🔧 Accord - Ignition Coil Replacement

You’ll be removing the plastic engine cover, unplugging each ignition coil, and swapping in new ones on top of the engine. This restores a strong spark and can fix misfires, rough running, and poor fuel economy.

Difficulty Level: Beginner | Estimated Time: 0.5–1 hour

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before starting to avoid burns from hot parts.
• ⚠️ Disconnect the 12V battery negative terminal so the engine cannot start while you work.
• ⚠️ Do not touch or unplug any orange high-voltage cables; those are for the hybrid system.
• ⚠️ Keep tools and hardware away from the battery terminals to avoid short circuits.
• ⚠️ Work in a well-ventilated area and keep loose clothing and jewelry away from moving parts.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ 10mm socket
• 🛠️ 3/8" drive ratchet
• 🛠️ 3/8" drive torque wrench (5–30 Nm range)
• 🛠️ 6" socket extension (3/8" drive)
• 🛠️ Flathead screwdriver
• 🛠️ Plastic trim removal tool
• 🛠️ Mechanic’s gloves
• 🛠️ Safety glasses
• 🛠️ Fender cover
• 🛠️ OBD2 scan tool (basic)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Ignition coil set (4 coils, cylinder 1–4) - Qty: 1 set
• 🔩 Spark plugs (iridium, correct heat range) - Qty: 4 (optional but recommended if high mileage)
• 🔩 Dielectric grease - Qty: 1 small tube
• 🔩 Engine cover retaining clips - Qty: 2–4 (optional, only if any break)

---

📋 Before You Begin

• Park the Accord on level ground, shift to P, and set the parking brake.
• Turn the ignition off and remove the key/fob from the vehicle.
• Open the hood and install the hood prop rod securely.
• Disconnect the 12V battery negative terminal using a 10mm socket and move the cable aside so it cannot spring back.
• Have a clean tray or container ready to hold bolts and clips so nothing gets lost.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the plastic engine cover

• Use your hands to pull up gently but firmly on the engine cover corners; it is held by rubber grommets, not screws.
• If it feels stuck, use a plastic trim removal tool under the edge to pry gently.
• Lift the cover off and set it aside in a safe place.
• Pull straight up to avoid cracking cover

Step 2: Locate the ignition coils

• Look at the top of the engine; you will see four black ignition coils in a row, each with an electrical connector, going down into the valve cover.
• These are cylinders 1–4, from the timing belt/chain side toward the transmission side (front to rear of the engine bay).
• Work one coil at a time to stay organized

Step 3: Unplug the ignition coil electrical connectors

• Starting with cylinder 1, press down on the plastic locking tab of the connector using your thumb or a flathead screwdriver if needed.
• While holding the tab down, pull the connector straight back to unplug it from the coil.
• Repeat for all four coils so the wiring harness is free.
• Never yank by the wires; pull on connector

Step 4: Remove the ignition coil hold-down bolts

• Fit a 10mm socket and 3/8" drive ratchet with a 6" extension onto the bolt securing the first coil.
• Turn the bolt counterclockwise to remove it and place it in your parts tray.
• Repeat for the remaining three coils.
• Break each bolt loose gently, do not force

Step 5: Remove the ignition coils

• Grasp the body of the first coil and twist it gently left and right to break the seal.
• Pull the coil straight up out of the spark plug tube.
• Inspect the coil boot for oil or heavy corrosion; this could mean a valve cover gasket or plug tube seal issue.
• Repeat for the other three coils.
• Keep old coils in order if diagnosing misfire

Step 6: Optional – inspect or replace spark plugs

• If you are replacing spark plugs, now is the time, but you will need a spark plug socket, which is a special deep socket with a rubber insert.
• Use a spark plug socket, 3/8" ratchet, and extension to remove and install plugs if equipped with the right tool.
• Install new plugs and torque to 18 Nm (13 ft-lbs) with a 3/8" drive torque wrench if you perform this step.
• Do not overtighten plugs; threads are delicate

Step 7: Install the new ignition coils

• Apply a small smear of dielectric grease inside each new coil boot where it contacts the spark plug.
• Align the new coil with the spark plug opening and push it straight down until it seats firmly on the plug.
• Repeat for all four coils.
• Seat coils fully to avoid misfires

Step 8: Reinstall and torque the coil hold-down bolts

• Install the original 10mm bolts by hand into each coil mounting hole to avoid cross-threading.
• Snug them down lightly with the 10mm socket and 3/8" ratchet.
• Set your 3/8" drive torque wrench to 12 Nm (8.7 ft-lbs) and tighten each bolt to this specification.
• Use a torque wrench to avoid cracking coil ears

Step 9: Reconnect ignition coil connectors

• Push each electrical connector back onto its matching coil until you feel or hear a click.
• Gently tug each connector to confirm it is locked in place.
• Make sure the wiring harness is not pulled tight or twisted.

Step 10: Reinstall the engine cover

• Position the engine cover over the engine, aligning it with the rubber mounting grommets.
• Press down firmly at each corner until it snaps into place.
• Check that it is seated evenly and not pinching any wires or hoses.

Step 11: Reconnect the battery and clear any codes

• Reconnect the 12V battery negative cable using a 10mm socket and tighten it securely.
• If the check engine light was on before due to misfires, plug in an OBD2 scan tool and clear any stored codes.
• Write down codes before clearing if unsure

---

✅ After Repair

• Start the engine and let it idle for a few minutes; it should run smoothly without shaking or misfire.
• Watch for any warning lights on the dash; if the check engine light returns, read the codes with your OBD2 scan tool.
• Take a short test drive, gently accelerating to confirm smooth power delivery with no hesitation.
• After the drive, open the hood and do a quick visual check to ensure all connectors and the engine cover are secure.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$650 (parts + labor)

DIY Cost: $200–$400 (parts only, full set of coils)

You Save: $250–$250 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 0.7–1.0 hours.

---
