🔧 Accord - Headlight Bulb/Assembly Replacement

Your Accord Sport Hybrid uses factory LED headlights. The main low/high beams are built into a sealed LED headlight unit, so Honda does not use normal replaceable bulbs for those. If a main beam has failed, you replace the whole headlight assembly; smaller bulbs (like front turn signals) are still replaceable.

Difficulty Level: Intermediate | Estimated Time: 2–3 hours (both sides)

---

⚠️ Safety & Precautions

• ⚠️ Always turn the ignition OFF and remove the key/fob from the car before working near the front lights.
• ⚠️ Let the engine bay cool if the car was just driven; parts around the headlight can be hot.
• ⚠️ You will be loosening front bumper fasteners; support the bumper to avoid bending or cracking it.
• ⚠️ Disconnect the 12V battery negative terminal before unplugging headlight connectors to avoid shorts or warning lights.
• ⚠️ Do not touch any LED chips or clear lens surfaces with bare fingers; oils can damage them.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ 10mm socket
• 🛠️ 8mm socket
• 🛠️ 1/4" drive ratchet
• 🛠️ 1/4" drive extension (3–6")
• 🛠️ Phillips #2 screwdriver
• 🛠️ Flathead screwdriver (medium)
• 🛠️ Plastic trim clip remover tool
• 🛠️ Plastic trim pry tool set
• 🛠️ Torque wrench (inch-lb and ft-lb scale)
• 🛠️ Floor jack (rated 2-ton minimum)
• 🛠️ Jack stands (rated 2-ton minimum, set of 2)
• 🛠️ Wheel chocks
• 🛠️ Work light or headlamp
• 🛠️ Mechanic gloves
• 🛠️ Safety glasses
• 🛠️ Fender cover or clean blanket

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Left LED headlight assembly (Sport Hybrid, with LED) - Qty: 1
• 🔩 Right LED headlight assembly (Sport Hybrid, with LED) - Qty: 1
• 🔩 Front bumper push clips / retainers - Qty: 10–15 have extras in case any break
• 🔩 Front fender liner clips - Qty: 6–8
• 🔩 Dielectric grease (electrical contact grease) - Qty: 1 small tube

---

📋 Before You Begin

• 📝 Park the Accord on level ground, engage the parking brake, and place wheel chocks behind the rear wheels.
• 📝 Open the hood and support it with the prop rod.
• 📝 Use a floor jack to lift the front slightly and place it on jack stands if you want more room at the front wheel wells. This is optional but helpful.
• 📝 Disconnect the 12V battery: use a 10mm socket to loosen the negative (-) terminal clamp and move the cable aside so it cannot spring back.
• 📝 Lay a fender cover or blanket over the bumper edge and fenders to protect paint while removing the bumper and headlights.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm what you are replacing

• 🛠️ On your Accord Sport Hybrid, the low and high beams are built-in LEDs in the headlight assembly, not separate bulbs.
• 🛠️ If your problem is a dead main headlight (low or high beam), you must replace the whole LED headlight assembly on that side.
• 🛠️ If only the turn signal or small side bulb is out, those are replaceable bulbs behind the headlight. The bumper may still need to be moved for space.

Step 2: Remove upper radiator cover clips

• 🛠️ Use the plastic trim clip remover tool or a flathead screwdriver to gently lift the center pins of the plastic clips holding the black radiator cover at the front under the hood.
• 🛠️ Remove all clips along the front edge and lift the cover off. Set it aside.
• Twist gently; old clips can snap easily.

Step 3: Remove top bumper fasteners

• 🛠️ Use a 10mm socket and ratchet to remove the bolts along the top edge of the bumper cover, just in front of the headlights.
• 🛠️ Keep track of bolt locations; some may be slightly different lengths.
• Torque on reassembly: 9 Nm (80 in-lbs)

Step 4: Loosen front fender liner at both sides

• 🛠️ Turn the front wheels to the left to access the right liner, and then to the right to access the left liner, or raise the car on jack stands for better access.
• 🛠️ Use a Phillips #2 screwdriver to remove the small screws at the front of each plastic fender liner where it meets the bumper edge.
• 🛠️ Use the plastic trim clip remover tool to remove any plastic clips at the lower front corner of the liner.
• 🛠️ Gently peel back the fender liner to reveal the bumper-to-fender fasteners behind it.

Step 5: Remove side bumper-to-fender fasteners

• 🛠️ Inside the wheel well, use an 8mm socket and ratchet to remove the screws or small bolts that attach the bumper cover to the fender at the side seam.
• 🛠️ There is usually one main fastener per side; check carefully by feel.
• Torque on reassembly: 7 Nm (62 in-lbs)

Step 6: Remove lower bumper fasteners

• 🛠️ Slide under the front of the car (wear safety glasses to protect your eyes from dirt).
• 🛠️ Use a Phillips #2 screwdriver and 8mm socket to remove the screws and bolts along the bottom edge of the bumper and front undertray.
• 🛠️ Use the plastic trim clip remover tool to remove any plastic push clips under the bumper.
• Lay clips out in order as you remove them.

Step 7: Detach bumper cover from fenders

• 🛠️ With all top, side, and bottom fasteners removed, stand at one front corner of the bumper.
• 🛠️ Use your hands or a plastic trim pry tool to gently pull the bumper cover outward at the seam where it meets the fender. It will pop off plastic retaining clips.
• 🛠️ Repeat on the other side. Do not yank; there are still electrical connectors attached.

Step 8: Disconnect fog light and sensor connectors

• 🛠️ With a helper if possible, carefully pull the bumper cover forward a few inches.
• 🛠️ Reach behind the bumper and use your fingers (or a flathead screwdriver gently) to release the tabs on any fog light, parking sensor, or side marker connectors and unplug them.
• 🛠️ Once all connectors are unplugged, lift the bumper cover away and place it on a blanket face-up.

Step 9: Unplug headlight connectors

• 🛠️ At the back of each headlight, locate the main electrical connector.
• 🛠️ Press the locking tab with your thumb or a flathead screwdriver and pull the connector straight out.
• 🛠️ If there are any small bulb connectors (turn signal, side marker), unplug those as well.

Step 10: Remove headlight mounting bolts

• 🛠️ Use a 10mm socket, extension, and ratchet to remove the bolts holding the headlight to the upper core support and side brackets.
• 🛠️ Check for lower mounting bolts that may be slightly hidden; feel along the bottom of the headlight.
• Torque on reassembly: 9–10 Nm (80–89 in-lbs)

Step 11: Remove the headlight assembly

• 🛠️ Gently slide the headlight forward, wiggling it slightly to free it from any locating pins.
• 🛠️ Be careful not to scratch the bumper edges or fenders; use your plastic trim pry tool to gently open space if needed.
• 🛠️ Remove the headlight from the car and set it on a soft surface.

Step 12: Transfer any brackets or bulbs (if applicable)

• 🛠️ If your old headlight has separate brackets or rubber seals that are not included with the new unit, transfer them over using a Phillips #2 screwdriver or 10mm socket as needed.
• 🛠️ If your turn signal bulb is separate and good, twist it out of the old housing and into the new one by hand.
• 🛠️ Apply a tiny amount of dielectric grease to the electrical connector pins to help prevent corrosion.

Step 13: Install the new headlight assembly

• 🛠️ Position the new headlight in place, lining up the locating pins with the body holes.
• 🛠️ Install all headlight mounting bolts by hand first, then tighten with a 10mm socket and ratchet.
• 🛠️ Use a torque wrench with the 10mm socket to tighten bolts to 9–10 Nm (80–89 in-lbs).

Step 14: Reconnect headlight connectors and test

• 🛠️ Reconnect the main headlight electrical connector and any smaller bulb connectors by hand until they click.
• 🛠️ Reconnect the 12V battery negative terminal using a 10mm socket and tighten to 7 Nm (62 in-lbs).
• 🛠️ Turn the ignition ON and test low beam, high beam, turn signals, and DRLs to make sure everything works.
• 🛠️ Turn ignition OFF and disconnect the battery negative again before putting the bumper back, for safety.

Step 15: Reinstall the bumper cover

• 🛠️ With a helper, position the bumper cover in front of the car.
• 🛠️ Reconnect all fog light and sensor connectors by hand until they click.
• 🛠️ Slide the bumper into place, making sure the top edge sits under the headlight edges and the side tabs line up with the fender slots.
• 🛠️ Press along the bumper-to-fender seams by hand until all side clips snap in.

Step 16: Reinstall bumper fasteners (bottom, sides, top)

• 🛠️ Under the bumper, reinstall all screws, bolts, and clips using the Phillips #2 screwdriver, 8mm socket, and plastic trim clip remover tool (to push in center pins).
• 🛠️ At the wheel wells, reinstall the bumper-to-fender fasteners using the 8mm socket and then secure the fender liner with screws and clips.
• 🛠️ At the top, reinstall the bumper bolts with the 10mm socket and torque to 9 Nm (80 in-lbs).

Step 17: Reinstall upper radiator cover

• 🛠️ Place the plastic cover back over the radiator support.
• 🛠️ Insert each clip, push the body in first, then press the center pin down with your thumb.

Step 18: Final electrical check and battery connection

• 🛠️ Reconnect the 12V battery negative terminal for the last time using a 10mm socket and tighten to 7 Nm (62 in-lbs).
• 🛠️ Turn ignition ON and re-check all front lights: low beams, high beams, turn signals, DRLs, and fog lights if equipped.
• 🛠️ Check for any warning messages in the dash. If any appear, turn the car OFF, wait 30 seconds, and restart.

---

✅ After Repair

• ✅ In the dark, park about 3–5 meters from a wall and check that both beams are even and pointing straight. The LED aim is fixed, but major misalignment could mean the headlight is not seated correctly.
• ✅ Take a short drive at night on a familiar road to confirm good visibility and that other drivers are not flashing you (indicating aim is too high).
• ✅ If steering feels normal and no warning lights appear after a few trips, the job is complete.

---

💰 DIY vs Shop Cost

Shop Cost: $900–$1,500 per side (parts + labor) if replacing full LED assemblies at a dealer.

DIY Cost: $350–$800 per side (parts only), depending on OEM vs aftermarket headlight assemblies and clips.

You Save: $400–$900+ by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
