🔧 Camaro - Front Brake Pad & Rotor Replacement

This guide will walk you through replacing the front brake pads and rotors on your Camaro. You’ll lift the front, remove the wheels, swap pads and rotors, then reassemble and bed in the new brakes.

Difficulty Level: Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• 🛑 Always support the car with jack stands, never rely only on a floor jack.
• 🧯 Work on a cool car; hot brakes and rotors can burn you.
• 😷 Brake dust can be harmful; avoid blowing with compressed air and do not inhale dust.
• 🔒 Set the parking brake and leave the car in gear so it cannot roll.
• 🔋 Battery disconnect is not required for this job.
• 🧰 Use the correct torque on all bolts and the wheel lug nuts to avoid damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠 Floor jack (rated 3-ton minimum)
• 🛠 Jack stands (rated 3-ton minimum, set of 2)
• 🛠 Wheel chocks
• 🛠 Lug wrench (22mm or 7/8" for lug nuts)
• 🛠 3/8" drive ratchet
• 🛠 1/2" drive ratchet
• 🛠 13mm socket
• 🛠 18mm socket
• 🛠 T30 Torx bit socket
• 🛠 Breaker bar 1/2" drive
• 🛠 Torque wrench 3/8" drive (up to 30 ft-lbs)
• 🛠 Torque wrench 1/2" drive (up to 150 ft-lbs)
• 🛠 Disc brake caliper compressor tool (specialty)
• 🛠 Flathead screwdriver medium
• 🛠 Wire brush small
• 🛠 Bungee cord or coat hanger
• 🛠 Shop rags
• 🛠 Brake cleaner spray
• 🛠 Anti-seize compound
• 🛠 High-temperature brake grease
• 🛠 Safety glasses
• 🛠 Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🧩 Front brake pad set (ceramic or semi-metallic) - Qty: 1 set
• 🧩 Front brake rotors - Qty: 2 (replace in pairs)
• 🧩 Front brake hardware kit (pad clips/shims) - Qty: 1 kit
• 🧩 Brake cleaner (14–20 oz can) - Qty: 1–2
• 🧩 Brake fluid DOT 3 or DOT 4 - Qty: 1 small bottle (for top-off)
• 🧩 Caliper bracket bolts (optional, single-use if badly corroded) - Qty: 4
• 🧩 Rotor retaining screws T30 (if damaged or corroded) - Qty: 2

---

📋 Before You Begin

• 🚗 Park the Camaro on a flat, solid surface with plenty of room.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔒 Set the parking brake and leave the transmission in 1st gear.
• 🧼 Loosen (do not remove) front wheel lug nuts one turn while the car is still on the ground.
• 🧴 Open the hood and remove the brake fluid reservoir cap, then set it back on loosely so pressure can vent.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and Support the Front of the Car

• Use the floor jack under the front center jacking point (crossmember behind the front bumper) to lift the front of the Camaro.
• Place jack stands under the pinch welds or frame pads on each side and lower the car onto them carefully.
• Verify the car is stable by gently rocking it before removing wheels. Never work under an unstable car.

Step 2: Remove the Front Wheels

• Use the lug wrench to remove the front lug nuts completely.
• Remove both front wheels and set them aside.
• Keep the lug nuts together so they don’t get lost.

Step 3: Inspect the Front Brake Setup

• Look at the caliper (the part that clamps the rotor) and the caliper bracket (the larger metal piece holding the caliper).
• Note the brake hose routing so you can avoid twisting or pulling it later.

Step 4: Remove Caliper Slide Bolts

• On the back of the caliper, locate the two smaller slide bolts.
• Use a 13mm socket and 3/8" ratchet to loosen and remove both slide bolts.
• If the slide pin wants to spin, hold the flat on the pin with a flathead screwdriver while turning the bolt.

Step 5: Remove and Support the Caliper

• Gently slide the caliper off the pads and rotor; if stuck, use a flathead screwdriver to gently pry.
• Support the caliper with a bungee cord or coat hanger hung from the spring or frame.
• Do not let the caliper hang by the rubber brake hose.

Step 6: Remove Old Pads and Hardware

• Slide the old brake pads out of the caliper bracket by hand.
• Remove the metal pad clips (hardware) from the bracket using a flathead screwdriver if needed.
• Note how the pad with the wear indicator or spring clip was positioned for reassembly.

Step 7: Remove Caliper Bracket

• Locate the two large bolts holding the caliper bracket to the steering knuckle.
• Use an 18mm socket, breaker bar, and 1/2" ratchet to loosen and remove both bolts.
• Remove the caliper bracket and set it on a clean surface.

Step 8: Remove Rotor Retaining Screw and Rotor

• Locate the small screw near the center of the rotor face.
• Use a T30 Torx bit socket and 3/8" ratchet to remove the screw.
• Pull the rotor off the hub. If rusted, tap the rotor hat (flat center area) with a rubber mallet to free it.

Step 9: Clean Hub Surface

• Use a wire brush to clean rust and debris from the hub face where the rotor sits.
• Wipe with brake cleaner and a shop rag so the new rotor sits flat. A clean hub prevents rotor wobble.
• Apply a thin film of anti-seize compound on the hub face to reduce future rust (avoid studs).

Step 10: Install New Rotor

• Spray both sides of the new rotor with brake cleaner to remove oil coating, then wipe dry.
• Place the rotor onto the hub, lining up the screw hole.
• Install the T30 rotor screw by hand, then tighten with the T30 Torx bit and 3/8" ratchet to snug: Torque to 9 Nm (7 ft-lbs).

Step 11: Prepare and Install New Hardware

• Clean the caliper bracket pad contact areas with a wire brush and brake cleaner.
• Install the new pad clips from your hardware kit onto the caliper bracket by hand until fully seated.
• Apply a very thin layer of high-temperature brake grease on the pad contact surfaces of the clips (where the pads slide), not on the rotor or pad friction surfaces.

Step 12: Reinstall Caliper Bracket

• Position the caliper bracket over the rotor and line up bolt holes.
• Install the two bracket bolts by hand first.
• Use an 18mm socket and 1/2" torque wrench to tighten: Torque to 170 Nm (125 ft-lbs).

Step 13: Install New Brake Pads

• Identify inner and outer pads (inner often has a clip or shim that snaps into the caliper piston or bracket).
• Slide the pads into the new hardware clips in the caliper bracket by hand until they seat firmly.
• Make sure the friction material faces the rotor and pads move smoothly.

Step 14: Compress Caliper Piston

• Place an old pad against the caliper piston.
• Use the disc brake caliper compressor tool to slowly push the piston fully back into the caliper housing.
• Watch the brake fluid reservoir; if it gets too full, remove excess with a clean shop rag or appropriate tool.

Step 15: Reinstall Caliper Over New Pads

• Position the caliper over the new pads and rotor without twisting the brake hose.
• Line up the caliper slide ears with the bracket.
• Install the two slide bolts by hand to avoid cross-threading.
• Use a 13mm socket and 3/8" torque wrench to tighten slide bolts: Torque to 30 Nm (22 ft-lbs).

Step 16: Repeat for the Other Front Side

• Repeat Steps 4–15 on the other front wheel.
• Do one side at a time so you can compare if needed.

Step 17: Reinstall Wheels and Lower the Car

• Put each front wheel back onto the hub and hand-thread all lug nuts.
• Use the lug wrench to snug the lug nuts in a star pattern while the car is still on stands.
• Use the floor jack to lift the car slightly, remove the jack stands, then lower the car fully to the ground.
• Use a 1/2" torque wrench and lug socket to torque the lug nuts in a star pattern: Torque to 150 Nm (111 ft-lbs).

Step 18: Reset Brake Pedal and Check Fluid

• With the engine off, slowly pump the brake pedal until it becomes firm (usually 3–5 pumps).
• Check the brake fluid level in the reservoir and top off with DOT 3 or DOT 4 brake fluid if needed to reach the “MAX” line.
• Secure the brake fluid cap tightly.

---

✅ After Repair

• 🚦 Start the engine and press the brake pedal; it should feel firm and consistent.
• 🧪 Check around each caliper and hose for any signs of leaks or rubbing.
• 🛣 Perform a short, low-speed test drive in a safe area, checking for noises, pulling, or vibration.
• 🔥 Bed in the new pads: make 5–8 moderate stops from 30–10 mph, then 3–4 harder stops from 45–15 mph, allowing brakes to cool slightly between stops. Avoid full panic stops unless needed for safety.
• 🔁 After the drive, recheck lug nut torque once the brakes have cooled.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$750 (parts + labor)

DIY Cost: $180–$320 (parts only)

You Save: $270–$430 by doing it yourself!

Shop labor rates in Reno typically run $120–$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
