🔧 Outback - Thermostat Replacement

Replacing the thermostat on your Outback involves draining some coolant, removing the thermostat housing at the lower front of the engine, installing a new thermostat and gasket, then refilling and bleeding the cooling system. The thermostat controls engine temperature, and a stuck thermostat can cause overheating, slow warm-up, or poor heater performance.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work only on a completely cool engine. Hot coolant can cause serious burns.
• ⚠️ Do not remove the radiator cap or coolant reservoir cap while the engine is hot.
• ⚠️ Keep Subaru Super Coolant away from pets and children. It is poisonous.
• ⚠️ Support your Outback with jack stands if lifting the front. Never rely on a floor jack alone.
• ⚠️ Disconnecting the battery is not normally required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 3/8-inch ratchet
• 3/8-inch extension
• Torque wrench rated 5-30 Nm
• Flat-blade screwdriver
• Hose clamp pliers
• Plastic trim clip remover
• Drain pan rated 2-gallon minimum
• Coolant funnel kit
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine thermostat - Qty: 1
• Thermostat gasket/O-ring - Qty: 1
• Subaru Super Coolant premixed 50/50 - Qty: 1-2 gallons
• Lower radiator hose clamp - Qty: 1 if damaged
• Lower radiator hose - Qty: 1 if swollen, cracked, or oil-soaked

---

📋 Before You Begin

• Park your Outback on level ground and let the engine cool completely.
• Set the parking brake and place wheel chocks behind the rear wheels.
• If you lift the front, use a floor jack and support the vehicle with jack stands.
• Set the cabin heater temperature to full hot before starting the engine later. This helps coolant circulate through the heater core.
• A coolant funnel kit is a spill-free funnel that attaches to the radiator or reservoir opening and helps remove air pockets from the cooling system.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Secure the Front

• Use wheel chocks behind the rear wheels.
• Use a floor jack rated 2-ton minimum to lift the front of your Outback at the front center jacking point.
• Place jack stands rated 2-ton minimum under the approved front support points.
• Gently lower the vehicle onto the jack stands.
• Shake lightly to confirm stability.

Step 2: Remove the Lower Engine Cover

• Put on safety glasses and nitrile gloves.
• Use a plastic trim clip remover to remove the lower splash shield clips.
• Use a 10mm socket and 3/8-inch ratchet to remove the lower cover bolts.
• Lower the splash shield and set it aside.

Step 3: Drain the Coolant

• Place a drain pan rated 2-gallon minimum under the radiator drain area.
• Slowly remove the coolant reservoir cap by hand only after the engine is fully cool.
• Use a flat-blade screwdriver if needed to open the radiator drain cock carefully.
• Drain enough coolant so the level is below the thermostat housing.
• If the drain cock is hard to access, drain from the lower radiator hose instead in the next step.
• Do not force plastic drain fittings.

Step 4: Disconnect the Lower Radiator Hose

• Locate the thermostat housing at the lower front area of the 3.6L engine where the lower radiator hose connects.
• Use hose clamp pliers to compress the spring clamp on the lower radiator hose.
• Slide the clamp back along the hose.
• Twist the hose gently by hand to break it loose.
• Pull the hose off the thermostat housing and direct remaining coolant into the drain pan.
• A spring clamp is a factory hose clamp that squeezes the hose evenly and is opened with pliers.

Step 5: Remove the Thermostat Housing

• Use a 12mm socket, 3/8-inch extension, and 3/8-inch ratchet to remove the thermostat housing bolts.
• Support the housing by hand while removing the last bolt.
• Pull the housing away from the engine.
• Note the thermostat direction before removing it. The spring side faces into the engine.
• Take a phone photo first.

Step 6: Remove the Old Thermostat and Gasket

• Remove the old thermostat by hand.
• Remove the old thermostat gasket/O-ring by hand.
• Use shop towels to clean the sealing surfaces.
• Do not gouge or scratch the aluminum housing surface.
• An O-ring is a round rubber seal that prevents coolant leaks.

Step 7: Install the New Thermostat

• Install the new thermostat into the engine with the spring side facing inward toward the engine.
• Fit the new thermostat gasket/O-ring evenly around the thermostat.
• Make sure the thermostat sits flat and does not pinch the gasket.
• If the thermostat has a small jiggle valve or bleed pin, position it upward.
• Flat seating prevents leaks.

Step 8: Reinstall the Thermostat Housing

• Place the thermostat housing back onto the engine by hand.
• Start the bolts by hand first to prevent cross-threading.
• Use a 12mm socket and 3/8-inch ratchet to snug the bolts evenly.
• Use a torque wrench rated 5-30 Nm with a 12mm socket to tighten the thermostat housing bolts to Torque to 7.5 Nm (5.5 ft-lbs).
• Do not overtighten. The housing and engine sealing surfaces can be damaged.

Step 9: Reconnect the Lower Radiator Hose

• Push the lower radiator hose fully onto the thermostat housing neck by hand.
• Use hose clamp pliers to move the spring clamp back into its original position.
• Make sure the clamp sits behind the raised bead on the housing neck.
• Wipe the area dry with shop towels so leaks are easier to spot later.

Step 10: Refill the Cooling System

• Close the radiator drain cock by hand or with a flat-blade screwdriver using light pressure only.
• Install the coolant funnel kit at the fill point.
• Pour Subaru Super Coolant premixed 50/50 slowly into the funnel.
• Pause often and let air bubbles escape.
• Squeeze the upper radiator hose gently by hand several times to help move trapped air.

Step 11: Bleed Air from the Cooling System

• Keep the coolant funnel kit installed and partially filled.
• Start the engine and let it idle.
• Set the cabin heat to full hot and fan to low using the climate controls.
• Watch the coolant level in the funnel and add Subaru Super Coolant premixed 50/50 as the level drops.
• Let the engine warm up until the cooling fans cycle on and warm air comes from the vents.
• Use safety glasses and stay clear of belts, fans, and hot parts.
• If large bubbles continue after warm-up, keep idling until bubbles slow down.

Step 12: Final Fill and Reinstall Covers

• Turn the engine off and let it cool enough to handle safely.
• Remove the coolant funnel kit according to its instructions.
• Install the coolant cap by hand.
• Fill the overflow reservoir to the correct mark with Subaru Super Coolant premixed 50/50.
• Use a 10mm socket and 3/8-inch ratchet to reinstall the lower engine cover bolts.
• Use a plastic trim clip remover or your fingers to reinstall the splash shield clips.
• If any lower cover bolts were removed from threaded metal inserts, tighten them snug only. Typical small splash shield fasteners are Torque to 5 Nm (44 in-lbs).

---

✅ After Repair

• Start your Outback and check around the thermostat housing, lower hose, and radiator drain for leaks.
• Take a short test drive while watching the temperature gauge.
• Let the engine cool completely, then recheck the coolant level in the overflow reservoir.
• Add Subaru Super Coolant premixed 50/50 if the level drops after the first heat cycle.
• Dispose of old coolant at a proper recycling center or auto parts store. Do not pour it on the ground or into a drain.
• If the temperature gauge rises above normal, stop driving and shut the engine off safely.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $255-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
