🔧 Explorer - Engine Oil & Oil Filter Change

Changing your A4’s engine oil keeps internal parts lubricated and cool, and replacing the oil filter keeps dirt and metal particles from circulating. On your Explorer, this is a straightforward maintenance job you can do at home with basic tools.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the Explorer with jack stands before going underneath.
• ⚠️ Engine oil can be very hot—let it cool 10-20 minutes if you just drove.
• ⚠️ Keep oil off the exhaust and belts to avoid smoke and smells.
• ⚠️ No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 16mm socket
• 3/8" drive ratchet
• Torque wrench (10-100 Nm range)
• Oil drain pan (8-quart minimum)
• Oil filter wrench (cap or strap type)
• Funnel
• Nitrile gloves
• Safety glasses
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 5W-20, Ford spec WSS-M2C930-A) - Qty: 5 quarts
• Oil filter - Qty: 1
• Oil drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Warm the engine for 2-3 minutes, then shut it off. Warm oil drains faster.
• Open the hood and loosen/remove the oil fill cap so the crankcase can vent while draining.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the Explorer

• Use a floor jack (rated 3-ton minimum) to lift the front of the vehicle at the proper front jacking point.
• Set it down securely on jack stands (rated 3-ton minimum).
• Give the vehicle a gentle shake to confirm it’s stable before you go underneath.

Step 2: Drain the old engine oil

• Slide the oil drain pan (8-quart minimum) under the oil pan drain plug.
• Use a 16mm socket with a 3/8" drive ratchet to loosen the drain plug, then finish removing it by hand.
• Let the oil drain until it slows to an occasional drip (usually 5-10 minutes).
• Wipe the drain plug area with shop rags.

Step 3: Reinstall the drain plug

• If you’re replacing it, install the new oil drain plug gasket on the drain plug.
• Thread the drain plug in by hand first (this helps prevent cross-threading).
• Use a torque wrench (10-100 Nm range) to tighten the drain plug: Torque to 28 Nm (21 ft-lbs).

Step 4: Remove the old oil filter

• Move the oil drain pan (8-quart minimum) under the oil filter area.
• Use an oil filter wrench (cap or strap type) to loosen the filter, then spin it off by hand.
• Make sure the old rubber gasket isn’t stuck to the engine (double-gasket can cause a major leak).
• Oil filter wrench = tool that grips the filter.

Step 5: Install the new oil filter

• Put a small film of fresh oil on the new filter’s rubber gasket (use a finger).
• Thread the new filter on by hand until the gasket touches the engine.
• Tighten by hand an additional 3/4 turn. Do not use the wrench to tighten unless access forces it.
• Wipe any spilled oil with shop rags.

Step 6: Refill with new engine oil

• Lower the Explorer off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Insert a funnel into the oil fill opening.
• Pour in about 4.5 quarts first, then wait 1 minute.
• Check the dipstick, then top off gradually to the full mark (typically ends up near 5 quarts total with a filter change).
• Reinstall the oil fill cap.

Step 7: Start engine and check for leaks

• Start the engine and let it idle for 30-60 seconds.
• Shut the engine off and wait 2 minutes.
• Check underneath for leaks at the drain plug and oil filter area (use safety glasses).
• Recheck the dipstick and top off if needed.

Step 8: Reset the oil life monitor (if equipped)

• Turn the key to ON (engine OFF).
• Using the steering wheel/message center buttons, navigate to: SETUP > OIL LIFE
• Press and hold: RESET until it shows 100%.

---

✅ After Repair

• Take a short 5-10 minute drive, then recheck for leaks and recheck the dipstick level.
• Dispose of used oil and the old filter properly at a recycling/collection center.
• If you notice dripping, stop driving and recheck the filter tightness and drain plug torque.

---

💰 DIY vs Shop Cost

Shop Cost: ₹3,000-₹6,000 (parts + labor)

DIY Cost: ₹1,800-₹3,500 (parts only)

You Save: ₹1,200-₹2,500 by doing it yourself!

Shop labor rates vary but typically run ₹800-₹1,500/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
