🔧 Accord - Front turn signal repair

On your Accord, the front turn signals are built into the LED headlight assembly and do not use a separate, replaceable bulb. If a front turn signal is out, Honda’s repair method is to replace the entire headlight assembly on that side.

Difficulty Level: Advanced | Estimated Time: 2–3 hours per side

---

⚠️ Safety & Precautions

• ⚠️ Always disconnect the 12V battery negative cable before unplugging headlight connectors to avoid short circuits.
• ⚠️ Hybrid system stays off for this repair; do not press the POWER button while working.
• ⚠️ Support the front bumper carefully; bending it can cause paint cracks.
• ⚠️ Use fender covers or thick cloths to protect paint from scratches.
• ⚠️ Do not touch the LED elements or internal wiring inside the new headlight.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (rated 3-ton minimum)
• 🛠️ Wheel chocks
• 🛠️ 10mm socket
• 🛠️ 8mm socket
• 🛠️ 1/4" drive ratchet
• 🛠️ 3/8" drive ratchet
• 🛠️ 3" socket extension
• 🛠️ Trim clip removal tool
• 🛠️ Phillips #2 screwdriver
• 🛠️ Flathead screwdriver (small)
• 🛠️ Plastic pry tool set
• 🛠️ Torque wrench (inch-lb and ft-lb scale)
• 🛠️ Fender covers or thick towels
• 🛠️ Work light
• 🛠️ Mechanic gloves
• 🛠️ Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Front headlight assembly with integrated LED turn signal (left or right, as needed) - Qty: 1
• 🔩 Front bumper upper retaining clips - Qty: 6–10
• 🔩 Front wheel well liner push clips - Qty: 6–10
• 🔩 Lower splash shield push clips - Qty: 6–10
• 🔩 Dielectric grease (electrical connector grease) - Qty: 1 small tube
• 🔩 Touch-up paint (optional, body color) - Qty: 1

---

📋 Before You Begin

• Park the Accord on level ground, engage the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and let the front bumper area cool if the car was just driven.
• Disconnect the 12V battery: use a 10mm socket to loosen the negative (black) terminal and move it aside so it cannot touch the post.
• Gather a clean blanket or cardboard under the front bumper area so removed parts don't get scratched.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise front corner slightly (optional but helpful)

• Place the floor jack under the front center jacking point or the side pinch weld near the wheel of the headlight you’re replacing.
• Lift just enough to give more space at the wheel well. Do not go very high.
• Place jack stands under the pinch weld and gently lower the car onto them using the floor jack.
• More room makes clips easier to reach.

Step 2: Remove upper radiator cover clips

• Open the hood fully and support it with the hood prop.
• Use the trim clip removal tool or flathead screwdriver to lift the centers of the plastic push clips holding the plastic cover at the front of the engine bay.
• Remove all clips, then lift off the plastic cover and set it aside.
• Keep clips in a small container so none get lost.

Step 3: Remove top bumper-to-radiator support fasteners

• Using a 10mm socket and 1/4" drive ratchet, remove the bolts and any remaining clips along the top edge of the front bumper cover near the headlight.
• Note where different bolt types go; take a photo if helpful.

Step 4: Remove wheel well liner fasteners at bumper corner

• Turn the steering wheel away from the side you are working on to open up space.
• Use the trim clip removal tool to remove the plastic clips holding the front of the wheel well liner to the bumper on that side.
• Use a Phillips #2 screwdriver or 8mm socket (depending on which is fitted) to remove the small screws at the bumper edge to fender area.
• Gently pull the liner back to expose the bumper-to-fender fasteners underneath.

Step 5: Release bumper-to-fender fasteners

• Behind the liner edge, you’ll see a few screws or bolts where the bumper meets the fender.
• Use an 8mm socket and 1/4" drive ratchet to remove these fasteners.
• Carefully release the plastic tabs that clip the bumper to the fender by pulling the bumper outward with your hands while supporting it. Do not yank.
• Pull gently; these tabs can snap if forced.

Step 6: Remove lower bumper fasteners and loosen bumper cover

• From under the front bumper, use the trim clip removal tool to remove the plastic clips attaching the lower splash shield to the bumper cover.
• Use an 8mm socket to remove any small bolts along the bottom edge.
• With the top, side, and bottom fasteners removed on that side, gently pull the bumper cover forward at the corner below the headlight to create space.
• You usually do not need to remove the entire bumper, but it must be pulled forward enough to slide the headlight out.

Step 7: Protect paint and support bumper

• Place fender covers or thick towels over the bumper edge and fender near the headlight.
• Use a small box or stack of towels under the loosened bumper corner to support it so it doesn’t hang and stress the remaining clips.
• Support prevents paint cracking at mounting points.

Step 8: Remove headlight mounting bolts

• Locate the headlight mounting bolts: usually on top, at the inner side near the grille, and one or more hidden behind where the bumper edge was.
• Use a 10mm socket with a 3" extension and 3/8" drive ratchet to remove all visible headlight mounting bolts and any small brackets attached.
• Note their positions and lengths; take a photo if needed.

Step 9: Disconnect headlight electrical connectors

• Carefully pull the headlight slightly forward to access the wiring at the back.
• Press the locking tabs on each electrical connector with your fingers or a small flathead screwdriver and unplug them. Do not pull on the wires.
• If you have dielectric grease, apply a tiny amount to the connector seals on the vehicle harness side.
• Set the old headlight aside on a soft surface.

Step 10: Install the new headlight assembly

• Position the new headlight in front of the opening, resting on the bumper edge (protected by towels).
• Reconnect all electrical connectors by pushing them in until you feel or hear a click.
• Carefully slide the headlight into place, making sure the locating pins sit correctly in their holes and that the edges line up evenly with the bumper and fender.
• Install the headlight mounting bolts by hand first.
• Use a 10mm socket and 3/8" drive ratchet to snug them down, then torque each to 9.8 Nm (7.2 ft-lb).
• Do not overtighten; you can crack the housing.

Step 11: Refit bumper cover on that side

• Lift the bumper corner and align it with the fender and the bottom of the new headlight.
• Press along the seam where the bumper meets the fender until all the clips snap back into place.
• Reinstall the bumper-to-fender screws/bolts using an 8mm socket and snug them firmly. These are usually in the 5–7 Nm (3.7–5.2 ft-lb) range—do not overtighten into plastic.
• Reposition the wheel well liner and reinstall all clips and screws with the trim clip removal tool, Phillips #2 screwdriver, and 8mm socket.
• Reinstall the lower splash shield clips and bolts using the trim clip removal tool and 8mm socket.

Step 12: Reinstall upper fasteners and radiator cover

• Reinstall the top bumper bolts and clips along the radiator support using the 10mm socket and trim clip removal tool.
• Place the plastic radiator cover back in position and reinstall its push clips, pressing the centers down to lock them.

Step 13: Lower the vehicle and reconnect battery

• Use the floor jack to lift the front slightly, remove the jack stands, then lower the vehicle back to the ground.
• Reconnect the 12V battery negative terminal using a 10mm socket and tighten it snugly (not extremely tight).

Step 14: Function check and aim check

• Power the Accord to ON (READY) and turn on the hazard lights to check both front turn signals, as well as low beams, high beams, and position lights.
• At night or in a dim area, park facing a wall and check that the new headlight beam height is similar to the other side.
• If the aim looks off, you can adjust using the headlight vertical adjuster screw on the back of the housing with a Phillips #2 screwdriver—small turns only.

---

✅ After Repair

• Check left and right turn signals, hazard lights, parking lights, and low/high beams.
• Take a short drive at night to confirm beam pattern and that there are no vibrations or rattles from the bumper or headlight.
• Recheck the headlight mounting and bumper fasteners after a day of driving to ensure nothing has loosened.

---

💰 DIY vs Shop Cost

Shop Cost: $750–$1,100 per side (parts + labor)

DIY Cost: $350–$650 per side (parts only)

You Save: $400–$450 per side by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
