🔧 RX350 - Timing Belt Replacement

Your RX350 does not use a timing belt. It uses a timing chain, which is lubricated by engine oil and is not a normal scheduled “replace it every X miles” item like a belt.

What you can DIY is confirming it’s chain-driven and checking for the common issues that lead to timing-chain service (oil leaks, low oil level, start-up rattles, and cam/crank timing codes).

Difficulty Level: Beginner (inspection) | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; hot parts can burn you.
• ⚠️ Keep hands/clothes away from the belt and fans if the engine is running.
• ⚠️ If you raise the vehicle, use jack stands on solid, level ground.
• ⚠️ Battery disconnect is not required for the inspection steps below.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Flashlight
• Telescoping inspection mirror
• OBD2 scan tool
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Trim clip removal tool
• 10mm socket
• 3/8" drive ratchet

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (0W-20 full synthetic) - Qty: 7 quarts
• Oil filter - Qty: 1
• Oil drain plug gasket - Qty: 1
• Engine air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Place wheel chocks behind the rear wheels.
• If you plan to look from underneath, lift the front with a floor jack and support with jack stands.
• Tip: Have a flashlight ready before removing clips.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm your RX350 is timing-chain driven

• Open the hood and use a flashlight to look at the front of the engine.
• On belt-driven engines, you typically see a large removable plastic “timing belt cover.” On your RX350, the timing drive is a timing chain inside the engine behind sealed covers, so there is no external belt to replace.
• Use a telescoping inspection mirror to check the tight spaces at the front of the engine.

Step 2: Check oil level and oil condition (most important for chain life)

• Pull the dipstick, wipe it, reinsert it fully, then pull again.
• If oil is below the safe range, top up with 0W-20 full synthetic (small amounts, recheck often).
• Dirty/sludged oil can accelerate timing-chain and tensioner wear. If the oil is very dark and thick, plan an oil change soon.

Step 3: Listen for timing-chain related noise on cold start

• With the hood open, start the engine and listen near the front/upper part of the engine.
• A brief “rattle” for 1-2 seconds can point to chain tensioner oil-drainback or wear. (A tensioner is a spring/oil-pressure device that keeps the chain tight.)
• If the noise is loud, lasts longer, or repeats often, avoid hard driving until it’s diagnosed.

Step 4: Scan for timing-related trouble codes

• Plug in an OBD2 scan tool and check for stored/pending codes.
• Codes like cam/crank correlation (often in the P0016–P0019 family) can indicate timing chain stretch, VVT issues, or sensor problems.
• Write down the exact code(s) and freeze-frame data if your scanner shows it.

Step 5: Inspect for oil leaks that can lead to chain/tensioner problems

• If raised, remove the front lower splash shield fasteners using a 10mm socket and trim clip removal tool.
• Use a flashlight to look for fresh oil around the front of the engine and along the lower edges of the engine covers.
• Oil leaks don’t directly “wear the chain,” but low oil level/pressure can cause real damage.

---

✅ After Repair

• Reinstall any splash shields and clips you removed using a 10mm socket.
• If you topped up oil, recheck the dipstick after a short drive and a 5-minute sit.
• If you found timing-related codes or persistent rattling, the next step is professional diagnosis; timing-chain replacement on the RX350 is an advanced job with special procedures.

---

💰 DIY vs Shop Cost

Shop Cost: $150-$350 (diagnosis/inspection) OR $2,000-$4,500 (timing chain service if needed)

DIY Cost: $0-$60 (basic inspection supplies) OR $50-$120 (oil change items if due)

You Save: $150-$350 by doing the initial checks yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours for diagnosis.

---
