F-150 - Taillight Bulb Replacement 💡

I’ll walk you through replacing the two main bulbs in each taillight (running/brake and turn/reverse style). Your truck uses a removable taillight housing held by two screws inside the bed opening.

Note: If your taillights look like a smooth LED “light bar” with no visible round bulbs, tell me and I’ll give the LED-specific steps. The guide below is for the common non-LED (bulb type) taillights.

Tools & Parts You’ll Need 🧰

• 🔧 Tools
  • 8 mm socket and ratchet (or nut driver) – removes taillight screws.
  • Short extension (2–3") – makes access easier but not required.
  • Flat plastic trim tool – optional, helps pry without scratching paint.
  • Clean gloves – keeps oils off bulbs and protects your hands.
• 💡 Common bulb types (2016 F-150 non-LED)
  • Brake/Tail (red): usually 3157 dual-filament bulb.
  • Turn signal / Reverse: often 3156 or similar single-filament bulb.

  Tip: Check the printing on your old bulbs or your owner’s manual to match exactly.

[HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need!]

F-150 - Safety & Prep ⚠️

• 🧯 Park safe
  • Park on a flat surface, set the parking brake, and put the shifter in PARK.
  • Turn the ignition OFF and lights OFF.
• 🔌 Battery (optional but safer)
  • You can disconnect the negative battery cable with a 10 mm wrench if you want zero chance of shorting anything, but for bulbs only, most techs leave it connected and just keep lights off.

F-150 - Remove Taillight Assembly (One Side) 🔩

Do one side at a time so you can look at the other side if you get confused.

• 🔧 Step 1 – Open the tailgate
  • Lower the tailgate fully. You’ll see two screws on the inside edge of each taillight (facing the bed).
• 🔧 Step 2 – Remove the two taillight screws
  • Use your 8 mm socket and ratchet to remove the upper and lower screws holding the taillight to the bed.
  • Set the screws somewhere safe; you’ll reuse them.
• 🔧 Step 3 – Pull the taillight straight back
  • With the screws out, the taillight is still held by plastic alignment pins that push into the body.
  • Place one hand on the outer edge of the taillight and one on the inner edge (near the bed).
  • Pull the taillight straight back toward you, not sideways. It may feel stuck; wiggle gently while pulling.
  • Tip: If it’s stubborn, use a plastic trim tool between the lamp and body to help, but don’t pry with metal to avoid scratching paint.
• 🔧 Step 4 – Support the taillight
  • Once it pops free, support it with one hand so it doesn’t hang by the wires.

F-150 - Replace the Bulbs 💡

On the back of the taillight you’ll see round bulb sockets that twist out.

• 💡 Step 5 – Identify the bulb sockets
  • Top socket: usually brake/tail (red lens area).
  • Lower socket(s): turn signal and/or reverse depending on exact lamp layout.
  • Tip: If you’re replacing “both taillight bulbs,” do each socket one by one so you don’t mix them up.
• 💡 Step 6 – Remove a bulb socket
  • Grasp the socket body (plastic part) and turn it about ¼ turn counterclockwise.
  • Pull the socket straight out of the taillight housing.
• 💡 Step 7 – Remove the old bulb
  • Most bulbs are push-in wedge style.
  • Hold the socket and pull the bulb straight out. Wiggle gently if needed.
• 💡 Step 8 – Install the new bulb
  • With clean gloves or a clean cloth, push the new bulb straight into the socket until fully seated.
  • Tip: Avoid touching the glass with bare fingers; skin oil can shorten bulb life.
• 💡 Step 9 – Reinstall the socket into the taillight
  • Align the tabs on the socket with the slots in the taillight opening.
  • Insert the socket and turn it ¼ turn clockwise until it stops and feels snug.
• 💡 Step 10 – Repeat for the other bulb(s)
  • Repeat Steps 6–9 for the second bulb in that taillight.
  • Do the same process on the other side of the truck.

F-150 - Reinstall the Taillight 🔙

• 🔧 Step 11 – Position the taillight
  • Line up the plastic guide pins on the back of the taillight with the holes in the body.
  • Push the taillight straight in until it sits flush with the body.
• 🔧 Step 12 – Install the screws
  • Reinstall the two 8 mm screws you removed earlier.
  • Tighten them snugly with the ratchet. Typical torque is about 35–45 in-lb (just past “snug” with a small ratchet). Do not overtighten or you can crack the plastic.
• 🔧 Step 13 – Repeat on the other side
  • Do the same removal and installation steps on the other taillight.

F-150 - Test the Lights ✅

• 💡 Step 14 – Function check
  • Turn the ignition to RUN (engine can stay off).
  • Turn on the parking/headlights – check both rear running lights.
  • Press the brake pedal (have a helper or use a stick against the seat) – check both brake lights.
  • Use the turn signals and shift to REVERSE (with foot on brake) to check turn and reverse bulbs.
• 🔁 If something doesn’t work
  • Recheck that the bulb is fully seated in the socket.
  • Make sure the socket is fully locked into the taillight housing.
  • Try swapping the new bulb with the old one to rule out a bad new bulb.

F-150 - Extra Tips for a Beginner 🧠

• 🧽 Clean the lens area while the taillight is off; it’s a good chance to wipe dirt away.
• 🧰 Do both sides even if only one bulb is out; the other is usually close to failing.
• 💡 Upgrade option: You can use quality LED replacement bulbs made for 3157/3156 sockets, but they must be CANbus-compatible to avoid hyperflash or errors.

If you tell me whether your current bulbs are red or clear and if you want to upgrade to LED, I can recommend exact bulb types and any extra parts (like resistors) you might need.
