 17mm socket
• 24mm socket
• 3/8" drive ratchet
• 6" socket extension
• Torque wrench (10-100 Nm range)
• Trim clip remover
• OBD2 scan tool with live data (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Kia/Hyundai SP-IV) - Qty: 5-7 quarts
• Transmission drain plug crush washer - Qty: 1
• Transmission fill/level plug crush washer - Qty: 1
• Brake cleaner - Qty: 1
• Shop towels - Qty: 1 pack

---

📋 Before You Begin

• Park on a flat, level surface, set the parking brake, and chock the rear wheels.
• Warm the transmission with a 10-15 minute drive so the fluid drains more completely.
• Lift the front (or ideally all four corners) and set it securely on jack stands so the vehicle sits level.
• Plan to use an OBD2 scan tool to watch transmission fluid temperature; this is critical for an accurate final level check.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Put on safety glasses and nitrile gloves.
• Use a 10mm socket, 12mm socket, and trim clip remover to remove the fasteners holding the lower cover.
• Set the cover and fasteners aside in a small tray.

Step 2: Locate the transmission drain and fill/level plugs

• Place your drain pan (8-quart minimum) under the transmission pan area.
• Find the bottom drain plug (typically a larger hex head on the transmission pan) and the fill/level plug (often on the side of the transmission case).
• Always loosen the fill plug first.

Step 3: Crack the fill/level plug loose FIRST

• Use a 17mm socket with a 3/8" drive ratchet and 6" socket extension to loosen the fill/level plug.
• Do not remove it fully yet—just confirm it will come out. This prevents being stuck with an empty transmission you can’t refill.

Step 4: Drain the old transmission fluid

• Use a 24mm socket with a 3/8" drive ratchet to remove the drain plug.
• Let the fluid drain into the drain pan until it slows to a drip.
• Clean the drain plug with shop towels and brake cleaner.

Step 5: Reinstall the drain plug with a new crush washer

• Install a new transmission drain plug crush washer on the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Tighten using a torque wrench (10-100 Nm range): Torque to 45 Nm (33 ft-lbs).

Step 6: Refill with the correct ATF

• Remove the fill/level plug using the 17mm socket and 3/8" drive ratchet.
• Use a fluid transfer pump (specialty) to pump in automatic transmission fluid (Kia/Hyundai SP-IV).
• Add fluid until it starts to trickle back out of the fill/level opening.
• Reinstall the fill/level plug finger-tight for now (you’ll set the final level next).
• A fluid transfer pump is a hand pump that pushes fluid upward into side fill holes.

Step 7: Set the final fluid level at the correct temperature

• Plug in your OBD2 scan tool with live data (specialty) and monitor transmission fluid temperature (TFT).
• Start the engine and keep the vehicle on level jack stands with the parking brake set and wheels chocked.
• With your foot on the brake, slowly shift through P-R-N-D, pausing ~3 seconds in each gear, then return to P.
• With the engine idling, remove the fill/level plug using the 17mm socket.
• When TFT is around 50°C (122°F), the level is correct when a thin stream/drip comes out of the fill/level opening.
• If no fluid comes out, pump more SP-IV in using the fluid transfer pump (specialty) until it begins to drip.
• If a heavy stream pours out, wait until it slows to a drip at the target temperature.

Step 8: Reinstall the fill/level plug with a new crush washer

• Install a new transmission fill/level plug crush washer.
• Thread the plug in by hand, then tighten with a torque wrench (10-100 Nm range): Torque to 35 Nm (26 ft-lbs).
• Clean any spilled fluid using brake cleaner and shop towels so leaks are easy to spot later.

Step 9: Reinstall the splash shield and lower the vehicle

• Reinstall the lower cover using the 10mm socket, 12mm socket, and trim clip remover.
• Lower the SUV carefully using the floor jack (rated 3-ton minimum).

---

✅ After Repair

• Test drive 10-15 minutes and confirm shifts feel normal (no flare, no harsh engagement).
• Park on clean pavement and check for any fresh drips under the transmission.
• Recheck for leaks around the drain and fill/level plugs after the test drive.
• Save a sample of old fluid if problems appear.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$450 (parts + labor)

DIY Cost: $60-$140 (parts only)

You Save: $160-$310 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
