🔧 Accord - Front Ball Joint Replacement

On your Accord, worn ball joints can cause clunks, wandering steering, uneven tire wear, and unsafe handling. Most commonly, the front lower ball joint is replaced by pressing it out of the steering knuckle, then pressing a new one in.

Difficulty Level: Advanced | Estimated Time: 3-6 hours (both sides)

---

⚠️ Safety & Precautions

• ⚠️ Support the car with jack stands on solid ground; never rely on a floor jack alone.
• ⚠️ Wear safety glasses; ball joint tools can release suddenly.
• ⚠️ Do not hit or pull on the CV axle boots; torn boots will leak grease.
• ⚠️ If you use a “pickle fork” (a wedge-style separator), it can tear the ball joint boot—fine for removal, not for saving parts.
• ⚠️ After ball joint work, get a front-wheel alignment as soon as possible.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• 19mm lug nut socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-250 ft-lb range)
• 36mm axle nut socket
• Ratchet (3/8" drive)
• Socket set (10mm, 12mm, 14mm, 17mm, 19mm, 22mm)
• Wrench set (14mm, 17mm, 19mm, 22mm)
• Needle-nose pliers
• Diagonal cutters
• Dead-blow hammer
• Pry bar (18")
• Ball joint separator tool (specialty)
• Ball joint press kit (specialty)
• Snap ring pliers (specialty)
• Penetrating oil
• Wire brush
• Bungee cord

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front lower ball joint - Replace in pairs - Qty: 2
• Cotter pins (assorted) - Qty: 1 kit
• Front axle nuts - Replace if removed - Qty: 2
• Anti-seize compound - Qty: 1

---

📋 Before You Begin

• 🧰 Park on level ground, put the transmission in 1st gear, and set the parking brake.
• 🧰 Place wheel chocks behind the rear wheels.
• 🧰 Crack the front lug nuts loose using a 19mm lug nut socket and breaker bar before lifting.
• 🧰 Spray penetrating oil on the ball joint nut, tie-rod end nut, and axle nut area; let it soak 10–15 minutes.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the wheel

• Lift the front using a floor jack (rated 3-ton minimum) and support with jack stands (rated 3-ton minimum).
• Remove the wheel using a 19mm lug nut socket.
• Set lug nuts aside. Torque to 108 Nm (80 ft-lb) during reassembly.

Step 2: Loosen the axle nut (recommended for easier knuckle movement)

• Use needle-nose pliers to remove any staked portion (if present) and clean threads with a wire brush.
• Use a 36mm axle nut socket and breaker bar to loosen the axle nut.
• Do not fully remove it yet—leave it threaded on a few turns.
• Loosen on the ground if it’s very tight.

Step 3: Disconnect the tie-rod end from the knuckle

• Remove the cotter pin using diagonal cutters or needle-nose pliers. (A cotter pin is a small metal safety pin that locks a nut.)
• Remove the tie-rod end castle nut using a 17mm socket.
• Separate the tie-rod end using a ball joint separator tool (specialty). (A ball joint separator pushes the tapered stud out without hammering on threads.)
• During reassembly: Torque to 49 Nm (36 ft-lb), then tighten to align the cotter pin hole; install a new cotter pin.

Step 4: Free the knuckle so it can swing out

• Support the lower control arm with a floor jack (rated 3-ton minimum) so it doesn’t drop suddenly.
• Remove the damper fork pinch bolt (at the bottom of the strut/fork area) using a 14mm socket and 14mm wrench.
• During reassembly: Torque to 64 Nm (47 ft-lb).

Step 5: Separate the lower ball joint from the knuckle

• Remove the cotter pin using needle-nose pliers.
• Remove the lower ball joint castle nut using a 17mm socket.
• Use the ball joint separator tool (specialty) to pop the tapered stud out of the knuckle.
• During reassembly: Torque to 59 Nm (43 ft-lb), then tighten to align the cotter pin hole; install a new cotter pin.
• Keep the nut on a few threads while separating.

Step 6: Push the axle out of the hub (if needed)

• Remove the axle nut completely using a 36mm axle nut socket.
• Tap the axle end inward using a dead-blow hammer (hit the nut threaded on flush if you’re protecting threads).
• Swing the knuckle outward and support it with a bungee cord so the brake hose isn’t pulled tight.

Step 7: Press the old lower ball joint out of the knuckle

• Locate and remove the ball joint snap ring (if equipped) using snap ring pliers (specialty).
• Set up the ball joint press kit (specialty) on the steering knuckle so the joint presses out into the receiving cup.
• Turn the press with a breaker bar until the old joint comes out.
• (The steering knuckle is the big casting that the hub and ball joints attach to.)

Step 8: Press the new lower ball joint into the knuckle

• Clean the knuckle bore using a wire brush and wipe it clean.
• Apply a very thin film of anti-seize compound to the bore (avoid getting it on the ball joint boot).
• Use the ball joint press kit (specialty) to press the new joint in straight until fully seated.
• Reinstall the snap ring using snap ring pliers (specialty) (if equipped).

Step 9: Reassemble the suspension

• Guide the axle splines back into the hub and swing the knuckle into place by hand.
• Install the lower ball joint stud into the knuckle and thread the nut on using a 17mm socket.
• Reconnect the tie-rod end and install its nut using a 17mm socket.
• Reinstall the damper fork pinch bolt using a 14mm socket and 14mm wrench.

Step 10: Tighten the axle nut and wheel

• Install a new axle nut and tighten using a 36mm axle nut socket and torque wrench: Torque to 245 Nm (181 ft-lb).
• Reinstall the wheel and snug lug nuts using a 19mm lug nut socket.
• Lower the car and final-tighten lugs with a torque wrench: Torque to 108 Nm (80 ft-lb).

Optional Path: Accord - Upper Ball Joint (Upper Control Arm) Replacement

• On your Accord, the upper ball joint is typically serviced by replacing the upper control arm assembly (ball joint included).
• Upper ball joint nut (at knuckle) uses a 17mm socket: Torque to 44 Nm (33 ft-lb), then tighten to align cotter pin hole; install new cotter pin.
• Upper control arm mounting nuts/bolts use a 12mm socket and 14mm socket: Torque to 64 Nm (47 ft-lb).

---

✅ After Repair

• ✅ Turn the steering wheel lock-to-lock and verify nothing binds or rubs.
• ✅ Test drive at low speed first; listen for clunks over small bumps.
• ✅ Recheck axle nut and lug nut torque with a torque wrench after a short drive.
• ✅ Schedule a front-wheel alignment to prevent tire wear.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $70-$220 (parts only)

You Save: $230-$830 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
