🔧 Tundra - Timing Belt Replacement

Your Tundra’s 5.7L V8 does not use a timing belt. It uses a timing chain, which is lubricated by engine oil and typically does not have a routine replacement interval like a belt.

If you’re chasing a noise, check-engine light, or oil leak, the usual “timing belt job” equivalent is a timing chain/tensioner/guide service (advanced) or an inspection.

Difficulty Level: Advanced | Estimated Time: 10-16 hours

Assumption: Stock 5.7L timing chain setup (no prior modifications).

---

⚠️ Safety & Precautions

• 🛑 Work on a cold engine; hot coolant and metal can burn you.
• 🛑 Support the truck with jack stands on solid ground; never rely on a jack.
• 🛑 Disconnect the negative battery terminal before cranking/cover removal.
• 🛑 Keep hands clear of the fan area; remove the fan assembly before major front-engine work.
• 🛑 If you rotate the engine, rotate clockwise only using the crank bolt.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (10-quart minimum)
• Metric socket set 8mm-22mm
• Metric wrench set 8mm-22mm
• 1/2" drive breaker bar
• 1/2" drive torque wrench (high-range)
• 3/8" drive torque wrench (low-range)
• Ratchet extensions set
• Trim clip remover
• Flathead screwdriver
• Pliers set
• Hose clamp pliers
• Serpentine belt tool 14mm
• Fan clutch wrench set (specialty)
• Harmonic balancer puller kit (specialty)
• Crank pulley holding tool (specialty)
• Plastic razor scraper
• Brake cleaner spray
• Shop towels
• Paint marker
• Funnel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Timing chain - Qty: 1
• Timing chain guides - Qty: 1 set
• Timing chain tensioner - Qty: 1
• Timing cover sealant (Toyota FIPG equivalent RTV) - Qty: 1
• Front crankshaft seal - Qty: 1
• Engine coolant (Toyota Super Long Life equivalent) - Qty: 3-4 gallons premix
• Engine oil (0W-20 full synthetic) - Qty: 8 quarts
• Oil filter - Qty: 1
• Serpentine drive belt - Qty: 1
• Fresh hose clamps - Qty: 2-6

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and chock the rear wheels.
• Raise the front and support with jack stands under the frame.
• Disconnect the negative battery terminal using a 10mm socket.
• Place a drain pan under the radiator area for coolant draining.
• Take photos before removing hoses and connectors.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove lower covers and drain coolant

• Use a metric socket set to remove the front skid plate/splash shields.
• Place a drain pan under the radiator.
• Use pliers or hose clamp pliers to remove the lower radiator hose and drain coolant.

Step 2: Remove intake ducting and fan/shroud

• Use a flathead screwdriver and 8mm-10mm sockets to remove the intake tube and air ducting.
• Remove the upper fan shroud fasteners with a 10mm socket.
• Remove the mechanical fan and clutch using a fan clutch wrench set (specialty). Fan clutch wrench = thin wrench to fit tight nuts.

Step 3: Remove the serpentine belt and front accessories

• Use a serpentine belt tool 14mm to rotate the tensioner and remove the belt.
• Use a metric socket set and extensions to remove accessory brackets/components blocking the timing cover.
• Label connectors with a paint marker as you unplug them.

Step 4: Remove the crank pulley (harmonic balancer)

• Use a crank pulley holding tool (specialty) and a 1/2" drive breaker bar to loosen the crank bolt.
• Remove the pulley using a harmonic balancer puller kit (specialty). Puller = tool that presses the pulley off safely.
• Do not pry on the timing cover sealing surfaces with a screwdriver.

Step 5: Remove the timing cover

• Use a metric socket set with extensions to remove all timing cover bolts (note different lengths).
• Break the seal carefully and remove the cover.
• Clean old sealant using a plastic razor scraper, then wipe with brake cleaner spray and shop towels.
• Torque to factory spec (refer to Toyota service information) when reinstalling cover bolts.

Step 6: Set engine to Top Dead Center (TDC) and mark timing

• Use a socket set and breaker bar on the crank bolt to rotate the engine clockwise to TDC.
• Verify timing marks align on the crank and cam sprockets before removing the chain.
• Add your own reference marks with a paint marker for extra safety.

Step 7: Remove chain tensioner, guides, and timing chain

• Remove the timing chain tensioner bolts using a metric socket set.
• Remove the chain guides using a metric socket set.
• Carefully lift the chain off the sprockets.
• Keep bolts grouped by location.

Step 8: Install new timing chain, guides, and tensioner

• Install the new chain, aligning colored links/marks to the sprocket timing marks (as supplied by the chain kit).
• Install new guides using a metric socket set.
• Install the new tensioner using a metric socket set, then release/activate it per the tensioner’s pin/lock design.
• Torque to factory spec (refer to Toyota service information) for guides and tensioner fasteners.

Step 9: Replace the front crank seal and reseal the timing cover

• Remove the old front crank seal with pliers carefully, avoiding scratches.
• Press in the new seal evenly (use a suitable large socket from your metric socket set as a driver).
• Apply a continuous bead of timing cover sealant (Toyota FIPG equivalent RTV) to the timing cover per the sealant instructions.
• Reinstall the timing cover and hand-start all bolts, then tighten evenly with a torque wrench.
• Torque to factory spec (refer to Toyota service information).

Step 10: Reinstall crank pulley, accessories, belt, fan, and shroud

• Reinstall the crank pulley and crank bolt using a crank pulley holding tool (specialty) and torque wrench.
• Torque to factory spec (refer to Toyota service information) for the crank bolt (this is a critical fastener).
• Reinstall accessory brackets/components using a metric socket set and tighten with a torque wrench.
• Install the serpentine belt using a serpentine belt tool 14mm.
• Reinstall the fan/clutch and shroud using the fan clutch wrench set (specialty) and a 10mm socket.

Step 11: Refill fluids and reassemble remaining covers

• Reconnect hoses using hose clamp pliers.
• Refill coolant using a funnel with engine coolant.
• Change engine oil and filter (coolant/oil contamination risk during this job).
• Reinstall skid plates/splash shields using a metric socket set.
• Reconnect the battery using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle; listen for abnormal rattles at the timing cover area.
• Check for oil leaks at the timing cover and front crank seal area.
• Bring the engine to operating temperature and verify heater output (helps confirm coolant circulation).
• After a short test drive, re-check coolant level and inspect again for leaks.
• Any loud rattle: shut off immediately.

---

💰 DIY vs Shop Cost

Shop Cost: $2,000-$4,000 (parts + labor)

DIY Cost: $350-$900 (parts only)

You Save: $1,650-$3,100 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 10-16 hours.

---
