🔧 Accord - Side View Mirror Replacement

You’ll remove the inner door trim, unplug the mirror wiring, and unbolt the mirror from the door. Then you’ll install the new mirror, plug it in, and reassemble the door panel.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (one side)

Assumption: power mirror with in-door connector; torque values listed are typical Honda door hardware specs.

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the 12V battery negative cable before door trim removal (side airbag wiring runs in the door on many trims).
• ⚠️ Wait at least 3 minutes after disconnecting the battery before unplugging any door connectors.
• ⚠️ Support the mirror with one hand when removing the last nut so it doesn’t fall and chip paint.
• ⚠️ Use plastic trim tools to avoid cracking trim and scratching paint.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Plastic trim removal tool set
• Phillips #2 screwdriver
• Small flat trim pick
• 10mm socket
• 1/4" ratchet
• 6" socket extension (1/4")
• Torque wrench (inch-pound or small Nm range)
• Panel clip pliers
• Painters tape (1" wide)
• Magnetic parts tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly (correct side, paint-to-match or textured) - Qty: 1
• Door panel trim clips - Qty: 6-10
• Mirror mounting gasket (if not included with mirror) - Qty: 1

---

📋 Before You Begin

• Park on level ground, key out, and open the window on the side you’re working on.
• Use painters tape (1" wide) along the door edge near the mirror to protect the paint.
• Disconnect the battery: use 10mm socket to remove the negative cable and isolate it so it can’t spring back.
• Wait at least 3 minutes before unplugging door electrical connectors.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the inner sail panel (mirror triangle trim)

• Use a plastic trim removal tool set to gently pry off the small triangular trim panel at the top-front of the door (inside corner by the mirror).
• Work slowly around the edges until the clips release. Pull straight outward to avoid breaking clips.

Step 2: Remove the door panel fasteners

• Use a small flat trim pick to pop off the small covers hiding screws (typically in the door pull/handle area).
• Remove the exposed screws with a Phillips #2 screwdriver.
• If a screw feels stuck, push the screwdriver firmly and turn slowly to prevent stripping.

Step 3: Release the door panel clips and lift the panel off

• Start at the bottom edge of the door panel.
• Use a plastic trim removal tool set to pop the panel clips free one by one.
• Once loose, lift the whole panel straight up to unhook it from the window ledge.

Step 4: Disconnect door electrical connectors

• Support the door panel close to the door so it doesn’t hang by wires.
• Unplug connectors (window switch, door lock, courtesy light) by pressing the lock tab and pulling apart by hand.
• Never pull on the wires—pull on the connector body.

Step 5: Locate and unplug the mirror connector

• Near the mirror area inside the door, find the mirror harness connector.
• Press the locking tab and unplug it.
• If it’s tight, use a small flat trim pick to gently help the tab release.

Step 6: Remove the mirror mounting nuts

• Hold the mirror from the outside with one hand.
• Use a 10mm socket, 6" socket extension (1/4"), and 1/4" ratchet to remove the mounting nuts.
• Place nuts in a magnetic parts tray so they don’t drop into the door.

Step 7: Remove the mirror from the door

• Carefully pull the mirror away from the door while feeding the wiring through the opening.
• Remove the old gasket if it stayed stuck to the door.

Step 8: Install the new mirror

• Make sure the new mirror gasket is seated flat (no folds).
• Feed the mirror wiring through the hole and position the mirror on the door.
• Start the nuts by hand first (prevents cross-threading).
• Use a torque wrench (inch-pound or small Nm range) with a 10mm socket to tighten the nuts evenly: Torque to 9.8 Nm (7.2 ft-lbs).

Step 9: Reconnect wiring and reassemble the door panel

• Plug in the mirror connector until it clicks.
• Reconnect all door panel electrical connectors.
• Hook the top of the door panel onto the window ledge, then press around the perimeter to seat the clips.
• Reinstall the screws using a Phillips #2 screwdriver.
• Reinstall the sail panel by pressing it back into place.

Step 10: Reconnect battery

• Reconnect the negative battery cable using a 10mm socket.
• Tighten securely (snug, not over-tight).

---

✅ After Repair

• Turn the key on and test mirror adjust in all directions.
• If equipped, test mirror heater and turn signal (if your replacement mirror has these features).
• Confirm the window and door lock switches work.
• Listen for door panel rattles on a short drive; re-press clips if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$650 (parts + labor, depends on mirror options/paint)

DIY Cost: $90-$450 (parts only)

You Save: $160-$200+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
