🔧 Pilot - Power Steering Pump Replacement

Your Pilot uses Electric Power Steering (EPS), so it does not have a hydraulic power steering pump or power steering fluid to replace. If you’re hearing a “pump whine” or the steering is heavy, the fix is usually in the EPS system (battery/charging, fuses, wiring, or the EPS steering rack).

Difficulty Level: Beginner (checks) / Advanced (EPS rack replacement) | Estimated Time: 0.5-1.5 hours (checks) / 6-10 hours (rack)

---

⚠️ Safety & Precautions

• ⚠️ Turn ignition OFF and remove the key/fob from the vehicle before working near the steering column.
• ⚠️ Disconnect the negative battery cable if unplugging EPS connectors or working near airbag wiring (yellow connectors = airbag circuits).
• ⚠️ If lifting the vehicle, support it with jack stands on solid ground; never rely on a jack alone.
• ⚠️ After any steering rack work, a professional alignment is required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench
• Trim clip remover
• Phillips screwdriver #2
• Flashlight
• Digital multimeter
• OBD2 scan tool with Honda EPS/ABS capability (specialty)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• EPS steering rack assembly - Qty: 1
• Outer tie rod ends - Qty: 2 (Replace in pairs)
• Steering rack mounting hardware kit - Qty: 1
• Front subframe bolt set - Qty: 1 (if required)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Center the steering wheel and keep it centered (don’t let it spin freely).
• If doing electrical checks, keep the battery connected until you reach the step that requires disconnecting it.
• Have your scan tool ready; EPS faults are best diagnosed by reading EPS codes (not just generic “Check Engine” codes).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm this is EPS (no pump/fluid)

• Open the hood and look for a power steering fluid reservoir—your Pilot will not have one because it’s EPS.
• If you were planning to “top off power steering fluid,” stop here—there’s no place to add it on this system.

Step 2: Check battery voltage (EPS is sensitive to low voltage)

• Use a digital multimeter at the battery terminals.
• Engine OFF: you want roughly 12.4–12.7V on a healthy battery.
• Engine running: you typically want ~13.5–14.8V charging voltage.
• Low voltage can mimic “pump” failure.

Step 3: Scan for EPS codes (this points to the real failed part)

• Plug in an OBD2 scan tool with Honda EPS/ABS capability (specialty). (This is a scan tool that can read EPS module codes, not just engine codes.)
• Read codes in the EPS system and save them.
• If you have an EPS warning light, codes are critical before replacing parts.

Step 4: Inspect EPS fuses and main connectors

• Turn ignition OFF.
• Disconnect the battery negative using a 10mm socket.
• Inspect EPS-related fuses in the under-hood fuse box (look for any marked for EPS/PGM/IGN). Use a flashlight.
• Check visible EPS wiring/connectors for looseness or corrosion. Do not probe yellow airbag connectors.

Step 5: If replacement is required, plan for EPS rack replacement (advanced)

• EPS rack replacement is a large job that may require lowering the front subframe and disconnecting steering/suspension components.
• Use a torque wrench and follow factory torque specs for: tie rod end nuts, rack bolts, intermediate shaft pinch bolt, and any subframe bolts. Torque to factory specification.
• After installation, you must get a 4-wheel alignment.
• Some repairs may require steering angle sensor/EPS calibration with a Honda-capable scan tool (specialty).

---

✅ After Repair

• Reconnect the battery using a 10mm socket and ensure the terminals are tight.
• Clear EPS codes with your Honda-capable scan tool (specialty) and recheck for returning codes.
• Start the engine and turn the wheel lock-to-lock slowly while parked to confirm assist feels smooth and consistent.
• If the steering wheel is off-center or it pulls, schedule an alignment immediately.

---

💰 DIY vs Shop Cost

Shop Cost: $1,500-$3,000 (parts + labor, EPS rack jobs vary a lot)

DIY Cost: $600-$1,600 (parts only, if you replace the rack)

You Save: $900-$1,400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 6-10 hours.

---
